Owner's Instruction and Operation Manual
Model Number:
AP5790
Report #: F20-578
Certified to: ASTM E1509-12 (2017)
and Certified to: ULC-S627-00-REV1
Mobile Home Approved
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
Save These Instructions In A Safe Place For Future Reference.
SAFETY NOTICE: If this heater is not properly installed, a house fire may result.
For your safety, follow the installation instructions. Never use make-shift
compromises during the installation of this heater. Contact local building or
fire officials about permits, restrictions and installation requirements in your
area. NEVER OPERATE THIS PRODUCT WHILE UNATTENDED.
CAUTION! Please read this entire manual before you install or use your new room
heater. Failure to follow instructions may result in property damage, bodily injury,
or even death. Improper Installation Will Void Your Warranty!
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
© 2021 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380
R
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to
852421F-1204K
www.P65warnings.ca.gov
Ph. 800-750-2723

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP5790 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ashley AP5790

Summary of Contents for Ashley AP5790

  • Page 1 Owner’s Instruction and Operation Manual Model Number: AP5790 Report #: F20-578 Certified to: ASTM E1509-12 (2017) and Certified to: ULC-S627-00-REV1 Mobile Home Approved * All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary. 852421F-1204K Save These Instructions In A Safe Place For Future Reference.
  • Page 2 Your stove is certified to ASTM E1509-12 (2017), and Certified to ULC S627, 2000. This manual describes the installation and operation of the Ashley, AP5790 wood heater. This heater meets the 2020 US Environmental Protection Agency’s wood pellet emissions limits for wood heaters sold after May 15, 2020.

  • Page 3: Installation Checklist

    INSTALLATION CHECKLIST Your Wood Stove should be installed by a qualified installer only. An NFI qualified Installer can be found at www.nficertified.org/public/find-an-nfi-pro/ CUSTOMER SERVICE 1-800-750-2723 ext 5050 Text to 423-301-5624 Email to: Customerservice@usstove.com COMMISSIONING CHECKLIST This Checklist is to be completed in full by the qualified person who installs this unit. Keep this page for future reference.

  • Page 4: Installation

    INSTALLATION SAFETY NOTICE ATTENTION: • IF THIS STOVE IS NOT PROPERLY INSTALLED, • A WORKING SMOKE DETECTOR MUST BE A HOUSE FIRE MAY RESULT. TO REDUCE THE INSTALLED IN THE SAME ROOM AS THIS RISK OF FIRE, FOLLOW THE INSTALLATION PRODUCT.

  • Page 5: Floor Protection

    INSTALLATION IMPROPER INSTALLATION safety reasons, please adhere to the installation clearances and restrictions. Any reduction in The use of other components other than stated clearance to combustibles may only be done by herein could cause bodily harm, heater damage, means approved by a regulatory authority. and void your warranty.

  • Page 6: Outside Air Supply

    INSTALLATION OUTSIDE AIR SUPPLY long enough to go through both a hearth pad, if (OPTIONAL, UNLESS used, and the floor of the home. INSTALLING IN A MOBILE HOME) • The heater must be electrically grounded to the ATTENTION: steel chassis of the mobile home with 8 GA copper wire using a serrated or star washer to penetrate DO NOT VENT UNDER ANY PORCH, DECK, paint or protective coating to ensure grounding.

  • Page 7: Maximum Venting Distance

    INSTALLATION MAXIMUM VENTING DISTANCE enable collection of fly ash and to permit periodic cleaning of the exhaust system. 90-degree elbows Installation MUST include at least 3-feet of vertical accumulate fly ash and soot thereby reducing pipe outside the home. This will create some natural exhaust flow and performance of the stove.

  • Page 8: Through The Wall Installation

    INSTALLATION A. Minimum 4-foot (1.22m) clearance below or of the snowdrift line, dead grass, and leaves. We beside any door or window that opens. recommend a 3ft (0.91m) minimum vertical rise on the inside or outside of the house. The “through the B.

  • Page 9: Panel Controls

    OPERATION INSTRUCTIONS NEVER OPERATE THIS PRODUCT WHILE UNATTENDED PANEL CONTROLS • The °C / °F button changes the two digit display from degrees Celsius to degrees Fahrenheit. D. MODE (M/T) BUTTON • The Mode of the stove can be switched between manual and controlled with a Thermostat.

  • Page 10: Proper Fuel

    OPERATION INSTRUCTIONS been, or are wet, will result in reduced performance. WARNING: Store your pellets in a dry place. DO NOT store the HOT WHILE IN OPERATION. KEEP CHILDREN, fuel within the installation clearances of the unit CLOTHING AND FURNITURE AWAY. CONTACT or within the space required for refuelling and ash MAY CAUSE SKIN BURNS.
  • Page 11 OPERATION INSTRUCTIONS PRE-START-UP CHECK pellet brands and pellet feed rates. It allows you to improve the efficiency of your stove. Providing Remove burn pot, making sure it is clean and none correct combustion air will reduce the frequency of the air holes are plugged. Clean the firebox, and of cleaning your glass door and prevent the rapid then reinstall burn pot.

  • Page 12: Room Air Fan

    OPERATION INSTRUCTIONS ROOM AIR FAN Turning your stove off is a matter of pressing the “POWER” button on the display board. The green When starting your stove the Room Air Fan will not light will turn back to red when the “POWER” come on until the stove’s heat exchanger warms up.

  • Page 13: Maintenance

    OPERATION INSTRUCTIONS while cleaning or if the stove does not seem to be burning properly. If a vacuum is used to clean your stove, we suggest Clean-Out Plate using the AV15E AshVac vacuum. The AV15E AshVac is designed for ash removal. Some regular vacuum cleaner (i.e.

  • Page 14: Blower Motors

    MAINTENANCE ASH REMOVAL & DISPOSAL is recommended that you use both smoke and CO monitors in areas having the potential to generate CAUTION: ALLOW STOVE COOL BEFORE CHECK & CLEAN THE HOPPER PERFORMING MAINTENANCE Check the hopper periodically to determine if there CLEANING.

  • Page 15: Fall Start Up

    MAINTENANCE carefully remove any loose pieces of glass from firebox. It may be desirable to spray the inside of the door frame. Dispose of all broken glass the cleaned hopper with an aerosol silicone spray properly. if your stove is in a high humidity area. The exhaust system should be thoroughly cleaned.

  • Page 16: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE When your stove acts out of the ordinary, the first reaction is to call for help. This guide may save time and money by enabling you to solve simple problems yourself. Problems encountered are often the result of only five factors: 1) poor fuel;...
  • Page 17 TROUBLE SHOOTING GUIDE Airflow switch wire Check the connectors that attach the gray wires to the air switch. connections are bad. With the stove on, check to see if the combustion blower is running. If it is not, you will need to check for power going to the combustion blower. It Combustion blower failure.
  • Page 18 TROUBLE SHOOTING GUIDE Temporarily bypass the POF thermodisc by disconnecting the two wires and connecting them with a short piece of wire. Then plug the stove Proof Fire back up. If the stove comes on and works, you need to replace the POF (POF) thermodisc thermodisc.
  • Page 19 TROUBLE SHOOTING GUIDE Display is Flashing “E5” Possible Causes Possible Remedies: (Unplug stove first when possible) The T-stat sensor has come unplugged from the control board. Check to stove automaticaly see if the sensor is unplugged. If the sensor is not unplugged, then the flashes "E5"...
  • Page 20 TROUBLE SHOOTING GUIDE Convection Blower Shuts Off And Comes Back On Possible Causes Possible Remedies: (Unplug stove first when possible) The convection blower is overheating and tripping Clean any dust off of the windings and fan blades. If cleaning the blower the internal temperature does not help, the blower may be bad.
  • Page 21 TROUBLE SHOOTING GUIDE High Limit Switch Keeps Tripping Possible Causes Possible Remedies: (Unplug stove first when possible) The convection blower is overheating and tripping Clean any dust off of the windings and fan blades. If oiling the blower does the internal temperature not help, the blower may be bad.

  • Page 22: Replacement Part

    To order parts: Call 1-800-750-2723 Ext 5051 or Email to: parts@usstove.com IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ASHLEY PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM ASHLEY. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY.
  • Page 23 REPLACEMENT PART © 2021 United States Stove Company...
  • Page 24 To order parts: Call 1-800-750-2723 Ext 5051 or Email to: parts@usstove.com IN ORDER TO MAINTAIN WARRANTY, COMPONENTS MUST BE REPLACED USING ASHLEY PARTS PURCHASED THROUGH YOUR DEALER OR DIRECTLY FROM ASHLEY. USE OF THIRD PARTY COMPONENTS WILL VOID THE WARRANTY.

  • Page 25: Wiring Diagram

    WIRING DIAGRAM ENSURE THE WIRES ARE CONNECTED TO THE BOTTOM TWO PRONGS OF THE HOPPER SWITCH AS SHOWN. CORRECT WRONG HOW TO ORDER REPAIR PARTS For Parts Assistance Call: 800-750-2723 Ext 5051 or Email: parts@usstove.com The information in this owner’s manual is specific to your unit. When ordering replacement parts the information in this manual will help to ensure the correct items are ordered.

  • Page 26: Service Record

    SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary.
  • Page 27 NOTES © 2021 United States Stove Company...
  • Page 28 NOTES © 2021 United States Stove Company...
  • Page 29 NOTES © 2021 United States Stove Company...
