Ashley AP5617-P Owner’s Instruction And Operation Manual

Hide thumbs Also See for AP5617-P:
Table of Contents

Advertisement

Quick Links

Owner's Instruction and Operation Manual
Model Number:
AP5617-P
Report #: F22-777
Certified to ASTM E1509-12 (2017)
and Certified to ULC-S627-00-REV1
Mobile Home Approved
* All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary.
Save These Instructions In A Safe Place For Future Reference.
SAFETY NOTICE: If this heater is not properly installed, a house fire may result.
For your safety, follow the installation instructions. Never use make-shift
compromises during the installation of this heater. Contact local building or
fire officials about permits, restrictions and installation requirements in your
area. NEVER OPERATE THIS PRODUCT WHILE UNATTENDED.
CAUTION! Please read this entire manual before you install or use your new room
heater. Failure to follow instructions may result in property damage, bodily injury,
or even death. Improper Installation Will Void Your Warranty!
U.S. Environmental Protection Agency
Certified to comply with 2020 particulate
emissions standards.
THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE.
© 2022 United States Stove Company, 227 Industrial Park Rd., South Pittsburg, TN 37380
R
CALIFORNIA PROPOSITION 65 WARNING:
This product can expose you to chemicals including carbon
monoxide, which is known to the State of California to cause
cancer, birth defects, and/or other reproductive harm. For
more information, go to
8 5 3 9 2 7-2 3 03 L
www.P65warnings.ca.gov
Ph. 800-750-2723

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AP5617-P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ashley AP5617-P

Summary of Contents for Ashley AP5617-P

  • Page 1 Owner’s Instruction and Operation Manual Model Number: AP5617-P Report #: F22-777 Certified to ASTM E1509-12 (2017) and Certified to ULC-S627-00-REV1 Mobile Home Approved * All Pictures In This Manual Are For Illustrative Purposes Only. Actual Product May Vary. 8 5 3 9 2 7-2 3 03 L Save These Instructions In A Safe Place For Future Reference.
  • Page 2 Your stove is Certified to ASTM E1509-12 (2017) and Certified. This manual describes the installation and operation of the Ashley, pellet stove. This heater meets the 2020 U.S. Environmental Protection Agency’s crib wood emission limits for wood-heaters sold after May 15, 2020.

  • Page 3: Installation Checklist

    INSTALLATION CHECKLIST Your Wood Stove should be installed by a qualified installer only. An NFI qualified Installer can be found at www.nficertified.org/public/find-an-nfi-pro/ CUSTOMER SERVICE 1-800-750-2723 ext 5050 Text to 423-301-5624 Email to: Customerservice@usstove.com COMMISSIONING CHECKLIST This checklist is to be completed in full by the qualified person who installs this unit. Keep this page for future reference.
  • Page 4 ASSEMBLY INSTRUCTIONS FOR CUSTOMER SERVICE CALL: 800-750-2723 EXT 5050 Pull the factory installed wires out of the top of 3. Connect the factory installed wiring harnesses the stove. There will be two wire harnesses, as to the control panel as shown. shown.

  • Page 5: Installation

    INSTALLATION FOR CUSTOMER SERVICE CALL: 800-750-2723 EXT 5050 SAFETY NOTICE CAUTION: • IF THIS STOVE IS NOT PROPERLY INSTALLED, BURNING FUEL CREATES CARBON MONOXIDE A HOUSE FIRE MAY RESULT. TO REDUCE THE AND CAN BE HAZARDOUS TO YOUR HEALTH RISK OF FIRE, FOLLOW THE INSTALLATION IF NOT PROPERLY VENTED.

  • Page 6: Installation Options

    INSTALLATION INSTALLATION OPTIONS CLEARANCES Freestanding Unit - supported by pedestal/legs Your pellet stove has been tested and listed and placed on a non-combustible floor surface for installation in residential, mobile home in in compliance with clearance requirements for a accordance with the clearances given below. For freestanding stove installation.

  • Page 7: Outside Air Supply

    INSTALLATION OUTSIDE AIR SUPPLY wire using a serrated or star washer to penetrate (OPTIONAL, UNLESS INSTALLING IN A MOBILE HOME) paint or protective coating to ensure grounding. Depending your location home • Vent must be 3 or 4-inch “PL” Vent and must construction, outside air may be necessary for extend a minimum or 36”...

  • Page 8: Pellet Vent Installation

    INSTALLATION during appliance shutdown and keep exhaust from several times during the burning season. The pellet causing a nuisance or hazard by exposing people vent pipe is not furnished with the unit and must or shrubs to high temperatures. The maximum be purchased separately.
  • Page 9 INSTALLATION maintain proper clearances from any combustible surfaces or materials in the room where your heater will be located. You can find proper clearance measurements in this manual and on the rating label of your pellet stove. The pellet stove can be vented through an exterior wall or into an existing masonry or metal chimney if “PL”...

  • Page 10: Through The Wall Installation

    INSTALLATION THROUGH THE WALL INSTALLATION 4. Locate the center of the exhaust pipe of your unit. This point should then be extended to (RECOMMENDED INSTALLATION) the interior wall of your house. Once you have located the center point, on the interior wall, cut a 7”...

  • Page 11: Through The Roof/Ceiling Installation

    INSTALLATION section and vertical pipe inside until ground level is reached. With this installation you have to be aware of the snowdrift line, dead grass, and leaves. We recommend a 3ft (0.91m) minimum vertical rise on the inside or outside of the house. The “through the wall”...
  • Page 12 OPERATION INSTRUCTIONS NEVER OPERATE THIS PRODUCT WHILE UNATTENDED PANEL / REMOTE CONTROLS C. °C / °F Button • The °C / °F button changes the two digit display from degrees Celsius to degrees Fahrenheit. NOTE: Operation range of this D. MODE (M/T) BUTTON remote is within 16-1/12 ft.

  • Page 13: Proper Fuel

    OPERATION INSTRUCTIONS PROPER FUEL need for more frequent maintenance. You will have to empty the burn pot plus vacuum the entire system more often. Poor quality pellets ATTENTION: could damage the auger. We cannot accept THIS APPLIANCE IS DESIGNED FOR THE responsibility for damage due to poor quality USE OF PELLETIZED FUEL THAT MEET pellet.
  • Page 14 OPERATION INSTRUCTIONS PRE-START-UP CHECK If the door is opened while the stove is in operation it must be closed within 30 seconds or the stove Remove burn pot, making sure it is clean and none will shut down. If the stove shuts down push the of the air holes are plugged.

  • Page 15: Shutdown Procedure

    OPERATION INSTRUCTIONS REFUELING A. To recognize an overheat situation in the stove and shut down the fuel feed or auger system. CAUTION: B. In case malfunctioning convection blower, the high-temperature snap disc will • THE HOPPER AND STOVE TOP WILL BE automatically shut down the auger, preventing HOT DURING OPERATION;...
  • Page 16 OPERATION INSTRUCTIONS d. Remove fly ash. It is possible that creosote may accumulate in the exhaust fan therefore, this must be brushed clean. The exhaust fan can be found behind the left side panel (facing the front of the heater), the circulation fan can be found behind the right side panel.

  • Page 17: Maintenance

    MAINTENANCE NEVER OPERATE THIS PRODUCT WHILE UNATTENDED service. It is also recommended that before each CAUTION: heating season the entire system be professionally • FAILURE TO CLEAN AND MAINTAIN THIS inspected, cleaned and, if necessary, repaired. To UNIT AS INDICATED CAN RESULT IN POOR clean the chimney, disconnect the vent from the PERFORMANCE, SAFETY HAZARDS, FIRE, stove.
  • Page 18 MAINTENANCE CHECK & CLEAN THE HOPPER 6. Never use substitute materials for the glass. Check the hopper periodically to determine if there DO NOT abuse the door glass by striking, slamming, is any sawdust (fines) that is building up in the feed or similar trauma.

  • Page 19: Troubleshooting Guide

    TROUBLESHOOTING GUIDE When your stove acts out of the ordinary, the first reaction is to call for help. This guide may save time and money by enabling you to solve simple problems yourself. Problems encountered are often the result of only five factors: 1) poor fuel;...
  • Page 20 TROUBLESHOOTING GUIDE Display is Flashing “E2” Possible Causes Possible Remedies: (Unplug stove first when possible) Unhook air hose from the air switch and blow through it. If air Airflow switch hose or stove attachment pipes flows freely, the hose and tube are fine. If air will not flow throw for hose are blocked.
  • Page 21 Display is Flashing “E3” Possible Causes Possible Remedies: (Unplug stove first when possible) The hopper is out of pellets Refill the hopper. The air dampener is too far open for a low feed If on the low setting, you may need to close the dampener all the setting way.
  • Page 22 Display is Flashing “E4” Possible Causes Possible Remedies: (Unplug stove first when possible) The air inlet, burnpot, interior combustion air Follow all cleaning procedures in the maintenance section of the chambers, combustion blower, or exhaust pipe owner’s manual. are blocked with ash or foreign material. The Proof of Fire (POF) thermodisc has came Check the (POF) thermodisc to see if the wires are connected unplugged...
  • Page 23 Stove Feeds Pellets, But Will Not Ignite Possible Causes Possible Remedies: (Unplug stove first when possible) In some situations it may be necessary to have the damper Air damper open too far for ignition. completely closed for ignition to take place. After there is a flame, the damper can then be adjusted for the desired feed setting.

  • Page 24: Repair Parts

    REPAIR PARTS NOTE: NUMBERS 4, 6, &16 ARE NOT YET SHOWN To order parts: Part # Description Call 1-800-750-2723 Ext 5051 or 1/8 X 1 Window Gasket W/ 88174 7.28 ft Email to: parts@usstove.com Adhesive 893159 Clear Glass 88324 1” Rope Gasket 5.17 ft 80780 IR Remote...

  • Page 25: Wiring Diagram

    WIRING DIAGRAM Ensure the wires are connected to the bottom two prongs of the hopper switch as shown. CORRECT WRONG HOW TO ORDER REPAIR PARTS For Parts Assistance Call: 800-750-2723 Ext 5051 or Email: parts@usstove.com The information in this owner’s manual is specific to your unit. When ordering replacement parts the information in this manual will help to ensure the correct items are ordered.

  • Page 26: Service Record

    SERVICE RECORD It is recommended that your heating system is serviced regularly and that the appropriate Service Interval Record is completed. SERVICE PROVIDER Before completing the appropriate Service Record below, please ensure you have carried out the service as described in the manufacturer’s instructions. Always use the manufacturer's specified spare part when replacement is necessary.
  • Page 27 NOTES © 2022 United States Stove Company...
