LITHIUM SERIES® II Electric Torque Tool
Icon Reference Guide
333 Route 17 N.
Mahwah, NJ 07430
USA
800-FOR-HYTORC
(800-367-4986)
201-512-9500
hytorc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LITHIUM II Series and is the answer not in the manual?

Questions and answers

Related Manuals for Hytorc LITHIUM II Series

Summary of Contents for Hytorc LITHIUM II Series

  • Page 1 LITHIUM SERIES® II Electric Torque Tool Icon Reference Guide 333 Route 17 N. 800-FOR-HYTORC hytorc.com Mahwah, NJ 07430 (800-367-4986) 201-512-9500...

  • Page 3: Language Translations

    DISCLAIMER: Featured imagery and content subject to change without notice. NOTICE OF PROPRIETARY RIGHTS: HYTORC Division UNEX Corporation (“HYTORC”) is the owner of all content included in this document and all right, title and interest to such content shall remain with HYTORC. COPYRIGHT NOTICE: © 2020 HYTORC. Any unauthorized use or distribution of any material from this document, without HYTORC’s written permission, is strictly prohibited.
  • Page 5 3. Schraubenart RH – Right Hand Fastener 4. Tipo di Fissaggio LH – Left Hand Fastener HWR – HYTORC Washer Right 5. Élément de montage HWL – HYTORC Washer Left 6. Tipo de cierre HN – HYTORC Nut...
  • Page 6 (C O N T ’ D . ) ICON MEANING DESCRIPTION Main Menu Main Menu “Hamburger” icon is 1. 主菜单 displayed in the lower center box of the 2. メインメニュー Home Screen, which corresponds to the 3. Hauptmenü center button. Pushing the center button 4.

  • Page 7: Scroll Down

    2 . M E N U N AV I G AT I O N 2 . M E N U N AV I G AT I O N ICON MEANING DESCRIPTION Scroll Up On menu screens, the Up-Arrow guides 1. 向上滚动 the user to push the left button to scroll 2.
  • Page 8 6. Liberación Fastener Fastener allows the selection of fastener 1. 紧固件 type: Right Hand Nut, Left Hand Nut, 2. ファスナー HYTORC Washer Right Hand, HYTORC 3. Verbindungselement Washer Left Hand and HYTORC Nut. 4. Fissaggi di serraggio 5. Fixation 6. Sujetador...
  • Page 9 6. Administrador Service Service sub-menu provides access to 1. 服务 the calibration menu and other options 2. サービス typically only used by authorized HYTORC 3. Service service personnel. 4. Servizio 5. Un service 6. Servicio LITHIUM SERIES® II ELECTRIC TORQUE TOOL ICON REFERENCE GUIDE...
  • Page 10 4 . A DVA N C E D B O LT I N G ICON MEANING DESCRIPTION Turn Angle Turn Angle allows the user to tighten a 1. 转动角度 fastener to a specific angle independent 2. 角度締め of the torque previously applied. Often 3.
  • Page 11 5 . J O B S ICON MEANING DESCRIPTION Start Job Start Job allows the user to select a Job 1. 开始工单 ID and begin recording data under that 2. 作業開始 Job ID. Appears only if no job is active. 3.
  • Page 12 (C O N T ’ D . ) ICON MEANING DESCRIPTION Delete Jobs Delete Jobs allows the user to delete a 1. 删除工作 job, or all jobs, from the tool. The data 2. 作業データー削除 records will no longer be accessible to 3.

  • Page 13: Delete Profile

    (C O N T ’ D . ) ICON MEANING DESCRIPTION Delete Profile Delete Profile allows the user to delete 1. 删除简述 profiles from the list of existing profiles. 2. プロファイル削除 3. Profil Löschen 4. Cancello Profilo 5. Supprimer le profil 6.
  • Page 14 6 . S E T T I N G S ICON MEANING DESCRIPTION Units Units allows the user to set the tool to 1. 单位 display torque in foot-pounds (ft-lbs), 2. 単位 Newton-meters (N-m), kilogram force 3. Einheiten meters (kgf-m) or as a percentage of the 4.
  • Page 15 (C O N T ’ D . ) ICON MEANING DESCRIPTION Angle Delay Angle Delay inserts a time delay between 1. 角度延迟 subsequent torque, angle, and release 2. 動作切替時間 operations that occur within the same 3. Winkelverzögerung trigger pull. 4. Ritardo dell’angolo 5.

  • Page 16: Work Light

    4. Luce di lavoro 5. Lampe de travail 6. Luz de trabajo App Mode App Mode allows the tool to be synced 1. 应用程式模式 with HYTORC bolting software via 2. アプリモード Bluetooth. 3. App Modus / Anwendungsmodus 4. Modalità app 5. Mode d'application...

  • Page 17: Access Level

    4. Livello di Accesso L3 – Full User 5. Niveau d'accès L4 – Admin 6. Nivel de acceso L5 - Service (HYTORC personnel only) Tool Info Tool Info provides the user with useful 1. 工具信息 information including the tool’s model 2.

  • Page 18: Change Password

    (C O N T ’ D . ) ICON MEANING DESCRIPTION Change Password The Change Password option allows an 1. 更改密码 Admin user to change the password for 2. パスワード変更 their level and for each lower access level. 3. Passwort ändern 4.
  • Page 19 L5 Service Service (L5) level provides access to all 1. L5服务 of the tool’s functionality. It is reserved for 2. L5サービス HYTORC service personnel. 3. L5 Service 4. Servizio L5 5. Service L5 6. L5 Servicio LITHIUM SERIES® II ELECTRIC TORQUE TOOL ICON REFERENCE GUIDE...
  • Page 21 On average, a tool with HY-CARE lasts up to five times longer in service. Never settle for less. *May not be available in all locations. Please contact your local HYTORC representative for more information. VISIT US ONLINE hytorc.com/standard hytorc.com/customer-service-policy...
