Blodgett BLP-30E Specifications

BLP-E
Electric Floor Model Braising Pan with
Power Tilt
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
220 VAC, 1 phase, 60 Hz
220 VAC, 3 phase, 60 Hz
220/380 VAC, 3 phase, 60 Hz
240/415 VAC, 3 phase, 60 Hz
480 VAC, 3 phase, 60 Hz
600 VAC, 3 phase, 60 Hz
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Etched markings
Gallons
Litres
18 kW elements (40 gallon braising pans only)
Steam pan insert
Pan carrier
Correctional package
Project
Item No.
Quantity
CONSTRUCTION
OPERATION
STANDARD FEATURES
*
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Model BLP-30E (30 gallon electric braising pan with power tilt)
Model BLP-40E (40 gallon electric braising pan with power tilt)
#4 finish 10 gauge stainless steel pan with polished interior, front
hinged for easy tilting
Coved corners
5/8" thick stainless steel clad plate
Tubular heating elements clamped to underside of pan
Welded stainless steel pipe frame with bullet feet on front legs and
flanged adjustable feet on back legs
Front control console
Integrally mounted controls
Power switch
Thermostat
Cook indicator light
High temperature cut-off
Tilt switch
160-445°F (71-230°C) temperature range
Electric motor driven screw jack for smooth and precise tilting
Spring assist hinged stainless steel cover with handle
No drip condensate guide
Removable pour strainer
Manual control
Standard voltage options
208 VAC, 1 phase, 60 Hz
240 VAC, 1 phase, 60 Hz
208 VAC, 3 phase, 60 Hz
240 VAC, 3 phase, 60 Hz
One year parts and labor warranty*
For all international markets, contact your local distributor.
BLODGETT
