Blodgett BTT-16E Specifications

BTT-16E
Electric Table Top Tilting
Round Braising Pan
Shown with optional stand
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Voltage options
380 VAC, 3 phase, 60 hz
415 VAC, 3 phase, 60 hz
480 VAC, 3 phase, 60 hz
600 VAC, 3 phase, 60 hz
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Etched markings
Gallons
Litres
30" wide stainless steel stand with sliding drawer
and stationary drain connection
Steam pan insert
Marine lock
Lift off cover
44 Lakeside Avenue, Burlington, VT 05401 • Phone: (802) 658-6600 • Fax: (802) 864-0183
Project
Item No.
Quantity
Model BTT-16E (16 gallon electric round tilting braising pan)
CONSTRUCTION
Satin finish 10 gauge stainless steel pan with polished interior
Coved corners
Pan slopes outward for easy access to cooking surface
3/8" thick stainless steel clad plate
7.5 kW heating elements are clamped to plate to ensure even heat
transfer over entire cooking surface
Stainless steel control housing
Side pivots for tilting
Tilting handle with heat proof knob
Concealed mounting legs for bolting unit to counter top or stand
OPERATION
Integrally mounted controls
Power switch
Thermostat
Cook indicator light
High temperature cut-off
160-445°F (71-229°C) temperature range
CAPACITY
16 gallon (60 litres)
STANDARD FEATURES
Side pivots and tilting handle
Manual control
Mounts to counterop (optional stand available)
Standard voltage options
208 VAC, 1 or 3 phase, 60 hz
220 VAC, 1 or 3 phase, 60 hz
240 VAC, 1 or 3 phase, 600 hz
220/380, 240, 415 VAC, 3 phase, 4 wire
One year parts and labor warranty*
* For all international markets, contact your local distributor.
