2500C-8-TC Installation and Operation Guide

Appendix A Module Specifications

Operation Mode Support (See Note 1)
Module Logon
Module Update Time all modes
Digital Filtering Time Constant
Thermocouple Measurement Ranges
Accuracy :
Thermocouple Types and mV
Open Thermocouple Detection
mV input impedance
Repeatability
Measurement Units
Resolution
Data Presentation w/scaling disabled
Data Presentation w/scaling enabled
Common Mode Rejection
Normal Mode Rejection
Backplane Power (MAX)
Input ESD Protection
Isolation
Operating Temperature Range
Agency Approvals Pending
Shipping Dimensions and Weight
Storage Temperature Range
Relative Humidity
Input Specifications
Classic Mode Classic Plus Mode
8WX
9mS
80mS
º º
J: -210 C to 760ºC (-350 F to 1400
º º º
K: -270 C to 1372 C (-450 F to 2500
º º º
T: -270 C to 400 C (-454 F to 752
º º º
E: -270 C to 1000 C (-454 F to 1832
º º º
R: 0 C to 1768 C (32 F to 3214
º º º
S: 0 C to 1768 C (32 F to 3214
º º º
N: -260 C to 1300 C (-436 F to 2372
mV: -55 to +55mV
J : +/-1ºC from 0ºC to 60ºC
K: +/-1ºC from 0ºC to 60ºC
T: +/-1ºC from 0ºC to 60ºC
E: +/-1ºC from 0ºC to 60ºC
R: +/-2ºC from 0ºC to 60ºC*
S: +/-2ºC from 0ºC to 60ºC*
N: +/-1ºC from 0ºC to 60ºC
mV: +/-0.5% full scale or +/- 500µV
* reduced accuracy for measurements below 500ºC
Less than 1 second
4.4MΩ DC, >10kΩ @ 60Hz
±1ºC, ±2ºF for all Thermocouple Types
Degrees C or Degrees F selectable
16 bits (15 bits plus sign)
0-32000(temp)
-32000 to +32000(mV)
ºC or ºF x 10 (temp)
-10000 to +10000 (mV)
>110db @ 60Hz
>60db @ 60Hz, >50db @ 50 Hz
1.25 watts
IEC 1000-4-2 Level 4
Channel to Channel 200V±
Channel to Backplane 1500VDC
0ºC to 60ºC (32ºF to 140ºF)
UL, ULC, UL Class 1, Div 2, CE
223.84mm x 109.86mm x 34.93mm, 0.45k
-40ºC to 85ºC (-40ºF to 185ºF)
5% to 95% (non-condensing)
8WX/8WY
80mS
º
F)
º
F)
º
F)
º
F)
º
F)
º
F)
º
F)
g
29
