*Note: S, T, E also require a jumper selection change from

Figure 5 2500C-8-TC Classic Plus Configuration Options

1.5 Input Signal Ranges

Thermocouple Measurement Ranges

Figure 6 2500C-8-TC Thermocouple Measurement Ranges

1.6 Measurement Resolution

The module has a resolution of approximately 0.1
The chart below shows the corresponding input resolution per step for each of the input
configuration modes:
2500C-8-TC Installation and Operation Guide
Thermocouple
J, K, N, R
S*, T*, E*
the shipped jumper configuration per channel.
mVolt
0-55mV
J: -210ºC to 760ºC (-350ºF to 1400ºF)
K: -270ºC to 1372ºC (-450ºF to 2500ºF)
T: -270ºC to 400ºC (-454ºF to 752ºF)
E: -270ºC to 1000ºC (-454ºF to 1832ºF)
R: 0ºC to 1768ºC (32ºF to 3214ºF)
S: 0ºC to 1768ºC (32ºF to 3214ºF)
N: -260ºC to 1300ºC (-436ºF to 2372ºF)
mV: -55 to +55mV
o o
C, 0.1 F or exactly .01 millivolts.
