Dacor Epicure ER36D Planning Manual

Document # PG05 - 004
Product tolerances: +/- 1/16" (+/- 1.6 mm) unless otherwise stated
48" (1219 mm)
(40 mm)
1 1/16" (27 mm) to cooking
surface (top of grates) from
top of trim
Width: ER36D - 35 7/8" (911 mm)
ER48D - 47 7/8" (1216 mm)
GAS - ELECTRICAL ACCESS DIMENSIONS
Model A
5 5/8"
ER36D
(142.9 mm)
3 13/16"
ER48D
(96.8 mm)
* The diameter on models equipped for use in Canada is ¼" (6.4mm) larger than
those stated. Canadian units come from the factory pre-wired with an appliance
cord. When installing an appliance cord on models that are not pre-wired, the hole
size must be increased to 1 1/8" (1 3/8" for model ER48D) by removing the conduit
bracket inside the range electrical access box.
Specifications subject to change without notice.
Install all appliances according to accompanying installation instructions.
ER36D, ER48D
Epicure
Front of open door
30 3/4" (781 mm) Front of handle
29 3/8" (746 mm)
Front edge of bull nose
28 1/4" (718 mm)
Front panel
26 1/8" (664 mm)
Rear of front panel/oven door
(229 mm)
(51 mm)
(483 mm)
(387 mm)
(229 mm)
(940 mm)
Finished side
panel
(908 mm)
B C
18 3/8" 10 3/4" 13 11/16"
(466.7 mm) (273.0 mm) (347.7 mm)
18 11/16" 9 3/8"
(474.7 mm) (238.1 mm) (349.3 mm)
Ranges
®
• Observe all governing codes and ordinances during planning
and installation. Contact your local building department for
further information.
• This appliance must be installed in accordance with the
accompanying installation instructions.
24" (610 mm)
**
Range Model
**
ER36D
(76 mm)
**
ER48D
* 4-wire, two 120 Vac hot (L1 and L2), one neutral, one ground
Gas Type
** Optional
Natural Gas
Propane (LP)
* Maximum gas supply pressure 1/2 p.s.i. for all models
D E*
7/8"
(22.2 mm)
13 3/4" 1 1/8"
(28.6 mm)
www.Dacor.com
PLANNING
wARNING
ELECTRIC CIRCUIT REQUIREMENTS
Circuit Required
240 Vac, 4-wire* 60 Hz, 30
Amp. (Min.) 40 Amp. (Recom-
mended)
240 Vac, 4-wire* 60 Hz, 50
Amp.
GAS SUPPLY PRESSURE REQUIREMENTS*
Manifold Pressure
5" Water Column
10" Water Column
Gas regulator access,
cover removed
Range electrical access,
cover removed
Inlet
Back of range
B
D
A
E Electrical connection
hole in bottom
C
Phone: (800) 793-0093
Revised 02/04/10 Page 1/2
GUIDE
Total Connected Load
6.5 kW (28 Amp.)
10.0 kW (42 Amp.)
Minimum Gas Supply
Pressure
6" Water Column
11" Water Column
