Installing the Device
2.2 Mounting the Device
IMPORTANT
If any item is missing or damaged, contact Siemens for assistance.
2.2

Mounting the Device

The RUGGEDCOM M969 is designed to be mounted on a panel by affixing the top
and bottom flanges of the device to a panel using screws.
IMPORTANT
Heat generated by the device is channeled outwards from the enclosure. As such, it
is recommended that 2.5 cm (1 in) of space be maintained on all open sides of the
device to allow for some convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a
reduction of ambient temperature and improve the long-term reliability of all
equipment mounted in the rack space.
Note
For detailed dimensions of the device with panel mount hardware installed, refer to
"Dimension Drawings (Page
10
25)".
RUGGEDCOM M969
Installation Manual, 01/2021, C79000-G8976-1039-03
