After Installation

2. To complete commissioning, refer to the Installer's Guide on the pages after this
installation manual.
3. Once commissioning is complete, the Host will receive an invitation from
EVCharge.Online to set up their Back Office and to take part in a walkthrough of
the system.
4. Engage with the customer to install the EVCharge.Online application to their
smartphone or similar device from either the AppStore for Apple devices or from
Google Play for Android devices.
The application is also accessible on a PC or Mac via a web browser.
https://evcharge.online/
After Installation
Make sure this manual is given to the Host.

LED Lamp

The pedestal incorporates an area illumination lamp at its top which activates in response
to changing light levels.
1. Cover the light sensor, located on the side of the pedestal, the lamp should
illuminate.
2. Uncover the light sensor and the lamp should switch OFF.
NOTE: To prevent flickering in frequently changing light conditions such as headlights or
shade from passing vehicles, the lamp has a built-in delay before it switches on / off.

Operation

NOTE: At the end of a charging session, always disconnect the cable from the vehicle
before disconnecting from the charger.

Charger Status LED Indications

No Power to Charger
Charger Available
Authorised to Charge

About RFID Cards/Fobs

This EV charger is fitted with an RFID sensor which will allow charging to take place when
activated via an RFID card/fob. All units support RFID but the feature can be restricted by
the Host. If this option has been selected, it can act as an alternative to the online EV
Driver Application. However, both systems can be used simultaneously to suit your
individual requirements.
RFID cards/fobs are supplied with a degree of pre-configuration ready to be registered to
an individual user/group or to a specific vehicle. To add a card/fob to the
Quantum:EV OpenCharge
Page 18 of 21
Charging
Vehicle paused Charging
Fault
EVQROCM-01-V01-R0 Installation and Operation Manual
RFID Recognition
September 2020
