Installation
For 'Office for Low Emission Vehicles' (OLEV) WCS grant funded installations, make sure
Before Installation
IMPORTANT: OLEV Installations
installation with OLEV.
to collect all information/photographs required to register the product and the
NOTE: Units using GPRS contain a roaming SIM card which will always connect to the
back office require a suitable GPRS signal of 14 CSQ or better.
1. Quantum:EV OpenCharge units using GPRS to communicate with the cloud-based
Rolec cannot be held responsible or accountable in the event a GPRS unit is
verified by the end user/installer prior to installation.
strongest signal available. It is assumed that a suitable GPRS signal has already been
installed in a location without adequate network signal.
2. Establish a suitable site location for the unit that is both secure and environmentally
safe.
5. If required, make sure a functioning ethernet cable is present.
4. Make sure there is a suitable mains power supply available at the installation site.
3. Make sure the location meets current legislation (if applicable).
NOTE: Items damaged in transit must first be reported to the courier and then to the
6. Make sure that the unit and any accessories have not been damaged in transit.
provided.
Where possible, photographic evidence of package and/or unit damage should be
supplier.
discuss rectification.
NOTE: Incorrect or damaged units must NOT be installed. Contact your supplier to
7. Make sure the unit model is correct and matches the order.
EVQROCM-01-V01-R0 Installation and Operation Manual
September 2020
Quantum:EV OpenCharge
Page 15 of 21
Before Installation
IMPORTANT: OLEV Installations
For 'Office for Low Emission Vehicles' (OLEV) WCS grant funded installations, make sure
to collect all information/photographs required to register the product and the
installation with OLEV.
1. Quantum:EV OpenCharge units using GPRS to communicate with the cloud-based
back office require a suitable GPRS signal of 14 CSQ or better.
NOTE: Units using GPRS contain a roaming SIM card which will always connect to the
strongest signal available. It is assumed that a suitable GPRS signal has already been
verified by the end user/installer prior to installation.
Rolec cannot be held responsible or accountable in the event a GPRS unit is
installed in a location without adequate network signal.
2. Establish a suitable site location for the unit that is both secure and environmentally
safe.
3. Make sure the location meets current legislation (if applicable).
4. Make sure there is a suitable mains power supply available at the installation site.
5. If required, make sure a functioning ethernet cable is present.
6. Make sure that the unit and any accessories have not been damaged in transit.
NOTE: Items damaged in transit must first be reported to the courier and then to the
supplier.
Where possible, photographic evidence of package and/or unit damage should be
provided.
7. Make sure the unit model is correct and matches the order.
NOTE: Incorrect or damaged units must NOT be installed. Contact your supplier to
discuss rectification.
EVQROCM-01-V01-R0 Installation and Operation Manual
September 2020
Installation
Quantum:EV OpenCharge
Page 15 of 21
