IAI EYECYLINDER EC-B6 Series Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ELECYLINDER
Instruction Manual
EC-B6□/B7□
First Edition
ME3798-1C
Specifications
ch.
Installation
ch.
Wiring
ch.
Operation
ch.
Preventive/
ch.
Predictive Maintenance
Parameters
ch.
Troubleshooting
ch.
Maintenance and
ch.
Inspection
External Dimensions
ch.
Life
ch.
Warranty
ch.
Appendix
ch.
1
2
3
4
5
6
7
8
9
1 0
1 1
1 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EYECYLINDER EC-B6 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IAI EYECYLINDER EC-B6 Series

Summary of Contents for IAI EYECYLINDER EC-B6 Series

  • Page 1 ELECYLINDER EC-B6□/B7□ Instruction Manual First Edition ME3798-1C Specifications Installation Wiring Operation Preventive/ Predictive Maintenance Parameters Troubleshooting Maintenance and Inspection External Dimensions Life Warranty Appendix...
  • Page 3 • This instruction manual is an original document dedicated for this product. • This product cannot be used in ways not shown in this instruction manual. IAI shall not be liable for any result whatsoever arising from the use of the product in any other way than what is noted in the manual.
  • Page 4 ELECYLINDER Instruction Manual Configuration Control Product name Instruction manual name number ELECYLINDER Quick Start Guide ME3765 Instruction Manual ELECYLINDER ME3798 (this document) RCM-101-MW/RCM-101-USB PC Compatible Software for RC/EC ME0155 Instruction Manual Touch Panel Teaching Pendant TB-02/02D Instruction Manual ME0355 TB-03 Instruction Manual Touch Panel Teaching Pendant ME0375 Wireless communication...

  • Page 5: Table Of Contents

    Contents Safety Guide ······························································································· Intro-1 Precautions for Handling ··············································································· Intro-9 International Standard Compliance ································································ Intro-11 Precautions for Handling Wireless Operation ··················································· Intro-12 Precaution for Axis Operation with Wireless Connection ···································· Intro-14 Part Names ······························································································ Intro-15 Chapter 1 Specifications Checking the product ······························································ 1-1 Components ································································································...
  • Page 6 Chapter 3 Wiring System configuration ······························································· 3-1 Electrical specifications ···························································· 3-2 Specifications table ······················································································· 3-2 I/O specifications ·························································································· 3-3 Brake release method ···················································································· 3-4 Frame grounding ·························································································· 3-5 Connection arrangement diagram ·············································· 3-6 Wiring connections (for connectors) ············································ 3-8 24VDC power supply wiring ············································································ 3-8 PLC wiring ·································································································...
  • Page 7 Chapter 5 Preventive/Predictive Maintenance Preventive/predictive maintenance ············································· 5-1 Maintenance information ·························································· 5-2 Total travel count ·························································································· 5-2 Total travel distance ······················································································ 5-2 Overload warning level ·················································································· 5-3 Setting maintenance information ················································ 5-4 Switching to maintenance information window ···················································· 5-4 Basic operation ···························································································· 5-5 Chapter 6 Parameters Precautions regarding parameters ·············································...
  • Page 8 Chapter 8 Maintenance and Inspection Precautions for maintenance and inspection work ························· 8-1 Inspection items and schedule ·················································· 8-3 Belt type (EC-B□S□) ······················································································ 8-3 Grease supply timing ····················································································· 8-3 Visual inspection items ···························································· 8-4 External visual inspection ··············································································· 8-4 Internal visual inspection ················································································ 8-5 Cleaning ···············································································...
  • Page 9 Chapter 11 Warranty 11.1 Warranty period ··································································· 11-1 11.2 Scope of the warranty ··························································· 11-1 11.3 Honoring the warranty ··························································· 11-1 11.4 Limited liability ····································································· 11-2 11.5 Conformance with applicable standards/regulations, etc., and application conditions ······················································ 11-2 11.6 Other items excluded from warranty ········································· 11-2 Chapter 12 Appendix 12.1 Index ···············································································...

  • Page 11: Safety Guide

    Safety Guide Safety Guide The Safety Guide is intended to permit safe use of the product and thus to prevent risks and property damage. Be sure to read it before handling the product. Intro-1...
  • Page 12 Safety Guide Safety Precautions for Our Products Common safety precautions for the use of robots in various operations are indicated here. Operation Precautions Model ● This product is not intended or designed for applications where high levels of Selection safety are required, and so cannot guarantee that human lives will be protected.
  • Page 13 Safety Guide Operation Precautions Transportation ● When transporting heavy objects, do the work with two or more persons or utilize equipment such as a crane. ● When working with two or more persons, make it clear who is to be in charge and communicate well with each other to ensure safety.
  • Page 14 (4) Locations where the product may come in contact with water, oil or chemical spray (2) Cable wiring ● Use IAI genuine cables for connecting the actuator and controller, and for the teaching tools. ● Do not scratch cables, bend them forcibly, pull them, coil them, snag them, or place heavy objects on them.
  • Page 15 Safety Guide Operation Precautions Installation (4) Safety measures ● When working with two or more persons, make it clear who is to be in charge Startup and communicate well with each other to ensure safety. ● When the product is operating or in the ready mode, take safety measures (such as the installation of safety/protection fences) so that nobody can enter the area within the robot's movable range.
  • Page 16 Safety Guide Operation Precautions Trial Operation ● When working with two or more persons, make it clear who is to be in charge and communicate well with each other to ensure safety. ● After teaching or programming, carry out trial operation step by step before switching to automatic operation.
  • Page 17 Safety Guide Operation Precautions Maintenance ● When releasing the brake on a vertically oriented actuator, be careful that it does not fall under its own weight, catching the operator's hand or damaging Inspection workpieces. ● The slider or rod may be misaligned from the stop position if the servo is turned OFF.
  • Page 18 Safety Guide Precaution Indications The safety precautions are divided into "Danger", "Warning", "Caution" and "Notice" according to the warning level, as follows, and described in the Instruction Manual for each model. Level Degree of risk to persons and property Symbol This indicates an imminently hazardous situation which, if the product Danger Danger...

  • Page 19: Precautions For Handling

    Precautions for Handling Precautions for Handling 1. The Safety Guide attached with the product is intended to permit safe use of the product and thus to prevent risks and property damage. Be sure to read it before handling the product. 2.
  • Page 20 Precautions for Handling 5. If return operations are continued over a short distance, they may rapidly degrade the film of grease. Continuous return operation within a distance less than 30mm may cause the grease film to degrade rapidly. As a guideline, in every 5,000 to 10,000 cycles, have approximately 5 cycles of return operation over a 50mm distance or more to regenerate the oil film.

  • Page 21: International Standard Compliance

    To be checked in EC Declaration of Conformity. EC Declaration of Conformity proving conformity to RE Directive may be modified without notice according to addition of conformed models, specification change and so on. Visit our homepage (http:/www.iai-robot/) or contact our sales site if necessary.

  • Page 22: Precautions For Handling Wireless Operation

    Precautions for Handling Wireless Operation Precautions for Handling Wireless Operation When the option for wireless communication support (model: WL, WL2) is selected, a wireless communication circuit board is built into the ELECYLINDER. Certificates and self-declarations regarding the wireless function are handled under the model name below for the wireless circuit board.
  • Page 23 • For details of the applicable standards, please refer to above mentioned international standards compliances. • Import Corporation Name : IAI Industrieroboter GmbH * The product can be used in any country which is a member of EU. 【中国／CHINA 】...
  • Page 24 - ช ื � อ โมเดล : IABL3826 - ประเทศผู ้ผลิ ต : ญี � ป ุ่ น (Made in Japan) - ผู ้นํ า เข ้า : IAI Robot (Thailand) Co., Ltd. Número de Certificación 【México / Mexico】 Nombre de la Empresa Solicitante ：IAI Corporation...

  • Page 25: Precaution For Axis Operation With Wireless Connection

    Precautions for Axis Operation with Wireless Connection Precautions for Axis Operation with Wireless Connection Touch Panel Teaching Pendant TB-03 (V2.30 or later) can operate the option model code -WL2 ELECYLINDER with wireless connection. For operation with wireless connection, secure safety by following the precautions below before use.

  • Page 26: Part Names

    Part Names Part Names The figure below shows EC-B6□/B7□. For models with their code comes with U, the motor unit is mounted facing the lower side. In this manual, the right and left sides of the actuator are expressed in the way it is placed horizontally as shown in the figure below, and is looked at from the motor side.
  • Page 27 Part Names Motor (built in controller) Status indicator LED Teaching port Power I/O connector [Teaching port] This connector is for the connection of a teaching pendant or PC software. When connecting, remove the cap. [Status indicator LED] The LED on the right side as seen from the motor side shows the servo ON/OFF status and alarm status, and the LED on the left side as seen from the motor side displays the wireless status.
  • Page 28 Intro-18...
  • Page 29 ELECYLINDER Chapter Specifications Checking the product ··············································· 1-1 Components ··········································································· 1-1 How to read the model nameplate ··············································· 1-2 How to read the model number ··················································· 1-3 Product list ············································································· 1-4 Mechanical specifications ·········································· 1-5 Belt type ················································································ 1-5 Duty ratio ············································································· 1-15 Options ·······························································...

  • Page 31: Checking The Product

    The following table shows the product configuration for the standard specification. See the packing list for the details of the enclosed components. In the unlikely case that any model number errors or missing parts come to light, contact your local IAI distributor. Body...

  • Page 32: How To Read The Model Nameplate

    1.1 Checking the product How to read the model nameplate EC-B******* Model number → Serial number → [Nameplate position]...

  • Page 33: How To Read The Model Number

    1.1 Checking the product How to read the model number [Belt type] Series Type Lead Stroke Power / I/O cable length Options Motor Joint System Incremental encoder specification, Belt 63 mm width 48 mm or equiv. 300 to 2600 mm Blank NPN specification, no option (per 100 mm)

  • Page 34: Product List

    1.1 Checking the product Product list [Belt type] Positioning MAX. payload (kg) Body width Lead Stroke Max. speed Type External view repeatability (mm) (mm) (mm) (mm/s) Horizontal (mm) 300 to 2600 1500 ±0.08 or equiv. (per 100st) 63mm 300 to 2600 ±0.08 1600 or equiv.

  • Page 35: Mechanical Specifications

    1.2 Mechanical specifications 1.2 Mechanical specifications Belt type [1] EC-B6 [Lead and Payload (Energy-Saving: Disabled)] Maximum payload Lead Model number (mm) Horizontal (kg) 48 or EC-B6S□ -① -② （-③） equiv. Legend ①Stroke ②Cable length ③Option Stroke and Max. Speed (Energy-Saving: Disabled)] Lead 900 to 2600...
  • Page 36 1.2 Mechanical specifications [Payload by Speed (Energy-Saving: Disabled)] At low load capacity, the acceleration/deceleration can be increased. The maximum acceleration/deceleration is 1.0G. For % input, 1.0G is set as 100%. Lead 48 or equiv. Orientation Horizontal Acceleration (G) Speed (mm/s) 1000 1200 1400...
  • Page 37 1.2 Mechanical specifications [Lead and Payload (Energy-Saving: Enabled)] Maximum payload Lead Model number (mm) Horizontal (kg) 48 or EC-B6S□ -① -② （-③） equiv. Legend ①Stroke ②Cable length ③Option Stroke and Max. Speed (Energy-Saving: Enabled)] Lead 800 to 2600 (mm) (mm) (mm) (mm) (mm)
  • Page 38 1.2 Mechanical specifications [Payload by Speed (Energy-Saving: Enabled)] At low load capacity, the acceleration/deceleration can be increased. The maximum acceleration/deceleration is 0.7G. For % input, 1.0G is set as 100%. Lead 48 or equiv. Orientation Horizontal Acceleration (G) Speed (mm/s) 1400 Caution Do not attempt to configure settings for acceleration/deceleration above the allowable...
  • Page 39 1.2 Mechanical specifications Belt type overhang load length (L = 220mm or less) Ma direction Mb/Mc direction Ma and Mb Direction Moment Offset Datum Position Datum Position Caution If the actuator is used with excessive allowable moment and overhang load, it may not only lead to abnormal noise and vibration but also significantly reduce the life of the ELECYLINDER.
  • Page 40 1.2 Mechanical specifications [2] EC-B7 [Lead and Payload (Energy-Saving: Disabled)] Maximum payload Lead Model number (mm) Horizontal (kg) 48 or EC-B7S□ -① -② （-③） equiv. Legend ①Stroke ②Cable length ③Option Stroke and Max. Speed (Energy-Saving: Disabled)] Lead 1000 to 2600 (mm) (mm) (mm)
  • Page 41 1.2 Mechanical specifications [Payload by Speed (Energy-Saving: Disabled)] At low load capacity, the acceleration/deceleration can be increased. The maximum acceleration/deceleration is 1.0G. For % input, 1.0G is set as 100%. Lead 48 or equiv. Orientation Horizontal Acceleration (G) Speed (mm/s) 1000 1400 1600...
  • Page 42 1.2 Mechanical specifications [Lead and Payload (Energy-Saving: Enabled)] Maximum payload Lead Model number (mm) Horizontal (kg) 48 or EC-B7S□ -① -② （-③） equiv. Legend ①Stroke ②Cable length ③Option Stroke and Max. Speed (Energy-Saving: Enabled)] Lead 600 to 2600 (mm) (mm) (mm) (mm) (Every 100mm)
  • Page 43 1.2 Mechanical specifications [Payload by Speed (Energy-Saving: Enabled)] At low load capacity, the acceleration/deceleration can be increased. The maximum acceleration/deceleration is 0.7G. For % input, 1.0G is set as 100%. Lead 48 or equiv. Orientation Horizontal Acceleration (G) Speed (mm/s) 1200 Caution Do not attempt to configure settings for acceleration/deceleration above the allowable...
  • Page 44 1.2 Mechanical specifications Belt type overhang load length (L = 280mm or less) Ma direction Mb/Mc direction Ma and Mb Direction Moment Offset Datum Position Datum Position Caution If the actuator is used with excessive allowable moment and overhang load, it may not only lead to abnormal noise and vibration but also significantly reduce the life of the ELECYLINDER.

  • Page 45: Duty Ratio

    1.2 Mechanical specifications Duty ratio The duty ratio is the operating rate, shown in %, of the actuator operating time within one cycle. Continuous operation is possible when the duty ratio is 100%. 1-15...

  • Page 46: Options

    1.3 Options 1.3 Options With brake (Model: B) This is used to prevent the slider from moving during power outages or when the servo is OFF. Indicated grease applied type: Food machinery grade grease (white alcom grease) (Model: G5) Grease applied on the linear guide on the ELECYLINDER can be changed to food machinery grade grease (White Alcom Grease).

  • Page 47: Wireless Axis Operation Specification (Model: Wl2)

    1.3 Options Wireless axis operation specification (Model: WL2) The wireless axis operation specification includes a built-in wireless circuit board enabling wireless communication between the ELECYLINDER and the Touch Panel Teaching Pendant. Specifying WL2 enables operation testing of axis operation (movement to forward and backward ends, jog operation, inching operation) as well as the operation via wireless communication enabled with WL.

  • Page 48: Accessories

    1.4 Accessories 1.4 Accessories Power I/O cable Supplied when length (value other than 0) is specified in the model number cable length. (Note1) LS0/PE0 LS1/PS1 ＊ALM Note1 TMD2 is 24V (control) ● The wiring on the opposite side of the connector has not been processed. ●...

  • Page 49: Power I/O Connector

    1.4 Accessories Power I/O connector Supplied when cable length is specified as "0" in the model number. Name Model number Quantity 1-1871940-6 Power I/O connector 1 pc (Tyco Electronics) 1-19...
  • Page 50 1-20...

  • Page 51: Installation

    ELECYLINDER Chapter Installation Precautions for transportation ···································· 2-1 Installation and storage/preservation environment ·········· 2-2 Installation environment ···························································· 2-2 Storage/preservation environment··············································· 2-3 Installation of belt type ·············································· 2-4 Installation surface ··································································· 2-4 Mounting orientation ································································· 2-5 Precautions regarding stainless steel sheet ·································· 2-6 Fixing bolt ··············································································...

  • Page 53: Precautions For Transportation

    2.1 Precautions for transportation 2.1 Precautions for transportation [Handling the package] ● Do not damage or drop the package. The package is not specially designed to withstand dropping or shock due to collision. ● Do not have a single operator to carry a heavy package. Use an appropriate method for transportation.

  • Page 54: Installation And Storage/Preservation Environment

    2.2 Installation and storage/preservation environment 2.2 Installation and storage/preservation environment Usage is possible in environments of pollution degree 2 or equivalent. Pollution degree 2: Environment in which generally only nonconductive pollution occurs, but temporary conductive pollution may occur due to condensation (IEC 60664-1) Installation environment Avoid the following locations for installation.

  • Page 55: Storage/Preservation Environment

    2.2 Installation and storage/preservation environment Storage/preservation environment ● For the storage and preservation environment, see the installation environment. However, give especial consideration to the prevention of condensation during long-term storage/preservation. ● Unless especially specified, desiccant is not included in the package at shipping. If the product is to be stored/preserved in an environment where condensation is anticipated, take condensation preventive measures.

  • Page 56: Installation Of Belt Type

    2.3 Installation of belt type 2.3 Installation of belt type Installation surface ● The body mounting surface should be a machined surface or a plane with similar accuracy, with flatness within 0.05mm/m. ● The mounting frame should have a structure rigid enough to prevent the generation of vibration.

  • Page 57: Mounting Orientation

    2.3 Installation of belt type Mounting orientation Type: EC-B6/B7 Horizontal installation Vertical installation Horizontal lateral installation Horizontal ceiling mount installation...

  • Page 58: Precautions Regarding Stainless Steel Sheet

    2.3 Installation of belt type Precautions regarding stainless steel sheet ● During installation and transport, do not grasp or press on the stainless steel sheet. Otherwise, this may lead to stainless steel sheet damage. ● There may be a case that slackness or misalignment occurs on the stainless steel sheet. Installation in horizontally oriented wall mount and in ceiling mount especially could cause slackness or misalignment on the stainless steel sheet.

  • Page 59: Body Mounting

    2.3 Installation of belt type Body mounting This actuator is equipped with through holes for installation so it can be held from the top. → For details regarding the position and dimensions, refer to "Chapter 9 External Dimensions". There are a reamed hole and an oblong hole for the positioning pins. Use the reamed hole and oblong hole if mounting reproducibility after detachment is required.
  • Page 60 2.3 Installation of belt type ◎ Caution for Installation of Main Unit ● Basically, all of the through holes should be used in order to hold on the whole area. ● In case that the accuracy in drive is not required, it is available to make foot brackets to hold the unit.

  • Page 61: Mounting Transported Objects

    2.3 Installation of belt type Mounting transported objects ● Use the tapped mounting holes on the top surface of the slider to fix transported objects. ● There are 2 reamed holes on the top surface of the slider. Use these reamed holes if repeated attaching and detaching is required. ●...
  • Page 62 2.3 Installation of belt type [Distance between slider center and motor cover at mechanical end: A] For upper motor type, the motor part (motor cover) overhangs from the slider top. Pay attention to the transferred work piece so it would not interfere with the motor. Model A (mm) 78.7...

  • Page 63: Wiring

    ELECYLINDER Chapter Wiring System configuration ················································ 3-1 Electrical specifications ············································· 3-2 Specifications table ·································································· 3-2 I/O specifications ····································································· 3-3 Brake release method ······························································ 3-4 Frame grounding ····································································· 3-5 Connection arrangement diagram ······························· 3-6 Wiring connections (for connectors) ····························· 3-8 24VDC power supply wiring ······················································· 3-8 PLC wiring ···········································································...

  • Page 65: System Configuration

    3.1 System configuration 3.1 System configuration The following shows the system configuration. <Model: PSA-24> Supply 24VDC to the ELECYLINDER and input a signal from a master device to the ELECYLINDER. This enables the ELECYLINDER to operate. This manual introduces an example using a PLC connected as the master device.
  • Page 66 3.2 Electrical specifications 3.2 Electrical specifications Specifications table Item Content Number of controlled axes 1 axis Power supply voltage 24VDC ±10% Energy-Saving: Disabled Rated 3.5A, max. 4.2A Power capacity Energy-Saving: Enabled Max. 2.2A Brake release power supply 24VDC ±10%, 200mA (only for external brake release) Generated heat Inrush current (Note 1)

  • Page 67: Electrical Specifications

    3.2 Electrical specifications I/O specifications Input part Output part Input voltage 24VDC ±10% Load voltage 24VDC ±10% Max. load Input current 5mA per circuit 50mA per point current Specs ON/OFF ON voltage MIN 18VDC Residual voltage 2V or less voltage OFF voltage MAX 6VDC Leakage Leakage current MAX 0.1mA per point...

  • Page 68: Brake Release Method

    3.2 Electrical specifications Brake release method (for specifications with brakes) Refer to the following method to release the brake. Brake release method Input 24V to the brake release (signal abbreviation: BKRLS) terminal. → Refer to "3.3 Connection arrangement diagram" and "3.4/3.5 Wiring connections". Operate the teaching pendant to force the brake to release.

  • Page 69: Frame Grounding

    3.2 Electrical specifications Frame grounding The ELECYLINDER has a built-in controller circuit board. The controller frame grounding line is connected to the ELECYLINDER body and through to ground via the ELECYLINDER mounting surface. If not grounding through the mounting surface, there are fixing screws (2 locations) under the end cover, of which either one can be used for the ground wire connection.

  • Page 70: Connection Arrangement Diagram

    3.3 Connection arrangement diagram 3.3 Connection arrangement diagram Here the wiring connection method with a power I/O connector is introduced. [For NPN specification] 24VDC ELECYLINDER (NPN specification) Power I/O connector 24V power supply Ground Note 1 Brake release BKRLS Backward complete Backward Forward complete Forward...
  • Page 71 3.3 Connection arrangement diagram 2-Circuit Power Supply Specification TMD2 (Option) [For NPN specification] 24VDC ELECYLINDER ( NPN specification Power I/O connector 24V power supply Ground (Driving Source) Note 1 Brake release BKRLS 24V power supply (Control) Backward complete Backward Forward complete Forward *ALM Alarm...

  • Page 72: Wiring Connections (For Connectors)

    3.4 Wiring connections (for connectors) 3.4 Wiring connections (for connectors) Here the wiring connection method with a power I/O connector is introduced. 24VDC power supply wiring Connect the power wiring to the power I/O connector. Connect the wiring to the connector terminal block while referring to the connection diagram.
  • Page 73 3.4 Wiring connections (for connectors) 2-Circuit power supply specification TMD2 (Option) Connect the power wiring to the power I/O connector. Connect the wiring to the connector terminal block while referring to the connection diagram. Connect the [B1] connector terminal and the +24V (Driving Source) terminal of the 24VDC power supply.

  • Page 74: Plc Wiring

    3.4 Wiring connections (for connectors) PLC wiring For I/O between the PLC and signals, the signal wiring must be connected to the connector terminal block. Connect the wiring to the connector terminal block while referring to the connection diagram. Connect the [B3] connector terminal and the [Backward] output terminal. Connect the [B4] connector terminal and the [Forward] output terminal.

  • Page 75: Connector Wiring Method

    3.4 Wiring connections (for connectors) Connector wiring method The name of each terminal is affixed to the power I/O connector. The connector nameplate name and pin number relationship is as below. Wiring inlet Wiring inlet Tool insertion slot Reference Precision screwdriver Power I/O connector internal structure looks like this.
  • Page 76 3.4 Wiring connections (for connectors) Wiring mounting method Recommended precision screwdriver 7mm of insulation should be stripped from the wire end. Item Specifications Slightly twist the core wire. (1) Shaft 1.6 ±0.03mm diameter (2) Blade Insert the recommended 0.2 ±0.1mm thickness precision screwdriver (3) Tip angle...

  • Page 77: Brake Release Wiring

    3.4 Wiring connections (for connectors) 3.5 Wiring connections (for cables) Brake release wiring For the specification with brake, when installing a forcible brake release switch, connect wiring to the [B2] connector terminal. Power capacity of 24VDC ±10%/200mA or higher is required. Connector Signal Compatible...

  • Page 78: Power I/O Cable Connection

    3.5 Wiring connections (for cables) ● The wiring on the opposite side of the connector has not been processed. ● The cable length is available from 1m to 10m. Specify the length in increments of 1m. ● The following shows a sample model number. Cable length 1m →...

  • Page 79: 24Vdc Power Supply Wiring

    3.5 Wiring connections (for cables) 24VDC power supply wiring Connect the power wiring to the power I/O cable. Connect the 24VDC power supply to the terminal block after terminal-processing the 24V and 0V wires of the power I/O cable. Connect the 24V wire (insulation color: red) to the +24V terminal of the 24VDC power supply.
  • Page 80 3.5 Wiring connections (for cables) 2-Circuit power supply specification TMD2 (Option) Connect the power wiring to the power I/O cable. Connect the 24VDC power supply to the terminal block after terminal-processing the 24V (Driving Source), 24V (Control) and 0V wires of the power I/O cable. Connect the 24V (Driving Source) wire (insulation color: red) to the +24V terminal of the 24VDC power supply.

  • Page 81: Plc Wiring

    3.5 Wiring connections (for cables) PLC wiring For I/O between the PLC and signals, the wiring of the power I/O cable must be connected to the PLC. Connect the wiring to the PLC terminal block while referring to the connection diagram. Connect the [orange] cable wire and the [Backward] output terminal.

  • Page 82: Brake Release Wiring

    3.5 Wiring connections (for cables) Brake release wiring For the specification with brake, when installing a forcible brake release switch, connect the [brown] cable wire. Power capacity of 24VDC ±10%/200mA or higher is required. Wiring Signal Function overview Required specifications color abbreviation Brown...
  • Page 83 ELECYLINDER Chapter Operation Basic operation ······················································· 4-1 Teaching tool connections and testing operation ············ 4-2 Teaching pendant connection ····················································· 4-2 ELECYLINDER test operation ···················································· 4-3 Stop position/operating conditions (AVD) setting/adjustment ··················································· 4-4 Stop position setting/adjustment ················································· 4-5 Operating conditions (AVD) setting/adjustment ······························ 4-6 I/O signals ·····························································...

  • Page 85: Basic Operation

    4.1 Basic operation 4.1 Basic operation An input signal from a master device to the ELECYLINDER triggers operation of the ELECYLINDER. The ELECYLINDER status can also be determined when the master device receives signal output from the ELECYLINDER. Control is just as simple as when using a solenoid valve (SOL valve) and air cylinder drive. This manual introduces an example using a PLC connected as the master device.

  • Page 86: Teaching Tool Connections And Testing Operation

    4.2 Teaching tool connections and testing operation 4.2 Teaching tool connections and testing operation A teaching pendant or PC software can be used to test operation or configure data settings. This manual introduces operating methods using a teaching pendant TB-02. Reference PC software operating method PC software manual (ME0155)

  • Page 87: Elecylinder Test Operation

    4.2 Teaching tool connections and testing operation ELECYLINDER test operation Touch [Simple Data Setting]. Action The screen will switch to the Simple Data Setting window. If the position edit password is set to a value other than "0000", the password input screen will be displayed.

  • Page 88: Stop Position/Operating Conditions (Avd) Setting/Adjustment

    4.2 Teaching tool connections and testing operation 4.3 Stop position/operating conditions (AVD) setting/adjustment Touch the [FEnd] (forward) button or [BEnd] (backward) button. Action The ELECYLINDER will move toward the forward or backward end. Releasing the controls during operation will cause the unit to slow to a stop. 4.3 Stop position/operating conditions (AVD) setting/adjustment A: Acceleration A:Acceleration...

  • Page 89: Stop Position Setting/Adjustment

    4.3 Stop position/operating conditions (AVD) setting/adjustment Stop position setting/adjustment (forward end/backward end) Setting item Unit Explanation Backward end, Enter as the distance from the home position. forward end Entries can be made in increments of 0.01mm. Touch the position you want to configure/adjust. Action Ten Key window will open.

  • Page 90: Operating Conditions (Avd) Setting/Adjustment

    4.3 Stop position/operating conditions (AVD) setting/adjustment A:Acceleration 加速度 A: Acceleration V: Velocity V:Velocity 速度 Operating conditions (AVD) setting/adjustment D: Deceleration D:Deceleration 減速度 Setting item Unit Explanation Set the acceleration between 1 and 100%. A: Acceleration Touch the [Switch units] button to switch the units to G, allowing entries to be made in increments of 0.01G.
  • Page 91 4.3 Stop position/operating conditions (AVD) setting/adjustment Touch Acceleration, Velocity or Deceleration. Action Ten Key window will open. The current transport load set value will be displayed below the ten key pad. To configure a new setting, touch the [Change] key. Action The [Transport load setting] window will open.
  • Page 92 4.3 Stop position/operating conditions (AVD) setting/adjustment Touch the operating condition to configure/adjust. Action Ten Key window will open. After setting the numerical value, touch the [ENT] key. Then touch the [Transfer] key. Action A value will be written to the controller and the [BEnd] button and [FEnd] button will turn green.

  • Page 93: I/O Signals

    4.4 I/O signals 4.4 I/O signals I/O signal list ELECYLINDER I/O signals are as follows. Signal Category Signal name Function overview abbreviation Turning ON sends it backward. Turning OFF midway through operation will cause a gradual stop. Turning ON when home return is not complete Backward triggers home return operation.

  • Page 94: [St0] [St1] Signals: Movement Command Input

    4.4 I/O signals [ST0] [ST1] signals: Movement command input (backward/forward) The ST signal function automatically switches depending on whether the unit has completed home return or not. Function overview by status Signal Signal name abbreviation Home return: Home return: Complete Not complete Backward Backward...

  • Page 95: [Res] Signal: Alarm Clear Input

    4.4 I/O signals [RES] signal: Alarm clear input ● When the [RES] signal is turned ON, the currently triggered alarm will be cleared. ● Alarm clear may not be possible depending on the alarm itself. → For details, refer to "7.4 Troubleshooting by alarm groups". [BKRLS] input: Brake release input ●...

  • Page 96: [Ls0] [Ls1] Signals: Position Detection Output

    4.4 I/O signals [LS0] [LS1] signals: Position detection output (backward end/forward end) ● The LS signals perform the same operation as an air cylinder automatic switch. They are not positioning complete signals. ● The LS signals turn ON when the current ELECYLINDER position is within the detection range configured at the backward and forward ends.

  • Page 97: [*Alm] Signal: Alarm Output

    4.4 I/O signals [*ALM] signal: Alarm output ● Turns ON when the ELECYLINDER is in normal status. Turns OFF when an alarm occurs. ● Always monitor the *ALM signal using the master device. If it turns OFF, immediately take appropriate safety countermeasures with the equipment as a whole.

  • Page 98: Operating Method From Master Device

    4.5 Operating method from master device 4.5 Operating method from master device Home return operation/positioning operation [ST0] [LS0] [ST1] [LS1] signals Turning the [ST0] signal ON when home return is not complete will first trigger home return operation. After a momentary stop at the home position, it will then move to the backward end.
  • Page 99 4.5 Operating method from master device This shows the PLC timing chart for operating the ELECYLINDER. The basic process is as follows. Power ON Home return Move to forward end Move to backward end [Basic timing chart] ELECYLINDER → PLC → input signals to Output Input output signals to PLC...
  • Page 100 4.5 Operating method from master device Turning the ST signal OFF midway through operation will cause a gradual stop. For example, be careful of the following point with a large LS signal detection range. If the sequence is set to turn the ST signal OFF immediately after the LS signal turns ON, the ELECYLINDER may not have reached the forward/backward end.
  • Page 101 ELECYLINDER Chapter Preventive/Predictive Maintenance Preventive/predictive maintenance ······························ 5-1 Maintenance information ··········································· 5-2 Total travel count ····································································· 5-2 Total travel distance ································································· 5-2 Overload warning level ····························································· 5-3 Setting maintenance information ································· 5-4 Switching to maintenance information window ······························· 5-4 Basic operation ······································································· 5-5...

  • Page 103: Preventive/Predictive Maintenance

    5.1 Preventive/predictive maintenance 5.1 Preventive/predictive maintenance predictive maintenance function The ELECYLINDER has a that notifies the user with an "overload warning" when the load exceeds normal status. preventive maintenance function It also has a that prompts the user to perform maintenance if the travel count or the travel distance exceeds the set values.

  • Page 104: Maintenance Information

    5.2 Maintenance information 5.2 Maintenance information This section introduces three items that can be configured and managed as maintenance information. When the set values are exceeded, a "maintenance warning" is issued and the status display LEDs flash alternately in red and green. Even if a "maintenance warning"...

  • Page 105: Overload Warning Level

    5.2 Maintenance information Overload warning level Default setting Name Symbol Unit Input range at shipping Overload warning OLWL 50 to 100 level (disabled setting) ● With the motor temperature rise value which triggers an overload alarm as 100%, set the level to output an overload warning between 50 and 99%.

  • Page 106: Setting Maintenance Information

    5.3 Setting maintenance information 5.3 Setting maintenance information The maintenance information can be configured and changed using the teaching pendant or PC software. This manual introduces operating methods using a teaching pendant TB-02. Reference PC software operating method PC software manual (ME0155) Teaching pendant operating method Teaching pendant manual (ME0355) Touch panel teaching pendant operation...

  • Page 107: Basic Operation

    5.3 Setting maintenance information Basic operation To set the target value, touch the field of the relevant item. Action The set value will blink and Ten Key window will open. Enter the value with the Ten Key pad and touch the [ENT] key. Action The target value will change.
  • Page 109 ELECYLINDER Chapter Parameters Precautions regarding parameters ······························ 6-1 How to change parameters ········································ 6-2 Edit parameters window ···························································· 6-2 Basic operation ······································································· 6-3 Parameter list ························································· 6-5 Parameter function descriptions ·································· 6-6 Parameter No.1: Operation range adjustment ································ 6-6 Parameter No.2: Auto switch "LS" signal detection range adjustment ····· 6-7 Parameter No.3: Change home return direction ·····························...

  • Page 111: Precautions Regarding Parameters

    This will be required for investigating causes of failure or when the ELECYLINDER is replaced. Caution Understand the control methods in advance if making a change or performing a setting in accordance with the system and application. Contact IAI if anything is unclear.

  • Page 112: How To Change Parameters

    6.2 How to change parameters 6.2 How to change parameters A teaching pendant or PC software can be used to change parameters. This manual introduces operating methods using a teaching pendant TB-02. Reference PC software operating method PC software manual (ME0155) Teaching pendant operating method Teaching pendant manual (ME0355) Touch panel teaching pendant operation...

  • Page 113: Basic Operation

    6.2 How to change parameters Basic operation If setting parameters numerically, touch the set value button. Action The set value will blink and Ten Key window will open. Enter the value with the Ten Key pad and touch the [ENT] key. Action The parameter will be changed.
  • Page 114 6.2 How to change parameters Touch the [Yes] button. Action The controller will restart, enabling parameter changes. However, if you touch [No], the reboot will be canceled and the Edit parameters window will return. Reference Touching the explanation button displays a description of each parameter at the bottom of the screen.

  • Page 115: Parameter List

    6.3 Parameter list 6.3 Parameter list Default Reference No. Category Name Symbol Unit Input range setting Page at shipping Operation Maximum range LIMM 0 to 9999.69 stroke adjustment Auto switch "LS" signal Actuator Depended 0.10 detection to 9999.99 range adjustment Home return According to Reverse,...

  • Page 116: Parameter Function Descriptions

    6.4 Parameter function descriptions 6.4 Parameter function descriptions Parameter No.1: Operation range adjustment Default setting Category Name Symbol Unit Input range at shipping Operation range LIMM 0 to 9999.69 Maximum stroke adjustment ● The ELECYLINDER operation range can be adjusted to suit your system. ●...

  • Page 117: Parameter No.2: Auto Switch "Ls" Signal Detection Range Adjustment

    6.4 Parameter function descriptions Parameter No.2: Auto switch "LS" signal detection range adjustment Default setting No. Category Symbol Unit Input range Name at shipping Auto switch Actuator Depended "LS" signal 0.10 to 9999.99 detection ● Sets the backward complete/forward complete ON trigger range relative to the backward end/forward end.

  • Page 118: Parameter No.3: Change Home Return Direction

    6.4 Parameter function descriptions Parameter No.3: Change home return direction Default setting No. Category Symbol Unit Input range Name at shipping Home return According to Reverse, direction ELECYLINDER forward change specifications ● The home return operation direction can be selected. ●...

  • Page 119: Parameter No.4: Home Position Adjustment

    Do not set Parameter No.4 to a value smaller than the default setting at shipping. This may result in abnormal home return operation, alarm triggering or abnormal operation. If the value must be set small, please contact IAI. After changing this parameter, always perform home return reset (absolute reset).

  • Page 120: Parameter No.5: Smooth Accel/Decel Setting

    6.4 Parameter function descriptions Parameter No.5: Smooth accel/decel setting Default setting No. Category Symbol Unit Input range Name at shipping Smooth Disabled, － MOD0 Disabled accel/decel setting enabled ● The movement waveform for ELECYLINDER operation can be selected. ● When [Enabled], accel/decel operation becomes smoother (less abrupt). This softens the shocks of acceleration/deceleration without delaying the operation time.

  • Page 121: Parameter No.6: Current Control Setting At Stop

    6.4 Parameter function descriptions Parameter No.6: Current control setting at stop Default setting No. Category Symbol Unit Input range Name at shipping Disabled: Powerful stop Current control SMOD Enabled: Disabled setting at stop Energy-saving stop ● The control method for ELECYLINDER stop can be selected. ●...

  • Page 122: Parameter No.7: Wireless Function Setting

    6.4 Parameter function descriptions Parameter No.7: Wireless function setting Default setting No. Category Symbol Unit Input range Name at shipping Wireless Disabled, RWOF Enabled function setting Enabled ● Either Enabled or Disabled can be selected for the ELECYLINDER wireless function. ●...

  • Page 123: Parameter No.8: Power-Saving Setting

    6.4 Parameter function descriptions Parameter No.8: Power-saving setting Default setting No. Category Symbol Unit Input range Name at shipping Power-saving Disabled, BUEN Disabled setting enabled ● Either Enabled or Disabled can be selected for the ELECYLINDER power-saving setting. ● When "Enabled," the power capacity can be reduced up to 40% compared to "Disabled" mode, but the maximum speed, maximum acceleration/deceleration, and payload decrease in comparison.
  • Page 124 6-14...
  • Page 125 ELECYLINDER Chapter Troubleshooting Troubleshooting confirmations ···································· 7-1 Troubleshooting diagnosis ········································· 7-4 Troubleshooting with no alarm generated ····················· 7-6 Operation failure ······································································ 7-6 Abnormal or unstable operation ·················································· 7-8 Troubleshooting by alarm groups ······························ 7-10 Alarm group A: Overload alarm ················································· 7-11 Alarm group B: Motor abnormality alarm ····································...

  • Page 127: Troubleshooting Confirmations

    7.1 Troubleshooting confirmations 7.1 Troubleshooting confirmations If a problem occurs, check the following points first in order to ensure quick recovery and prevent recurrence of the problem. (1) Check status indicator LED (SV/ALM LED) ○ : Light ON × : Light OFF : Blinking ★...
  • Page 128 7.1 Troubleshooting confirmations Check status indicator LED (wireless status LED) ○ : Light ON × : Light OFF : Blinking ★ ★ Wireless status LED (Left side as seen from the motor side) Wireless status Green Wireless hardware initializing × ×...
  • Page 129 7.1 Troubleshooting confirmations (3) Check for abnormality in the master device (PLC, etc.) (4) Check the voltage of the main power supply (24VDC) Check for momentary power failure, voltage drop, power failure, etc. (5) Confirm the generated alarm Check the alarm information with the teaching tool. (6) Check the connectors for disconnection or incomplete connection (7) Check the cables for connection error, disconnection or snagging Cut off the main power supply of the equipment (to avoid electric shock) and remove the...

  • Page 130: Troubleshooting Diagnosis

    Abnormal conditions can be roughly divided into the following two types. For details and countermeasures, see "7.3 Troubleshooting with no alarm generated". Operation failure Abnormal or unstable operation If the issue is not resolved after checking and taking countermeasures, contact IAI.
  • Page 131 7.2 Troubleshooting diagnosis [When an alarm is generated] The alarm groups and warnings are as follows. For details and countermeasures, see "7.4 Troubleshooting by alarm groups". Alarm Content Main content and typical countermeasures group [Content] Moving parts stopped abnormally. [Countermeasure] Make sure that there are no Overload alarm obstructions or obstacles.

  • Page 132: Troubleshooting With No Alarm Generated

    ● Replace the controller cover assembly. →For details, refer to " Controller replacement (page 8-15 to 16)". ● If the unit still does not recover, contact IAI. [Condition 2] SV/ALM LEDs light up red Possible cause Confirmation/countermeasure Alarm generated. ● Connect the teaching tool.
  • Page 133 7.3 Troubleshooting with no alarm generated [Condition 3] The unit does not operate even when a command is sent from a master device such as a PLC Possible cause Confirmation/countermeasure I/O signal communication is not established ● Check the input/output status of the I/O signal with the monitoring function of the teaching tool.

  • Page 134: Abnormal Or Unstable Operation

    ● Re-mount according to the mounting method described in the instruction manual. →For details, refer to "2.3/2.4 Installation method". The sliding resistance of the Contact IAI. ELECYLINDER is excessive. [Situation 2] The movement is complete, but the LS signal is not output Possible cause Confirmation/countermeasure The detection range of the LS signal is set Adjust Parameter No.
  • Page 135 7.3 Troubleshooting with no alarm generated [Situation 3] Shock or vibration is observed in acceleration/deceleration Possible cause Confirmation/countermeasure ● Acceleration/deceleration setting is too ● Lower the acceleration/deceleration setting. high. ● Enable Parameter No. 5 "Smooth ● A load susceptible to acceleration and accel/decel setting"...

  • Page 136: Troubleshooting By Alarm Groups

    If the same alarm recurs after clearance, it is highly probable that the cause of the alarm has not been resolved. If the cause of the alarm cannot be resolved or the alarm cannot be cleared after resolving the cause, contact IAI. 7-10...

  • Page 137: Alarm Group A: Overload Alarm

    7.4 Troubleshooting by alarm groups Alarm group A: Overload alarm Moving parts of ELECYLINDER stopped abnormally while moving to the target position. Cause Countermeasure Operation may not be possible due to contact with or Remove any external obstacles or other external snagging on external obstacles.

  • Page 138: Alarm Group B: Motor Abnormality Alarm

    If this alarm recurs after performing the inspection Replacement of the motor is required. Customers above and improving the power supply environment, may not replace the motor by themselves. Contact it is highly likely that the motor has failed. IAI. 7-12...

  • Page 139: Alarm Group C: Controller Abnormality Alarm

    7.4 Troubleshooting by alarm groups Alarm group C: Controller abnormality alarm Controller abnormality occurred. Cause Countermeasure The controller is affected by the noise of a peripheral Shut down the power supply of the peripheral device device and cannot operate normally. and operate only with the ELECYLINDER, then check to see whether this alarm persists.

  • Page 140: Alarm Group D: Controller-Encoder Abnormality Alarm

    Replace the motor or controller cover assembly. above and improving the power supply environment, Customers may not replace the motor by themselves. it is highly likely that the motor or controller has failed. Contact IAI. Controller replacement →For details, refer to " (page 8-15 to 16)".

  • Page 141: Alarm Group E: Supply Voltage/Power Capacity Abnormality Alarm

    7.4 Troubleshooting by alarm groups Alarm group E: Supply voltage/power capacity abnormality alarm An abnormality occurred in the power supply voltage and capacity supplied to the rear of the ELECYLINDER. Cause Countermeasure The ELECYLINDER may be being used under Check the specification values such as payload, conditions exceeding the specifications described in acceleration/deceleration and speed, and adjust the catalog.
  • Page 142 7.4 Troubleshooting by alarm groups Warning: Maintenance warning 1 This is an alert that the target value of the "total travel count" set by the customer has been reached. Content Countermeasure For safe use and long service life of the [Countermeasure 1] ELECYLINDER, periodic lubrication is Perform maintenance and inspection such as...
  • Page 143 If there is no abnormality in the sliding motion, there is a possibility of motor or brake failure. Replacement of the motor is recommended. Customers may not replace the motor by themselves. Contact IAI. * For setting, refer to "5.2 Maintenance information" and "5.3 Setting maintenance information". 7-17...
  • Page 144 7-18...
  • Page 145 ELECYLINDER Chapter Maintenance and Inspection Precautions for maintenance and inspection work ·········· 8-1 Inspection items and schedule ··································· 8-3 Belt type (EC-B□S□) ································································ 8-3 Grease supply timing ································································ 8-3 Visual inspection items ············································· 8-4 External visual inspection ·························································· 8-4 Internal visual inspection ··························································· 8-5 Cleaning ································································...

  • Page 147: Precautions For Maintenance And Inspection Work

    8.1 Precautions for maintenance and inspection work 8.1 Precautions for maintenance and inspection work Make sure to read the following precautions before conducting any maintenance or inspection work. Warning Do not climb on or put anything on the ELECYLINDER. Otherwise, this may lead to accidental falling, injury or damage to the product due to falling objects, product loss of function or performance degradation, or shortening of product life.
  • Page 148 8.1 Precautions for maintenance and inspection work Caution Never use fluorine-based grease. Mixing with lithium-based grease not only reduces the performance of the grease, it may even cause damage to the actuator. For Grease Option G5, do not attempt to use any grease that is not recommended. The grease film may run out if the actuator performs return operation continuously over a distance of 30mm or less.

  • Page 149: Inspection Items And Schedule

    8.2 Inspection items and schedule 8.2 Inspection items and schedule Follow the maintenance inspection schedule below. It is assumed that the equipment is operating 8 hours per day. If the equipment is running continuously night and day or otherwise running at a high operating rate, inspect more often.

  • Page 150: Visual Inspection Items

    8.3 Visual inspection items 8.3 Visual inspection items Refer to "8.5 Greasing method" for detailed information about the greasing method. Refer to "8.6 How to replace components" for detailed information about specific component replacement and adjustment methods. External visual inspection Inspection items Maintenance work Is abnormal noise or vibration...

  • Page 151: Internal Visual Inspection

    Inspection items Maintenance work The guide may be damaged. Is play or dust generated? Contact IAI. Remove the foreign matter, clean, and inspect the Has foreign matter penetrated inside? interior for any damage. Is the guide grease not lubricating well?
  • Page 152 8.3 Visual inspection items The period of replacement for the belt cannot be simply determined as the durability of the belt can be affected by the duration of operation significantly. As the belt gets deteriorated in duration of use such as abrasion, it is required that you have inspection on the points stated below.
  • Page 153 8.3 Visual inspection items (1) Remove the sheet clamp. (2) Fold back the stainless steel sheet and inspect the interior. (3) Return the stainless steel sheet to normal and secure with sheet clamps. Sheet clamp How to have internal inspection [How to remove the sheet clamps] Grab a "sheet clamp"...

  • Page 154: Cleaning

    8.4 Cleaning 8.4 Cleaning External cleaning ● Clean exterior surfaces as necessary. ● Use a soft cloth to wipe away dirt and buildup. ● Do not blow too hard with compressed air, as it may cause dust to get in through gaps. ●...

  • Page 155: Greasing Method

    8.5 Greasing method 8.5 Greasing method [1] Grease used: Use an equivalent product Application During maintenance Default (reference) location (recommended product) Kyodo Yushi Kyodo Yushi Guide Multemp LRL No.3 Multemp LRL No.3 Caution Never use fluorine-based grease. Mixing with lithium-based grease not only reduces the performance of the grease, it may even cause damage to the actuator.
  • Page 156 8.5 Greasing method Greasing method: guide (1) Remove the sheet clamp. (Refer to page 8-7 for the removal method) (2) Pull up the stainless steel sheet and lubricate using a grease gun through the φ3.5 grease fitting. (B6:1.5 to 2.0cc, B7:2.0 to 2.5cc) (3) Move the slider full-stroke to apply the grease thoroughly.
  • Page 157 8.5 Greasing method [Recommended Grease Gun and Nozzle] Nozzle Grease Gun Nozzle Manufacturer Grease gun with attachment screw R1/8 eg. GC-57K (Yamada) Caution Supplying too much grease may increase sliding resistance. This may increase motor load and result in decreased performance. If the grease enters your eye, immediately see a specialist physician for appropriate care.

  • Page 158: How To Replace Components

    8.6 How to replace components 8.6 How to replace components Stainless steel sheet replacement/adjustment (1) Remove the sheet clamp. (Refer to page 8-7 for the removal method) (2) Loosen the screws. (3) Pull out the old stainless steel sheet. (4) Insert a new stainless steel sheet using the reverse procedure. It should be inserted along the slider internal guide.
  • Page 159 ● Stainless steel sheet replacement can be performed by the customer. However, if you have any concerns regarding the work, we recommend that you bring the unit to IAI or have one of our technicians come to your site to perform the replacement.

  • Page 160: Sheet Slider Replacement

    8.6 How to replace components Sheet slider replacement (1) Remove the sheet clamp. (Refer to page 8-7 for the removal method) (2) Loosen the screws and remove the stainless steel sheet. (3) Remove the slider cover (4) Remove the old sheet slider. (5) Mount the new sheet slider using the reverse procedure.

  • Page 161: Controller Replacement (Motor Cover Assembly Replacement)

    8.6 How to replace components Controller replacement (motor cover assembly replacement) (1) Loosen the screws and remove the end cover. (2) Loosen the screws to remove the wiring/connectors, then remove the used motor cover assembly. → Refer to "Precautions for connectors/wiring" on page 8-16. (3) Mount the wiring/connectors to the new motor cover assembly and return it to the original state.
  • Page 162 8.6 How to replace components Precautions for connectors/wiring Frame grounding wires should be jointly fastened Ａ Motor cover assembly To replace, remove the connector Frame grounding wires should be jointly fastened Motor * Before pulling off the motor cover assembly, make sure to remove the connector * Be careful not to snag the Motor cover assembly interior...

  • Page 163: Wireless Communication Circuit Board Replacement (End Cover Assembly Replacement)

    8.6 How to replace components Wireless communication circuit board replacement (End cover assembly replacement) (1) Loosen the screws, then remove the old end cover assembly. (2) Loosen the screws, then dislodge the motor cover assembly. Keep the cable connected to the motor cover assembly connected. (3) Remove the cable connector for the old end cover assembly from the controller circuit board inside the motor cover assembly.
  • Page 164 8.6 How to replace components Notes on connectors/wiring Frame grounding wires should be jointly fastened Ａ Motor cover assembly For replacement, remove the old end cover assembly connector and mount the new end cover assembly connector Motor cover assembly interior End cover assembly interior (A arrow view) Wireless communication circuit board [Model: IABL3826]...

  • Page 165: Belt Adjustment

    8.6 How to replace components Belt adjustment (1) Remove the sheet clamp. (Refer to page 8-7 for the removal method) (2) Remove the slider cover. (3) Loosen the screws and remove the stainless steel sheet. (4) Remove the sheet slider. Cross-recessed pan screws ×...
  • Page 166 8.6 How to replace components (6) Loosen the flanged hex socket set screws holding idler pulley assembly. Idler pulley assembly Flanged hex socket set screw （B6/B7:M4 × 12） (7) Adjust the belt tension. Hang a wire on Idler Pulley Assembly and pull it evenly by applying tension described in the table below with a tension gauge.
  • Page 167 8.6 How to replace components (8) Mount the front cover. Hex socket head cap screws × 2 pcs (B6/B7:M4 × 5, Tightening torque 1.14N•m) (9) Mount the sheet slider. (10) Mount the stainless steel sheet and affix it with screws. (11) Mount the slider cover.

  • Page 168: Belt Replacement

    8.6 How to replace components Belt replacement (1) Remove the sheet clamp. (Refer to page 8-7 for the removal method) (2) Remove the slider cover. (3) Loosen the screws and remove the stainless steel sheet. (4) Remove the sheet slider. Cross-recessed pan screws ×...
  • Page 169 8.6 How to replace components (6) Remove the bracket cover. Bracket cover (7) Take off the screws, slide the slider and have belt retainer 1 seeable. Hex socket head cap screws × 2 pcs (B6/B7:M4 × 10) Belt retainer 1 Slider (8) Loosen the flanged hex socket set screws affixing idler pulley assembly and take off idler pulley assembly.
  • Page 170 8.6 How to replace components (9) Take off belt and take belt retainer 1, rolled bush, fixing belt and belt retainer 2 off the long belt. Belt retainer 1 Rolled bush Fixing belt Hex socket head cap screws × 2 pcs Long belt (B6/B7:M3 ×...
  • Page 171 8.6 How to replace components (11) Put a new long belt through the pulley on motor unit assembly and idler pulley assembly. (Note) Pay attention to the long belt so it will not twist. New long belt Idler pulley assembly Pulley on motor unit assembly Put long belt through this gap.
  • Page 172 8.6 How to replace components (12) Attach belt retainer 1, rolled bush, fixing belt and belt retainer 2 to long belt and hold them with screws. (Note) Make sure long belt and fixing belt are aligned with each other. (Note) Insert rolled bush to fixing belt. Belt retainer 1 Rolled bush Fixing belt...
  • Page 173 8.6 How to replace components (14) Affix belt retainer 1 on the slider with screws. Hex socket head cap screws × 2 pcs (B6/B7:M4 × 10) Tightening torque 3.59N•m) Belt retainer 1 Slider (15) Adjust the belt tension. Hang a wire on Idler Pulley Assembly and pull it evenly by applying tension described in the table below with a tension gauge.
  • Page 174 8.6 How to replace components (16) Mount the bracket cover. Bracket cover (17) Mount the front cover. Hex socket head cap screws × 2 pcs (B6/B7:M4 × 5, Tightening torque 1.14N•m) 8-28...
  • Page 175 8.6 How to replace components (18) Mount the sheet slider. (19) Mount the stainless steel sheet and affix it with screws. (20) Mount the slider cover. (21) Mount the sheet clamp. Cross-recessed pan screws × 2 pcs (B6/B7:M3 × 5, Tightening torque 0.41N•m) Slider cover Sheet slider...

  • Page 176: Motor Replacement

    8.6 How to replace components Motor replacement (1) Remove the sheet clamp. (Refer to page 8-7 for the removal method) (2) Remove the slider cover. (3) Loosen the screws and remove the stainless steel sheet. (4) Remove the sheet slider. Cross-recessed pan screws ×...
  • Page 177 8.6 How to replace components (6) Remove the bracket cover. Bracket cover (7) Loosen the flanged hex socket set screws affixing idler pulley assembly and take off idler pulley assembly. Loosen long belt. Idler pulley assembly Flanged hex socket set screw （B6/B7:M4 ×...
  • Page 178 8.6 How to replace components (8) Loosen the screws and remove the end cover. (9) Loosen the screws to remove the wiring/connectors, then remove the motor cover assembly. → Refer to "Precautions for connectors/wiring" on page 8-16. Cross-recessed tapping screws × 2 pcs End cover (M3 ×...
  • Page 179 8.6 How to replace components (12) Connect the cables and connectors, attach motor cover assembly and fix them with screws. (13) Attach the end cover and fix it with screws. Cross-recessed tapping screws × 2 pcs End cover (M3 × 10, Tightening torque 0.60N•m) Cross-recessed pan screws ×...
  • Page 180 8.6 How to replace components (15) Adjust the belt tension. Hang a wire on Idler Pulley Assembly and pull it evenly by applying tension described in the table below with a tension gauge. Once the tension reaches the specified load, tighten the flanged hex socket set screws to affix it.
  • Page 181 8.6 How to replace components (17) Mount the front cover. Hex socket head cap screws × 2 pcs (B6/B7:M4 × 5, Tightening torque 1.14N•m) (18) Mount the Sheet slider (19) Mount the stainless steel sheet and affix it with screws. (20) Mount the slider cover.
  • Page 182 8.6 How to replace components Body model Motor unit model number EC-B6S□ EC-MUB6(-WA)(-B) EC-B7S□ EC-MUB7(-WA)(-B) WA: Battery-less absolute specification, B: Specification with brake 8-36...

  • Page 183: Chapter 9 External Dimensions

    ELECYLINDER Chapter External Dimensions 9.1 Belt type external dimensions ············································ 9-1 EC-B6 ···························································································· 9-1 EC-B7 ···························································································· 9-2...

  • Page 185: Belt Type External Dimensions

    9.1 Belt type 9.1 Belt type external dimensions EC-B6 M.E.: Mechanical end, S.E.: Stroke end ST: Stroke 14.7 59.8 M.E. S.E. Home M.E. Teaching port 19.5 Status LED 2-φ5 H7 Reamed, depth 5 Power I/O connector 51 (Reamed hole tolerance ±0.02) 4-M5 Depth 10 Grease fitting for guide Greasing port...

  • Page 186: Ec-B7

    9.1 Belt type EC-B7 M.E.: Mechanical end, S.E.: Stroke end ST: Stroke 14.2 60.8 15.5 M.E. S.E. M.E. 19.5 Teaching port 78.5 Status LED 2-φ5H7 Reamed, depth 5 Power I/O connector 61 (Reamed hole tolerance ±0.02) 4-M5 Depth 10 Grease fitting for guide Greasing port Datum surface Allowable moment...
  • Page 187 ELECYLINDER Chapter Life 10.1 Concept of life for belt type ······································ 10-1 How to calculate operation life ·················································· 10-1 Relation between operation life and moment ······························· 10-3 10.2 Concept of life for controller ····································· 10-3...

  • Page 189: Concept Of Life For Belt Type

    10.1 Concept of life for belt type 10.1 Concept of life for belt type The mechanical life of the belt type is represented by that of the linear guide receiving the greatest moment load. The operation life of the linear guide is to be determined by the total driving distance reachable without flaking (peeling on rail surface) in 90% of a group of products operated under the same conditions.
  • Page 190 10.1 Concept of life for belt type For "Standard load coefficient fws", "Load coefficient fw" and "Mounting coefficient fα", refer to the contents below for configuration and selection. [Standard load coefficient fws] For ELECYLINDERs described in this manual, calculate with fws = 1.2. [Load coefficient fw] This coefficient allows consideration of the effects on life due to operating conditions.

  • Page 191: Relation Between Operation Life And Moment

    10.1 Concept of life for belt type 10.2 Concept of life for controller Relation between operation life and moment The operation life depends on the moment acting on the slider. With a light load, it may be longer than 5,000km, the standard rated life. With no consideration of vibration and mounting conditions, the operation life is 40,000km according to the calculation with the formula on the previous page, assuming that 0.5 C (half of...
  • Page 192 10-4...
  • Page 193 ELECYLINDER Chapter Warranty 11.1 Warranty period ···················································· 11-1 11.2 Scope of the warranty ············································ 11-1 11.3 Honoring the warranty ············································ 11-1 11.4 Limited liability ······················································ 11-2 11.5 Conformance with applicable standards/regulations, etc., and application conditions ································· 11-2 11.6 Other items excluded from warranty ·························· 11-2...

  • Page 195: Warranty Period

    Our products are covered by warranty when all of the following conditions are met. Faulty products covered by warranty will be replaced or repaired free of charge: (1) The breakdown or malfunction in question pertains to our product as delivered by IAI or our authorized dealer.

  • Page 196: Limited Liability
