IAI EleCylinder Series Quick Start Manual

STEP

Checking the Necessary Equipment

1
ELECYLINDER Quantity: 1
24VDC Power Supply
Model: PSA-24*
*Commercially
available 24V
power supply can
also be used.
STEP

Installing the ELECYLINDER

2
Prepare the screws, nuts and tools required for installation.
Precautions for Installation
Install with proper length of screws and tightening torque.
Do not apply external force to the ELECYLINDER body during installation.
When installing an external guide, please perform the centering adjustment.
STEP

Wiring

3
Connecting the Cable
Connect the power - I/O cable to the ELECYLINDER.
Push in the connector until it clicks into place.
ELECYLINDER
Quick Start Guide e Quick Start Guide
Please refer to the Instruction Manual (ME3766 ,ME3778,ME3779) for details of handling.
Power - I/O Cable Quantity: 1
Model: EC
Teaching Pendant Quantity: 1
Quantity: 1
e
Model: CB-EC-PWBIO***-RB
Please prepare
either one.
* Select by model
Model: TB-03-*-*
Please prepare
either one.
* Sold separately
Items to Prepare
ELECYLINDER/Power - I/O cable
Connection Diagram
EC
T Third hird d Edition
Power - I/O Connector
Quantity: 1
Model: 1-1871940-6
* Select by model
PC Compatible Software
Quantity: 1
Model: RCM-101-USB
* Sold separately
Insert until it
clicks
