MATSONIC MS9087C Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
This publication, photographs, illustrations and software are under
the protection of international copyright laws and all rights
reserved. It does not allow any reproduction of this manual,
content and any materials contained herein without the written
consent of the authentic manufacturer.
The information in this manual is subject to change without notice.
The manufacturer does neither represent nor warrant the contents
hereof; and specifically disclaims any implied warranties of
merchantability or fitness for any particular purpose. Furthermore,
the manufacturer reserves the right to revise and change this
publication from time to time, without the obligation of notifying
any person of such revision or changes.
Trademarks
IBM, VGA, and PS/2 are registered trademarks of International
Business Machines.
Intel, Pentium/II/III, Pentium 4, Celeron and MMX are registered
trademarks of Intel Corporation.
Microsoft, MS-DOS and Windows 98/ME/NT/2000/XP are
registered trademarks of Microsoft Corporation.
PC-cillin is a trademark of Trend Micro Inc.
AMI is a trademark of American Megatrends Inc.
It has been acknowledged that other brands or product names in
this manual are trademarks or the properties of their respective
owners.
Copyright © 2003
All Rights Reserved
MS9087C Series, V1.0
I865PE/October 2003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS9087C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MATSONIC MS9087C

Summary of Contents for MATSONIC MS9087C

  • Page 1 AMI is a trademark of American Megatrends Inc. It has been acknowledged that other brands or product names in this manual are trademarks or the properties of their respective owners. Copyright © 2003 All Rights Reserved MS9087C Series, V1.0 I865PE/October 2003...

  • Page 2: Table Of Contents

    Table of Contents Trademark ................I Static Electricity Precautions ..........III Pre-Installation Inspection..........III Chapter 1: Introduction............1 Key Features...............2 Package Contents ..............5 Chapter 2: Mainboard Installation..........6 Mainboard Components............7 I/O Ports................7 Installing the Processor............8 Installing Memory Modules ..........9 Jumper Settings ..............11 Install The Mainboard............11 Connecting Optional Devices..........13 Install Other Devices ............15 Expansion Slots ..............

  • Page 3: Static Electricity Precautions

    Static Electricity Precautions Static electricity could damage components on this mainboard. Take the following precautions while unpacking this mainboard and installing it in a system. 1. Don’t take this mainboard and components out of their original static-proof package until you are ready to install them. 2.
  • Page 4 Notice: Owing to Microsoft’s certifying schedule is various to every supplier, we might have some drivers not certifie d yet by Microsoft. Therefore, it might happen under Windows XP that a dialogue box (shown as below) pop out warning you this software has not passed Windows Logo testing to verify its compatibility with Windows XP.

  • Page 5: Chapter 1: Introduction

    Chapter 1 Introduction This mainboard has a Socket-478 supporting Intel Pentium 4/Hyper Threading Technology processors with Front-Side Bus (FSB) speeds up to 800 MHz. Hyper Threading Technology, designed to take advantage of the multitasking features in Windows XP, gives you the power to do more things at once.

  • Page 6: Key Features

    Key Features This mainboard has these key features: Socket-478 Processor ♦ Supports Intel Pentium 4 series CPU with Hyper Threading Technology ♦ Supports up to 800 MHz Front-Side Bus Hyper-Threading technology enables the operating system into thinking it’s hooked up to two processors, allowing two threads to be run in parallel, both on separate ‘logical’...
  • Page 7 Memory Support ♦ Three 184-pin DIMM sockets for DDR SDRAM memory modules ♦ Supports DDR400 memory bus ♦ Maximum installed memory is 3GB AC97 Audio Codec ♦ 6-CH hardware architecture allows multi - channel south bridge to playback 6CH audio ®...
  • Page 8 Onboard I/O Ports The mainboard has a full set of I/O ports and connectors: ♦ Two PS/2 ports for mouse and keyboard ♦ One serial port ♦ One parallel port ♦ Eight USB2.0 ports (four back-panel ports, onboard USB connectorsUSB2/USB3 providing four extra ports ♦...

  • Page 9: Package Contents

    ♦ Power management ♦ Wake-up alarms ♦ CPU parameters and memory timing ♦ CPU and memory timing The firmware can also be used to set parameters for different processor clock speeds. Bundled Software ♦ PC-Cillin 2002 provides automatic virus protection under Windows 98/ME/NT/2000/XP ♦...

  • Page 10: Chapter 2: Mainboard Installation

    Chapter 2 Mainboard Installation To install this mainboard in a system, please follow these instructions in this chapter: Identify the mainboard components Install a CPU Install one or more system memory modules Make sure all jumpers and switches are set correctly Install this mainboard in a system chassis (case) Connect any extension brackets or cables to connectors on the mainboard...

  • Page 11: Mainboard Components

    Mainboard Components Identify major components on the mainboard via this diagram underneath. I/O Ports The illustration below shows a side view of the built-in I/O ports on the mainboard. (optional)

  • Page 12: Installing The Processor

    Use the upper PS/2 port to connect a PS/2 PS/2 Mouse pointing device. Use the lower PS/2 port to connect a PS/2 PS/2 Keyboard keyboard. Use the Parallel port to connect printers or Parallel Port other parallel communications devices. (PRN) Use the COM port to connect serial devices COM1 such as mice or fax/modems.

  • Page 13: Installing Memory Modules

    2. Match the pin1 corner marked as the beveled edge on the CPU with the pin1 corner on the socket. Insert the CPU into the socket. Do not use force. 3. Push the locking lever down and hook it under the latch on the edge of socket.
  • Page 14 DIMM1 DIMM2 DIMM3 Memory Module Installation Procedure These modules can be installed with up to 3 GB system memory. Refer to the following to install the memory module. 1. Push down the latches on both sides of the DIMM socket. 2.

  • Page 15: Jumper Settings

    Jumper Settings Connecting two pins with a jumper cap is SHORT; removing a jumper cap from these pins, OPEN. JP1: Clear CM OS Jumper Use this jumper to clear the contents of the CMOS memory. You may need to clear the CMOS memory if the settings in the Setup Utility are incorrect and prevent your mainboard from operating.
  • Page 16 ATX1 PWRFAN ATX2 SYSTEMFAN SJ1 LSJ1 PANEL1 Connect the power connector from the power supply to the ATX2 connector on the mainboard. ATX1 is the CPU Vcore power connector. If there is a cooling fan installed in the system chassis, connect the cable from the cooling fan to the SYSFAN fan power connector on the mainboard.

  • Page 17: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the mainboard’s optional devices: USB2 AUDIO2 USB3 SPK1 SPK1: Speaker Connector Connect the cable from the PC speaker to the SPK1 connector on the mainboard. Pin Signal Signal SPKR AUDIO2: Front Panel Audio Connector This connector allows the user to install auxiliary front-oriented microphone and line -out ports for easier access.
  • Page 18 Signal Pin Signal VERG_FP_USBPWR0 2 VERG_FP_USBPWR0 USB_FP_P0 - USB_FP_P1 - USB_FP_P0+ USB_FP_P1+ GROUND GROUND USB_FP_OC0 1. Locate the USB2/3 connector on the mainboard. 2. Plug the bracket cable onto the USB2/3 connector. 3. Remove a slot cover from one of the expansion slots on the system chassis.

  • Page 19: Install Other Devices

    Install Other Devices Install and connect any other devices in the system following the steps below. SATA1 SATA2 IDE2 FLOPPY IDE1 Floppy Disk Drive The mainboard ships with a floppy disk drive cable that can support one or two drives. Drives can be 3.5” or 5.25” wide, with capacities of 360K, 720K, 1.2MB, 1.44MB, or 2.88MB.
  • Page 20 If you want to install more IDE devices, you can purchase a second IDE cable and connect one or two devices to the Secondary IDE channel connector IDE2 on the mainboard. If you have two devices on the cable, one must be Master and one must be Slave. Serial ATA Devices The Serial ATA (Advanced Technology Attachment) is the standard interface for the IDE hard drives, which is designed to...

  • Page 21: Expansion Slots

    Pin Signal CD IN L CD IN R Expansion Slots This mainboard has one AGP, one CNR and five 32-bit PCI slots. PCI2 AGP1 CNR1 PCI3 PCI1 Follow the steps below to install an AGP/CNR/PCI expansion card. 1. Locate the AGP, CNR or PCI slots on the mainboard. 2.

  • Page 22: Chapter 3: Bios Setup Utility

    Chapter 3 BIOS Setup Utility Introduction The BIOS Setup Utility records settings and information of your computer, such as date and time, the type of hardware installed, and various configuration settings. Your computer applies the information to initialize all the components when booting up and basic functions of coordination between system components.

  • Page 23: Running The Setup Utility

    Running the Setup Utility Every time you start your computer, a message appears on the screen before the operating system loading that prompts you to “Hit <DEL>if you want to run SETUP”. Whenever you see this message, press the Delete key, and the Main menu page of the Setup Utility appears on your monitor.

  • Page 24: Standard Cmos Setup Page

    Standard CMOS Setup Page This page displays a table of items defining basic information about your system. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. Standard CMOS Setup System Time: 00:02:01 Help Item System Date: Wed Jul 23, 2003 User [Enter], [TAB] or [SHIFT-TAB] to Primary IDE Master...

  • Page 25: Advanced Setup Page

    Advanced Setup Page This page sets up more advanced information about your system. Handle this page with caution. Any changes can affect the operation of your computer. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. Advanced Setup Quick Boot Enabled Help Item Boot Device...

  • Page 26: Features Setup Page

    When this item is enabled, BIOS will Auto detect disable the clock signal of free DIMM/PCI DIMM/PCI slots. Clock Spread Spectrum If you enable spread spectrum, it can significantly reduce the EMI (Electro- Magnetic Interference) generated by the system. Features Setup Page This page sets up some parameters for peripheral devices connected to the system.

  • Page 27: Power Management Setup Page

    Use this item to enable or disable either or OnBoard PCI both of the onboard Primary and Secondary IDE channels. Controller This item enables or disables the AC’97 Audio Device audio chip. This item enables or disables the onboard Ethernet Ethernet LAN.

  • Page 28: Pci/Plug And Play Setup Page

    Suspend Mode This item selects the status S1(Stop Clock) or S3(Suspend to RAM) when the system enters the power-saving Suspend mode. This item sets up the timeout for Suspend Suspend Time mode in minutes. If the time selected passes without any system activity, the computer will enter power-saving Suspend mode.

  • Page 29: Bios Security Features Setup Page

    This item indicates if the primary graphics Primary adapter uses the PCI or the AGP bus. The Graphics default AGP setting still lets the onboard Adapter display work and allows the use of a second display card installed in an AGP slot. If this item is enabled, an IRQ will be Allocate IRQ assigned to the PCI VGA graphics system.

  • Page 30: Cpu Pnp Setup Page

    CPU PnP Setup Page This page helps you manually configure the CPU of this mainboard. The system will automatically detect the type of installed CPU and make the appropriate adjustments to these items on this page. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. CPU PnP Setup Manufacturer : Intel Help Item...

  • Page 31: Hardware Monitor Page

    Hardware Monitor Page This page sets up some parameters for the hardware monitoring function of this mainboard. CMOS SETUP UTILITY – Copyright (C) 1985-2003, American Megatrends, Inc. Hardware Monitor Setup *** System Hardware Monitor*** Help Item Vcore 1.419V Vddq 1.548V Vcc5V 5.067V SB3V...

  • Page 32: Save Changes And Exit

    Save Changes and Exit Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility configuration. When the Save Changes and Exit dialog box appears, press Y to save and exit, or press N to return to the main menu. Discard Changes and Exit Highlight this item and press <Enter>...

  • Page 33: Chapter 4: A Bout The Software & Cd-Rom

    Chapter 4 About the Software & CD-ROM The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your mainboard version.

  • Page 34: Utility Software Reference

    Utility Software Reference All the utility software available on the CD-ROM is Windows compliant. It is provided only for the convenience of customers. The following software is furnished under license and may only be used or copied in accordance with the terms of the license. Note: The software in these folders is subject to change at anytime without prior notice.

  • Page 35: Hyper Threading Cpu

    Hyper Threading CPU You must update BIOS to initiate BIOS Hyper Threading Function and use HT CPU function under WinXP Operating System; if not, please disable this option. ♦ When BIOS detects the HT CPU, it shows the “Hyper Threading Function (default Disabled)” option, which you must set Enabled if you want to test HT CPU function.
