Mainboard User's Manual
This publication, including all photographs, illustrations and
software, is protected under international copyright laws, with all
rights reserved. Neither this manual, nor any of the material
contained herein, may be reproduced without the express written
consent of the manufacturer.
The information in this document is subject to change without
notice. The manufacturer makes no representations or warranties
with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular
purpose. Further, the manufacturer reserves the right to revise this
publication and to make changes from time to time in the content
hereof without obligation of the manufacturer to notify any person
of such revision or changes.
Trademarks
IBM, VGA, and PS/2 are registered trademarks of International
Business Machines.
Intel, Pentium/II/III/IV, Celeron and MMX are registered
trademarks of Intel Corporation.
Microsoft, MS-DOS and Windows NT/95/98/ME/2000 are
registered trademarks of Microsoft Corporation.
PC-cillin is a registered trademark of Trend Micro Inc.
AMI is a registered trademark of American Megatrends Inc.
A3D is a registered trademark of Aureal Inc.
MediaRing Talk is a registered trademark of MediaRing Inc.
3Deep is a registered trademark of E-Color Inc.
SiS is a trademark of Silicon Integrated System Corporation.
Other names used in this publication may be trademarks and are
acknowledged.
Copyright © 2001
All Rights Reserved
MS9307C Series, V3.0
S645/December 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS9307C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MATSONIC MS9307C Series

  • Page 1 3Deep is a registered trademark of E-Color Inc. SiS is a trademark of Silicon Integrated System Corporation. Other names used in this publication may be trademarks and are acknowledged. Copyright © 2001 All Rights Reserved MS9307C Series, V3.0 S645/December 2001...
  • Page 2 Mainboard User’s Manual...
  • Page 3: Table Of Contents

    Mainboard User’s Manual Table of Contents Trademarks ................I Chapter 1..................1 Introduction ................. 1 Key Features ................2 Package Contents ..............5 Static Electricity Precautions ..........6 Pre-Installation Inspection ............6 Chapter 2..................7 Mainboard Installation ..............7 Mainboard Components............8 I/O Ports..................
  • Page 4 Mainboard User’s Manual...
  • Page 5: Chapter 1

    1: Introduction Chapter 1 Introduction This mainboard has a Socket-478 processor socket for Intel Pentium 4 type of processors supporting front side bus (FSB) speeds up to 400 MHz. This mainboard uses the SiS645 chipset which supports built-in AC97 Codec , 2 DDR + 2 SDR modules up to 2GB system memory, and provides Ultra DMA 33/66/100 function.
  • Page 6: Key Features

    Mainboard User’s Manual Key Features The key features of this mainboard include: Socket-478 Processor The PGA Socket 478 Supports Intel Pentium 4 series CPUs Supports up to 400 MHz Front-Side Bus Memory Support Two 168-pin DIMM slots for SDRAM memory modules Two 184-pin DIMM slots for DDR memory modules Support SDRAM up to 133 MHz /DDR up to 333 MHz memory bus...
  • Page 7 1: Introduction AC97 Audio Codec Compliant AC97 2.2 specification Supports 18-bit ADC (Analog Digital Converter) and DAC (Digital Analog Converter) as well as 18-bit stereo full- duplex codec Onboard I/O Ports The mainboard has a full set of I/O ports and connectors: Two PS/2 ports for mouse and keyboard Two serial ports One parallel port...
  • Page 8 Mainboard User’s Manual Bundled Software PC-Cillin2000 provides automatic virus protection under Windows 95/98/NT/2000 MediaRing Talk provides PC to PC or PC to Phone internet phone communication SuperVoice is data, fax and voice communication software WinDVD2000 is a DVD playback application (optional) Recovery Genius 21 V5.0 provides the function to recover, reserve and transfer hard disk data.
  • Page 9: Package Contents

    1: Introduction Package Contents Your mainboard package contains the following items: The mainboard The User’s Manual One diskette drive ribbon cable One IDE drive ribbon cable Software support CD Module Retention damp Optional Accessories You can purchase the following optional accessories for this mainboard.
  • Page 10: Static Electricity Precautions

    Mainboard User’s Manual Static Electricity Precautions Components on this mainboard can be damaged by static electricity. Take the following precautions when unpacking the mainboard and installing it in a system. 1. Keep the mainboard and other components in their original static-proof packaging until you are ready to install them.
  • Page 11: Chapter 2

    2: Mainboard Installation Chapter 2 Mainboard Installation To install this mainboard in a system, please follow the instructions in this chapter: Identify the mainboard components Install a CPU Install one or more system memory modules Verify that all jumpers or switches are set correctly Install the mainboard in a system chassis (case) Connect any extension brackets or cables to connecting headers on the mainboard...
  • Page 12: Mainboard Components

    Mainboard User’s Manual Mainboard Components Use the diagram below to identify the major components on the mainboard. Note: Any jumpers on your mainboard that do not appear in the illustration above are for testing only.
  • Page 13: I/O Ports

    2: Mainboard Installation I/O Ports The illustration below shows a side view of the built-in I/O ports on the mainboard. 1. Use the upper PS/2 port to connect a PS/2 pointing device. 2. Use the lower PS/2 port to connect a PS/2 keyboard. 3.
  • Page 14: Install A Cpu

    Mainboard User’s Manual Install A CPU This mainboard has a Socket-478 which supports Intel Pentium 4 series processors. To ensure reliability, ensure that your processor has a heatsink/cooling fan assembly. Do neither try to install a Socket 370 processor nor a Socket423 in the Socket-478.
  • Page 15: Installing Memory Modules

    2: Mainboard Installation 5. Swing the locking lever down and hook it under the catch on the side of the socket. This secures the CPU in the socket. 6. All processors should be installed with a combination heatsink/cooling fan, connect the cable from the fan to the CPU fan power connector CPUFAN.
  • Page 16 Mainboard User’s Manual Installation Procedure The mainboard accommodates two memory modules. You must install at least one module in any of the three slots. Each module can be installed with up to 2GB system memory. Refer to the following to install the memory modules. 1.
  • Page 17: Setting Jumper Switches

    2: Mainboard Installation Setting Jumper Switches Jumpers are sets of pins connected together with jumper caps. The jumper caps change the way the mainboard operates by changing the electronic circuits on the mainboard. If a jumper cap connects two pins, we say the pins are SHORT. If a jumper cap is removed from two pins, the pins are OPEN.
  • Page 18 Mainboard User’s Manual Install the mainboard in a case. Follow the instructions provided by the case manufacturer using the hardware and internal mounting points on the chassis. ATXPW1 AUDO1 FAN2 Connect the power connector from the power supply to the ATXPW1 connector on the mainboard.
  • Page 19: Optional Extension Brackets

    2: Mainboard Installation Optional Extension Brackets For this mainboard, you can also obtain a USB module extension bracket for more USB ports. Install them by following the steps below. Note: All the ribbon cables used on the extension brackets have a red stripe on the Pin-1 side of the cable.
  • Page 20 Mainboard User’s Manual USBPWR GROUND USBPP4     USBPP3     USBPP4     USBPP3     USBPWR GROUND USBPWR GROUND USBPP6     USBPP5     USBPP6         USBPP5...
  • Page 21: Install Other Devices

    2: Mainboard Installation Install Other Devices Install and connect other devices in the system as steps below. IDE1 IDE2 FDC1 Floppy Disk Drive The mainboard ships with a floppy disk drive cable that can support one or two drives. Drives can be 3.5” or 5.25” wide, with capacities of 360K, 720K, 1.2MB, 1.44MB, or 2.88MB.
  • Page 22 Mainboard User’s Manual Internal Sound Connections If you have installed a CD-ROM drive or DVD-ROM drive, you can connect the drive audio cable to the onboard sound system. On the mainboard, locate the two 4-pin connectors CD_IN1 and CD_IN2. There are two kinds of connector because different brands of CD-ROM drive have different kinds of audio cable connectors.
  • Page 23: Expansion Slots

    2: Mainboard Installation Expansion Slots This mainboard has four 32-bit PCI slots, one ACR slot and one AGP slot. Follow the steps below to install a PCI/ACR/AGP expansion card. 1. Locate the AGP or PCI slots on the mainboard. 2. Remove this slot cover from the system chassis. 3.
  • Page 24 Mainboard User’s Manual...
  • Page 25: Chapter 3

    3: BIOS Setup Utility Chapter 3 BIOS Setup Utility Introduction The BIOS Setup Utility records settings and information about your computer such as the date and time, the type of installed hardware, and various configuration settings. Your computer applies that information to initialize all the components while booting up, and the basic functions of coordination between system components.
  • Page 26: Running The Setup Utility

    Mainboard User’s Manual Running the Setup Utility Every time you start your computer, a message appears on the screen before the operating system loading that prompts you to “Hit <DEL> if you want to run SETUP”. Whenever you see this message, press the Delete key and the Main menu page of the Setup Utility appears on your monitor.
  • Page 27: Standard Cmos Setup Page

    3: BIOS Setup Utility Standard CMOS Setup Page This page helps you set up basic information such as the date and time, the IDE devices, and the diskette drives. AMIBIOS SETUP – STANDARD CMOS SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yy) : Wed Dec.5, 2001 Time (hh/mm/ss) : 14:39:06 32Bit...
  • Page 28: Advanced Setup Page

    Mainboard User’s Manual Advanced Setup Page This page sets up more advanced information about your system. Take care of this page with caution. Any changes can affect the operation of your computer. AMIBIOS SETUP – ADVANCED SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved Quick Boot Enabled Boot Device...
  • Page 29 3: BIOS Setup Utility Floppy Drive Swap If you have two diskette drives installed and you enable this item, drive A becomes drive B and drive B becomes drive A. Floppy Drive Seek If you enable this item, your system will check all floppy disk drives at start up.
  • Page 30: Power Management Setup Page

    Mainboard User’s Manual Power Management Setup Page This page sets some of the parameters for system power management operation. AMIBIOS SETUP – POWER MANAGEMENT SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved ACPI Aware O/S Power Management Enabled Suspend Time out Disabled Hard Disk Time out Disabled...
  • Page 31: Pci / Plug And Play Setup Page

    3: BIOS Setup Utility KeyBoard Power If you enable this item, you can turn the system on and off by pressing hot keys on the keyboard. You must enable the Keyboard Power On jumper and use an ATX power supply in order to use this feature.
  • Page 32: Load Optimal Settings

    Mainboard User’s Manual Load Optimal Settings If you select this item and press Enter a dialog box appears. If you press Y, and then Enter, the Setup Utility loads a set of fail-safe default values. These default values are not very demanding and they should allow your system to function with most kinds of hardware and memory chips.
  • Page 33: Features Setup Page

    3: BIOS Setup Utility Features Setup Page This page sets some of the parameters for peripheral devices connected to the system. AMIBIOS SETUP – FEATURES SETUP (C) 2000 American Megatrends, Inc. All Rights Reserved OnBoard FDC Enabled OnBoard Serial PortA 3F8h/COM1 OnBoard Serial PortB 2F8h/COM2...
  • Page 34 Mainboard User’s Manual Parallel Port DMA Use this item to assign a DMA channel to the parallel port. The options are 0, 1 and 3. OnBoard Game Use this item to enable or disable the onboard Port Game port. OnBoard MIDI Port Use this item to enable or disable the onboard MIDI port, and to assign a port address.
  • Page 35: Cpu Pnp Setup Page

    3: BIOS Setup Utility CPU PnP Setup Page This page lets you manually configure the mainboard for the CPU. The system will automatically detect the kind of CPU that you have installed and make the appropriate adjustments to the items on this page.
  • Page 36: Hardware Monitor Page

    Mainboard User’s Manual Hardware Monitor Page This page sets some of the parameters for the hardware monitoring function of this mainboard. AMIBIOS SETUP – HARDWARE MONITOR (C) 2000 American Megatrends, Inc. All Rights Reserved *** System Hardware *** Vcore 1.632V Vcc 2.5V/Vcc3.3V 2.496V Vcc 3.3V...
  • Page 37: Change Password

    3: BIOS Setup Utility Change Password If you highlight this item and press Enter, a dialog box appears which lets you enter a Supervisor password. You can enter no more than six letters or numbers. Press Enter after you have typed in the password.
  • Page 38 Mainboard User’s Manual...
  • Page 39: Chapter 4: Using The Mainboard Software

    4: Software & Applications Using the Mainboard Software About the Software CD-ROM The support software CD-ROM that is included in the mainboard package contains all the drivers and utility programs needed to properly run the bundled products. Below you can find a brief description of each software program, and the location for your mainboard version.
  • Page 40: Utility Software Reference

    Mainboard User’s Manual Utility Software Reference All the utility software available on the CD-ROM is Windows compliant. It is provided only for the convenience of customers. The following software is furnished under license and may only be used or copied in accordance with the terms of the license. Note: The software in these folders is subject to change at anytime without prior notice.
  • Page 41 4: Software & Applications Super Voice – Fax/Modem Software To install the Super Voice voice, fax, data communication application for use with the built-in fax/modem, run PICSHELL.EXE from the following directory: \UTILITY\SUPER VOICE CD Ghost The CD Ghost software enables you to create a virtual cabinet of CD-ROM drives on your system to help you categorize and organize your CD collection.
  • Page 42 Mainboard User’s Manual PageABC The PageABC application software enables you to create your own home page. To install the PageABC, run SETUP.EXE from the following directory: \UTILITY\PageABC This concludes Chapter 4.
