Control Techniques UD53 User Manual page 23

16.06 Simulated encoder output select
ô
0 ~ 1
Note
This parameter is available only with the following:
Set 16.06 as follows to select the required source for the simulated-
encoder outputs:
16.06
0
1
The simulated-encoder outputs appear on the following terminals:
Terminal
40
41
43
44
46
47
16.07 Simulated-encoder output scaling
ô
0 ~ 15
Enter the required value in 16.07 for scaling the simulated-encoder output.
The scaling factor is as follows:
1
[ 16 07 .
2
For example, for a division of
UD53 User Guide
Issue code: 53nu3
ð
0
UD53 version 2 onward
Drive software version V03.xx.07 onward
Source
Resolver
Encoder 1
Function
Quadrature Frequency
AB and
direction
A
A\
B
B\
Z
Z\
ð
0
]
1
/ , set 16.07 at 4 (16 = 2
16
RW Bit
F
F\
D
D\
Z
Z\
n
2 RW Uni
4
)
19
