16.12 Simulated-encoder Z marker-pulse outputs
synchronization disable
ô
0 ~ 1
Note
This parameter is available only with the following:
Use 16.12 to control the setting of 16.13 Simulated-encoder Z marker-pulse
outputs synchronization inactive indicator.
16.13 Simulated-encoder Z marker-pulse output
synchronization inactive indicator
ô
0 ~ 1
Note
This parameter is available only with the following:
16.13 indicates as follows:
16.13 set at 0
Z marker-pulses are synchronized to the quadrant where the quadrature A
and B outputs are both low.
16.13 set at 1
Z marker-pulses can be present in any of the four quadrants, as follows:
A and B both low
A and B both high
A low and B high
A high and B low
See Z marker-pulse outputs (terminals 46, 47) in Chapter 5 Setting Up the
UD53.
