Summary of Contents for TSC M 23

  • Page 1 Direct Thermal Portable Printer Quick Start Guide...
  • Page 3: Table Of Contents

    Contents Overview ......................1 Front View ....................... 1 Rear View......................2 Installing the Battery..................2 Using the Strap....................3 Loading Media....................3 Loading Continuous Labels for Receipt Paper ..........3 Loading Die-cut Labels..................4 Loading Fan-fold Labels.................. 5 Connecting the Communication Cable ............5 Using the LCD Display and Control Panel............
  • Page 4: Overview

    Overview Front View Context-sensitive keys Paper exit chute Front door release button Tear plate (for label) Peel roller Peel bar Tear bar (for liner) Gap/black mark sensor Platen Supply Li-ion holder battery Graphic LCD with Peel-off back lit display enabler...
  • Page 5: Rear View

    Rear View RS-232 interface +5V/DTR switch Hinged cable door interface Strap button Power jack chute Fan fold paper entrance chute Installing the Battery 1. Open the supply door by pulling outward on the release buttons located on either side of the printer. The supply door should swing open. 2.
  • Page 6: Using The Strap

    Using the Strap Clip both rings of the hand strap onto the strap buttons by placing each O-ring over the strap button and gently pulling up on the strap until the strap locks into place. Hand Strap strap button O-rings Loading Media Loading Continuous Labels for Receipt Paper 1.
  • Page 7: Loading Die-Cut Labels

    Loading Die-cut Labels 1. Open the supply door by pulling outward on the release buttons on both sides of the printer. 2. Lift up the peel off enablers on both sides. 3. Pull supply holder tabs apart. 4. Insert a roll of labels. Make sure the supply unwinds from the top as shown. Note: Calibrate the gap/black mark sensor when changing media.
  • Page 8: Loading Fan-Fold Labels

    Loading Fan-fold Labels 1. Open the supply door by pulling outward on the release buttons on both sides of the printer. 2. Pull supply holder tabs apart to insert a 3” paper core to keep supply holder wide open. 3. Insert the fan-fold paper through the fan-fold paper entrance chute and pass over the paper exit chute.
  • Page 9: Using The Lcd Display And Control Panel

    Using the LCD Display and Control Panel LCD display Navigation buttons On/Off button Feed/Ready button Turns the printer on and off. Advances label or returns the display to the previous menu. Three buttons for selecting options on the display. Charging the Battery 1.
  • Page 10: Maintenance

    Note: It takes 2 to 3 hours to fully charge the battery before the first time usage. The lifetime of the battery is 300 times for charge/discharge cycles. Maintenance 1. Please use one of following material to clean the printer. Cotton swab Lint-free cloth Vacuum...
  • Page 11 Platen roller Gap/black mark sensor Peel bar Peel-off sensor Note: Do not touch printer head by hand. If you touch it careless, please use ethanol to clean it. It’s industry alcohol. Please do not use regular alcohol, which may damage the printer head.
  • Page 12: Troubleshooting

    Troubleshooting The following guide lists the most common problems that may be encountered when operating this printer. If the printer still does not function after all suggested solutions have been invoked, please contact the Customer Service Department of your purchased reseller or distributor for assistance. Problem Possible Cause Recovery Procedure...
  • Page 13 For more information and features about this printer, please refer to the User’s Manual inside the CD disk.
  • Page 14 P/N : 39-0000144-10LF...
