Room controller display compact module
Room controller display compact module
Art. No. : ..519.. KRMTSD
Operating instructions
1 Safety instructions
Electrical devices may only be mounted and connected by electrically skilled
persons.
Serious injuries, fire or property damage possible. Please read and follow manual fully.
Use only the enclosed plastic screws for fastening to the supporting frame! Otherwise
safe operation cannot be ensured. Electrostatic discharges can cause defects in the
device.
These instructions are an integral part of the product, and must remain with the end
customer.
2 Function
System information
This device is a product of the KNX system and complies with the KNX directives. Detailed
technical knowledge obtained in KNX training courses is a prerequisite to proper understanding.
The function of this device depends upon the software. Detailed information on loadable
software and attainable functionality as well as the software itself can be obtained from the
manufacturer´s product database. Planning, installation and commissioning of the device are
carried out with the aid of KNX-certified software. The latest versions of product database and
the technical descriptions are available on our website.
Intended use
-
Operation of loads, e.g. light on/off, dimming, blinds up/down, brightness values,
temperatures, calling up and saving light scenes, etc.
-
Measurement and feedback control of the room temperature
-
Installation in appliance box according to DIN 49073
Product characteristics
All buttons can be assigned with push-button sensor functions or functions for controller
operation.
-
Back-lit LC display
-
One or two functions per button
-
Completion with keyset
-
Eight status LEDs – red, green or blue
-
Brightness of Status LEDs and LED adjustable
-
Integrated bus coupling unit
-
Connection to room controller or push-button extension module
-
Integrated room temperature sensor
-
Remote sensor can be connected
-
Room temperature control with setpoint value specification
-
Two internal independent controllers to control two independent rooms - in conjunction with
extension modules
-
Display of room or setpoint temperature (°C or °F)
-
Display of outdoor temperature – with external sensor, e.g. weather station
-
Display of time, in conjunction with KNX time encoder
-
Push-button function or rockers function
-
Disabling function: Disable or function switch-over of all or of individual pushbutton
functions
-
Alarm function, optionally with confirmation by pressing any button
32593503
j0082593503
1/7
23.02.2016
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Jung KNX 519 KRMTSD Series
Summary of Contents for Jung KNX 519 KRMTSD Series
- Page 1 Room controller display compact module Room controller display compact module Art. No. : ..519.. KRMTSD Operating instructions 1 Safety instructions Electrical devices may only be mounted and connected by electrically skilled persons. Serious injuries, fire or property damage possible. Please read and follow manual fully. Use only the enclosed plastic screws for fastening to the supporting frame! Otherwise safe operation cannot be ensured.
-
Page 2: Operation
Room controller display compact module 3 Operation Operating a function or load Switch: Short press on button. Dim: Long press on the button. Move Venetian blind: Long press on button. Stop or adjust Venetian blind: Short press on button. Call up light scene: Short press on button. Save light scene: Long press on button. - Page 3 Room controller display compact module Displaying the current room temperature Displaying the current temperature setpoint Displaying the current outdoor temperature The following menu items can be used to exit the submenu: Stor – Exit and save settings ESC – Exit without saving settings Opening and operating a menu Figure 1: Opening or exiting a menu Precondition: The menu is programmed and not disabled.
-
Page 4: Information For Electrically Skilled Persons
Room controller display compact module 4 Information for electrically skilled persons DANGER! Electrical shock on contact with live parts in the installation environment. Electrical shocks can be fatal. Before working on the device, disconnect the power supply and cover up live parts in the working environment. - Page 5 Room controller display compact module (5) Buttons (6) Connection terminal for extension module (optional) (7) KNX connection terminal (8) Box screws (9) Remote sensor connection (optional) CAUTION! Device defect if KNX voltage is applied between one of the KNX terminals and one of the other connections.
-
Page 6: Technical Data
Room controller display compact module Figure 5: Activating programming mode Activate programming mode: Press and hold push-button at the upper left (10). Then press push-button at the lower right (11). The top Status LEDs flash: blue | red | blue | red; 4 Hz. The display alternately shows Prog and the firmware version. - Page 7 Room controller display compact module ALBRECHT JUNG GMBH & CO. KG Volmestraße 1 58579 Schalksmühle GERMANY Telefon: +49 2355 806-0 Telefax: +49 2355 806-204 kundencenter@jung.de www.jung.de 32593503 23.02.2016 j0082593503...
