Instruction Manual
SM7860-01
-07
to
SM7860-21
-27
to
POWER SOURCE UNIT
February 2012 Revised edition 1 SM7860A981-01 12-02H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM7860-01 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hioki SM7860-01

Summary of Contents for Hioki SM7860-01

  • Page 1 Instruction Manual SM7860-01 SM7860-21 POWER SOURCE UNIT February 2012 Revised edition 1 SM7860A981-01 12-02H...

  • Page 3: Table Of Contents

    Contents Contents Introduction.................1 Confirming Package Contents............1 Safety Information ..............2 Operating Precautions..............3 Chapter 1 Overview ___________________________________ 7 Product Overview and Features ......... 7 Names and Functions of Parts ..........8 Screen Layout ..............10 Chapter 2 Preparing to Use the Device and Supplying Power ___________________________ 11 Installation &...
  • Page 4 Contents Chapter 4 External Control ____________________________ 33 External Input/Output Connector and Signals ....33  Connector Type and Signal Pinouts ..........34  Signal Descriptions ................35 Timing Chart ..............36 Internal Circuitry ..............38 Chapter 5 Specifications ______________________________ 39 General Specifications ............

  • Page 5: Contents

    Introduction Introduction Thank you for purchasing the HIOKI Model SM7860 series Power Source Unit. To obtain maximum performance from the device, please read this manual first, and keep it handy for future reference. Confirming Package Contents When you receive the device, inspect it carefully to ensure that no damage occurred during shipping.

  • Page 6: Safety Information

    Safety Information Safety Information This device is designed to comply with IEC 61010 Safety Standards, and has been thoroughly tested for safety prior to shipment. However, mishan- dling during use could result in injury or death, as well as damage to the device.

  • Page 7: Operating Precautions

    Before using the device for the first time, verify that it operates normally to ensure that no damage occurred during storage or shipping. If you find any dam- age, contact your dealer or Hioki representative. Device Installation Operating temperature and humidity : 0 to 40°C at 80%RH or less (non-condensing)
  • Page 8 Operating Precautions Installing To prevent overheating, be sure to leave the specified clearances around the unit. • Vents must not be obstructed. • When rack-mounting the device, fans must be installed above or on top of the rack to ensure proper ventilation. Be sure that the rack is adequately venti- lated so that the internal temperature remains at or below 40°C.
  • Page 9 Cable is undamaged and that no bare conductors are improperly exposed. Using the device in such conditions could cause an electric shock, so con- tact your dealer or Hioki representative for replacements. • Avoid stepping on or pinching cables, which could damage the cable insula- tion.
  • Page 10 Operating Precautions...

  • Page 11: Chapter 1 Overview

    Overview 1.1 Product Overview and Features The SM7860-01 to -07 and SM7860-21 to -27 are power supply units designed for use with the Model SM7810 or SM7810-20 Super MΩ HiTester. They support bipolar, multi-channel output and are compatible with multi-channel systems.

  • Page 12: Names And Functions Of Parts

    1.2 Names and Functions of Parts 1.2 Names and Functions of Parts Front Panel LCD screen Scroll keys (PAGE UP▲/ PAGE DOWN▼) The screen uses a 2-page Used to scroll through the display pages. layout to display setting val- "1.3 Screen Layout" (p.10) ues and setting status infor- The scroll keys are also used to set the GP-IB address.
  • Page 13 1.2 Names and Functions of Parts Side Panel Handle It should be moved by at least two people, who should grip it using the handles on the left and right sides. Vent Keep clear of obstructions.

  • Page 14: Screen Layout

    1.3 Screen Layout 1.3 Screen Layout The LCD screen consists of two display pages. When the SM7860 is turned on, page 1 is shown. The scroll keys on the front of the device (PAGE UP▲/ PAGE DOWN▼) are used to scroll among the display pages, which can also be selected directly by sending the “...

  • Page 15: Preparing To Use The Device And Supplying Power

    2.1 Installation & Connection Procedures Preparing to Use the Device and Supplying Chapter 2 Power 2.1 Installation & Connection Procedures Be sure to read the "Operating Precautions" (p.3) before installing and connecting this device. Front Panel Rear Panel Be sure to complete the pre-oper- Install this device (p.3) ation inspection (p.14) before using the device...

  • Page 16: Connecting The Power Cord

    Using the device in such conditions could cause an electric shock, so contact your dealer or Hioki representative for replacements. To avoid damaging the power cord, grasp the plug, not the cord, when unplug- ging it from the power outlet.

  • Page 17: Connecting The Device To The Measuring Instrument

    2.3 Connecting the Device to the Measuring Instrument 2.3 Connecting the Device to the Measuring Instrument To avoid electric shock or damage to the equipment, always observe the following precautions when connecting to voltage output terminal. • Always turn off the power to the device and to any devices to be con- nected before connecting the voltage output connectors.

  • Page 18: Pre-Operation Inspection

    2.4 Pre-Operation Inspection Before using the device the first time, verify that it operates normally to ensure that the no damage occurred during storage or shipping. If you find any damage, contact your dealer or Hioki representative. Peripheral Device Inspection Metal Exposed Do not use a damaged cord because •...

  • Page 19: Turning The Power On And Off

    2.5 Turning the Power On and Off 2.5 Turning the Power On and Off • Before turning the device on, make sure the supply voltage matches that indicated on its power connector. Connection to an improper supply volt- age may damage the device and present an electrical hazard. •...

  • Page 20: Setting The Operating Conditions

    2.6 Setting the Operating Conditions 2.6 Setting the Operating Conditions This section describes how to set the operating conditions according to the man- ner in which the device is to be used. Settings are configured via either of the device’s external interfaces: See: GP-IB/RS-232C Interface (p.17) The device cannot be configured directly in a standalone manner.

  • Page 21: Communication (Gp-Ib/Rs-232C Interface)

    3.1 Overview and Features Communication Chapter 3 (GP-IB/RS-232C Interface) The symbol shown below indicates that the following instructions are specific to the RS-232C or the GP-IB interface. Instructions without these symbols are for both the RS-232C and the GP-IB interface. : GP-IB only : RS-232C only Before Use...

  • Page 22: Specifications

    3.2 Specifications 3.2 Specifications Precautions RS-232C and GP-IB communications cannot be used simultaneously. GP-IB Specifica- Electrical machinery specifications: IEEE std. 488.1-1987 compliant tions Address setting : Can be set to talker/listener addresses 1 to 30. Interface Functions ● All Source Handshake functions ●...

  • Page 23: Connect A Cable To The Gp-Ib Connector Or Rs-232C Connector

    Using the GP-IB Interface Connect the GP-IB cable to the GP-IB connector. Rear Panel Recommended cable: HIOKI Model 9151-02 GP-IB Connector Cable (2 m) Using the RS-232C Interface Connect the RS-232C cable to the RS-232C connector. Rear Panel 1 2 3 4 5...
  • Page 24 When connecting the device to a computer Use a crossover cable with female 9-pin D-sub connectors. Crossover Wiring Female 9-pin Female 9-pin Recommended cable: D-sub D-sub Model SM7860 PC/AT-end HIOKI Model 9637 RS-232C Pin No. Pin No. Cable (1.8 m)

  • Page 25: Configuring The Communications Protocol

    3.4 Configuring the Communications Protocol 3.4 Configuring the Communications Protocol Configuring GP-IB Interface Communications Setting the address Press and hold the scroll keys ( ) on the front of the device PAGE UP▲ PAGE DOWN▼ for about 7 seconds. (The address can be set from the P1 or P2 screen.) ■...

  • Page 26: Communication Methods

    3.5 Communication Methods 3.5 Communication Methods Various messages are supported for controlling the device through the interfaces. Messages can be either program messages, sent from the controller such as PC to the device, or response messages, sent from the device to the controller. Program Messages Message types are further categorized as follows Command Message...
  • Page 27 3.5 Communication Methods Separators 1. Message Unit Separator Multiple message can be written in one line by separating them with semicolons “ ” 2. Header Separator In a message consisting of both a header and data, the header is separated from the data by a space “...
  • Page 28 3.5 Communication Methods Status Byte Register RS-232C reads the status bytes to find out the status of the device. The device adopts the IEEE488.1-1987 defined status model for parts related to the serial polling performed by the service request function. A trigger for generating a service request is called an event.
  • Page 29 3.5 Communication Methods Status Byte Register (STB)_______________________________________ A status byte register is an 8-bit register output from the unit to the controller during serial polling. If even one of the status byte register bits enabled by the service request enable register changes from "0" to "1" the MSS bit becomes 1. At the same time, the RQS bit also becomes "1"...

  • Page 30: Event Registers

    3.5 Communication Methods Event Registers Standard Event Status Register (SESR) ____________________________ A standard event status register is an 8-bit register. If any bit in the Standard Event Status Register is set to 1 (after masking by the Standard Event Status Enable Register), bit 5 (ESB) of the Status Byte Register is set to 1.
  • Page 31 3.5 Communication Methods Standard Event Status Enable Register (SESER) ____________________ Setting any bit of the Standard Event Status Enable Register to 1 enables access to the corresponding bit of the Standard Event Status Register. Standard Event Status Register (SESR) and Standard Event Status Enable Register (SESER) bit 6 bit 5...

  • Page 32: Error Registers

    3.5 Communication Methods Error Registers The Error Register, which consists of 8 bits, manages error information. The contents of this register are aggregated in the CME, EXE, DDE, and QYE bits of the Standard Event Status Register (no mask processing is performed). Error register-related message are listed below.

  • Page 33: Message List

    VBI? VBI? The contents of responses are the same as the settings. [Response] d1 Output voltage setting range by model Model Lower limit (V) Upper limit (V) SM7860-01, -21 500.0 SM7860-02, -22 250.0 1000.0 SM7860-03, -23 500.0 SM7860-04, -24 250.0 1000.0...
  • Page 34 *IDN? Hardware ID query *IDN? [Format] Returns the device’s hardware ID as the response. [Response] d1: String d1 (HIOKI, SM7860-XX, 0, 01.00) Note: The SM7860-2X is shown as "SM7860-0X." *SAV Save environmental data *SAV d1 [Format] (output voltage setting and alarm setting) d1: NR1 format d1 (Environmental data no.: 0 to 3)
  • Page 35 3.6 Message List Command Description Formats *OPC Sets the standard event status register’s OPC bit after all ongoing *OPC [Format] operations have completed. This command is used to detect the completion of commands that involve time-consuming processing. *OPC? *OPC? Returns the value 1 when all ongoing operations have completed. [Format] d1: 1 [Response] d1: NR1 format...

  • Page 36: Listener Specification Precautions

    3.7 Listener Specification Precautions 3.7 Listener Specification Precautions Input buffer size Multiple command messages can be transferred at once by joining them with message separators. Since the instrument provides an 128-byte input buffer, the instrument is unable to receive message strings in excess of 127 characters in length.

  • Page 37: Chapter 4 External Control

    4.1 External Input/Output Connector and Signals Chapter 4 External Control This chapter describes how to use the EXT I/O connector on the rear of the device to control the device. Connect the device’s EXT I/O connector to the signal output or input device.
  • Page 38 4.1 External Input/Output Connector and Signals Connector Type and Signal Pinouts Rear Panel Connector EXT I/O connector • 57RE-40500-730B (50-pin: DDK) Signal name Signal name EXT_DCV2(+24V) Input EXT_DCV2(+24V) Input OUTPUT Input INTERLOCK Input OUT1(1)_ON Input OUT1(2)_ON Input OUT1(3)_ON Input OUT1(4)_ON Input OUT1(5)_ON Input...
  • Page 39 4.1 External Input/Output Connector and Signals Signal Descriptions Input Signals EXT_DCV2(+24V) External power source input OUTPUT Output on/off setting OUT 1(1)_ON to OUT 1(8)_ON Channel-specific on/off setting OUT 2(1)_ON to OUT 2(8)_ON Channel-specific on/off setting OUT 3(1)_ON to OUT 3(8)_ON Channel-specific on/off setting OUT 4(1)_ON to OUT 4(8)_ON Channel-specific on/off setting...

  • Page 40: Timing Chart

    SM7860-03, 04, 05, 06, -23, 24, 25, 26 : OUT1 to OUT2 SM7860-07, -27 : OUT1 to OUT3 *2: SM7860-01, 02, 05, 06, -21, 22, 25, 26 : OUT3 SM7860-03, 04, -23, 24 : OUT3 to OUT4 *3: SM7860-05, 06, -25, 26...
  • Page 41 4.2 Timing Chart Timing Chart Interval Descriptions Interval Description Duration 100 μ s or more Channel setup time 200 μ s or more Channel hold time → 200 μ s or less OUTPUT ON Busy delay time → 600 μ s or less OUTPUT ON Voltage output delay time Alarm delay time...

  • Page 42: Internal Circuitry

    4.3 Internal Circuitry 4.3 Internal Circuitry Input Circuit 24 VDC EXT_DC2 Input signals SM7860 side External device side Output Circuit 5 to 24 VDC Output signals External device side SM7860 side Input Signals Input method Photocoupler-isolated input Input voltage LOW: 0 to 0.5 V, HIGH: 24 V±10% Output Signals Output method Photocoupler-open collector output...

  • Page 43: Chapter 5 Specifications

    Dimensions Approx. 425W × 249H × 581D mm (16.73"W × 9.80"H × 22.87"D) Mass Approx. 45 kg (1587.3 oz.) (SM7860-01, 02, 03, 04, 05, 06, 21, 22, 23, 24, 25, 26) Approx. 32 kg (1128.7 oz.) (SM7860-07, 27) Accessories Power Cord................1 Instruction manual ..............1...

  • Page 44: Basic Specifications

    1.0 V to 500.0 V -1.0 V to -500.0 V Output voltage range (0.1 V resolution) (0.1 V resolution) SM7860-01 SM7860-21 OUT 1 (1) to (8): Voltage output OUT 3 (1) to (8): Voltage output Channels OUT 2 (1) to (8): None...
  • Page 45 LED indicator POWER, Voltage output, Inter-lock LCD screen P1: Output voltage setting, monitor voltage value, channel-specific output setting state P2: Alarm setting, GP-IB address HIOKI Model SM7810, SM7810-20 Super M Ω HiTester Supported model Functions Voltage output function Operating method...
  • Page 46 Charging interval must be greater than or equal to the time calculated from the graphs shown in Figure 1 and Figure 2 below. (Continuous charging is not supported.) Figure 1: Charging Interval by Applied Voltage and Capacity (SM7860-01, 03, 05, 07, 21, 23, 25, 27) Applied voltage 印加電圧...
  • Page 47 5.2 Basic Specifications Graph description and operating precautions Because the SM7860 is designed to be embedded in an automated system in applications in which it charges capacitors, it cannot be used with a continuous load. Figures 1 and 2 define the minimum cycle times at which this automated system can operate based on the output voltage and capacitor capacitance.

  • Page 48: Input / Output Functions

    5.3 Input / Output Functions 5.3 Input / Output Functions GP-IB Interface Data reception Output voltage setting, output on/off, voltage error alarm setting Data transmission Setting read access, error description RS-232C Interface Data reception Output voltage setting, output on/off, voltage error alarm setting Setting read access, error description Data transmission Communication conditions...

  • Page 49: Maintenance And Service

    Do not attempt to modify, disassemble or repair the device; as fire, electric shock and injury could result. If the device seems to be malfunctioning, confirm that "If the unit malfunctions/ before you have it repaired" (p.46) before contacting your dealer or Hioki repre- sentative. Transporting Pack the device so that it will not sustain damage during shipping, and include a description of existing damage.
  • Page 50 Does the voltage output indicator light up when output is turned on? No voltage is being output The unit's protective circuitry may have Please contact your dealer or Hioki representa- p.10 from the voltage output been triggered due to a failure.

  • Page 51: Replacing The Power Fuse

    6.2 Replacing the Power Fuse 6.2 Replacing the Power Fuse • To avoid electric shock, turn off the power switch and disconnect the connection cables before replacing the fuse. • Replace the fuse only with one of the specified characteristics and volt- age and current ratings.

  • Page 52: Error Displays

    6.3 Error Displays 6.3 Error Displays Error Display Description Remedy Please contact your dealer or Hioki repre- ERROR:001 Call Service Center Backup data corrupt sentative. Please contact your dealer or Hioki repre- ERROR:002 Call Service Center Backup data write failure sentative.
