Return this Specification to SMC after stamping of signing in the column of Signature
of reception. This Specification is recognized to be accepted if no reply for 20 days
from the date of issue of SMC.

l
i
v
e
r
y
l
i
v
e
r
y
Thermo Electric Bath
Product Description
HEBC002-WA10
HEBC002-WB10
Model no. / Series / Part no.
Signature of reception
Doc. No
1
Rev. date
S
p
e
c
i
f
S
p
e
c
i
f
A_HEC-PS-J009
st
edit. date
Mar.28
i
c
a
t
i
o
n
i
c
a
t
i
o
n
SMC date stamp
Prepared by: PD Div. 6
Appr'd
Chk'd
Sakama
Saika
PD Div. 6
PD Div. 6
th
2006
Prep'd
Ono
PD Div. 6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HEBC002-WA10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SMC Networks HEBC002-WA10

  • Page 1 Mar.28 2006 Rev. date Thermo Electric Bath Product Description HEBC002-WA10 HEBC002-WB10 Model no. / Series / Part no.       Return this Specification to SMC after stamping of signing in the column of Signature of reception. This Specification is recognized to be accepted if no reply for 20 days from the date of issue of SMC.
  • Page 2   Revision History Rev. Date Reason for revision Appr'd Prep'd Note...
  • Page 4: Table Of Contents

      Contents                                                                         Page 1. Scope  ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 2.
  • Page 5: Scope

    1.  Scope 1) This Specifications explains an electronic cooling/heating contant temperature bath “Thermo Electric Bath”. 2) The manufactured range is as shown on the figure below. Preapare other items than listed on section 6-2 by customer itself separately. Master computer Communication Signal cable Alarm output...
  • Page 6: Period And Scope Of Warranty

    Part name: Fan Capable life: 5 to 10 years Possible failure: The capacity of the fan lowers due to the end of lubricating performance of the bearing, which results in increase of internal temperature of the Controller.                   The overheat protective function at the inside of the power supply starts, the outputs stops and the display goes off.
  • Page 7: How To Order And Manufacturing Code Indication

    (5)  Disclaimer ① Expenses to compensate for secondary damages to other equipment and goods due to the failure of the product ② Expenses for repairs performed by other companies ③ Expenses for transfer, installation and removal of the product ④ Expenses for replacement of parts other than those in the product and for the supply of liquids ⑤...
  • Page 8 4-2. Manufacturing code indication The date of manufacturing can be found on the model number plate attached to this product. SERIAL No.K O−0001 (JAN.2006) Mfg. year Mfg. month Serial No. Mfg. month O : Jan.   U : Jul. Mfg. year P : Feb.   V : Aug. K :...
  • Page 9: Specifications

    5.  Specifications Table1 Thermo Electric Bath specifications Part No. HEBC002-WA10 HEBC002-WB10 Control method Cooling/heating automatic shift PWM control Cooling / Heating method Thermoelectric device (Thermo-module) Liquid Tank Water-cooled Radiating method Controller Forcible air-cooled Operating temp. range -15.0 to 60.0 C (5 C or more for water) (Note 1) (Note 5) ±0.1...
  • Page 10 Note 1) Differs depending on operating conditions. Note2) Determined under the following conditions: water as the recirculating fluid, set temperature 25℃, cooling water temperature 25℃, flow rate 3L/min, ambient temperature 25℃, and sealed from outside air with a lid. ○ Note 3) GALDEN is a trade mark of Solvay Solexis and Fluorinert is a trade mark of 3M.
  • Page 11: Packaging And Deliverables

    6.  Packaging and Deliverables 6-1. Packaging ・One Liquid Tank and Controller are packaged into one box for delivery. ・The product is packaged with a vinyl bag for delivery. ・Accessories such as a power supply cable and Operation Manual are packaged together. ・...
  • Page 12: Functions

    8.  Functions 1) Auto tuning function This function automatically adjusts the PID values (proportional band, integrating time, and derivative time) necessary for control. Appropriate PID values are input at the time of shipment from the factory. If the temperature deviation is found at these values on a regular basis, try to perform auto tuning.
  • Page 13 4) Set Value Memory (EEPROM back-up) This function memorizes all set values input via the operation and display panel to nonvolatile memory EEPROM as back-up. Even if the power supply is turned off, the settings remain and do not need to be reset when the power supply is restarted.
  • Page 14 PID values before auto tuning.   7)Communication Function ・HEBC002-WA10 This product has a communication function conforming to communication protocol RS-485. The transmission cable length, i.e., transmittable distance, is 500m. RS-485 enables one master computer to set and monitor operation conditions of up to 31 Thermo Electric Baths.
  • Page 15: Outline Dimensions

    9.  Outline Dimensions   The detail can be found on specifications. Fig. 2 Liquid Tank Fig. 3 Internal dimensions of Liquid Tank Fig. 4 Controller - 11 -...
  • Page 16: Performance Chart

    10.  Performance Chart The values shown on the performance chart are representative and not guaranteed. Allow a margin for safety to decide use of the product. 1)Cooling capacity Ambient temperature : 25 ℃ ○ Recirculating fluid : GALDEN HT200 Recirculating fluid level : 180 ㎜ (At recirculating fluid temp. 25 ℃ ) Cooling water flow rate :...
  • Page 17: Communication

    Any set value input via the communication function is not stored. If they need to be stored, use a storage request message. 11-2.  Communication Details of the communication format can be found on the Operation Manual. Table6  Communication HEBC002-WA10 HEBC002-WB10 Protocol RS-485 RS-232C...
  • Page 18: Precautions On Handling

    12.  Precautions on handling       Caution Keep the precautions to prevent accidents accompanying injury and a failure of the product resulting in peripheral equipment damage. 1) Surrounding environment and Set-up Environment (1) Do not use this product in the following environments. ① ...
  • Page 19 2) Power Supply and Grounding (1) Terminate the power supply cable in a manner suitable to the specifications of the connected equipment. This product must be supplied with power through a branch protective circuit and earth leakage breaker rated at 15A or less. Terminate the power supply cable in a manner suitable to the specifications of the connected equipment.
  • Page 20 6) Maintenance check (1) Action for abnormality If any abnormality such as noise, smoke and odor is found, turn off the power supply immediately and stop the cooling water supply to stop the product, and ask for repair. (2) Prohibition of decomposing and remodeling Do not disassemble and retrofit the product by removing the panel to prevent electric shock, burns and injuries.
  • Page 21: Connectors

    13.  Connectors       Caution The power supply cable and connection cable are specific for the Thermo Electric Bath. Do not use them to others. Prepare mating connectors for communication connector and alarm output connector by customer separately. 13-1.  Connection of Liquid Tank and Controller ・Liquid Tank connector DC connector (male) Signal connector (male)
  • Page 22 13-2,  Connection of power supply cable ・Controller connector Power supply connector IEC60320  C-14 equivalent Male Connected ・Power supply cable Controller side IEC60320  C-13 equivalent Female AWG14 Content Black 1 AC100-240V (L) Black 2 AC100-240V (N) Green/Yellow PE - 18 -...
  • Page 23 Output cutoff alarm contact (opened for alarm)   Output cutoff alarm common Unused Communication connector Hirose Electric co.,Ltd: CDE-9S  Fixed screw M2.6 Mating connector: CDE-9P equivalent  Content Pin no. HEBC002-WA10 HEBC002-WB10 RS-485  T/R(A) Unused RS-485  T/R(B) RS-232C  RX Unused RS-232C  TX Unused...
  • Page 24: Flow Sheet

    14.  Flow sheet Thermo-module Liquid Tank Controller Thermostat Communication connector RS-485 or RS-232C Tank Signal connector Alarm output connector Recirculating pump DC output AC100 connector to 240V Temperature sensor Cooling water outlet Cooling water inlet Fig. 7 Flow sheet - 20 -...
