PISO-1730U Card
User Manual
32-ch Optically Isolated DIO Board (Sink, NPN)
S
UPPORTS
Board includes PISO-1730U.
W
ARRANTY
All products manufactured by ICP DAS are warranted against defective
materials for a period of one year from the date of delivery to the original
purchaser.
W
ARNING
ICP DAS assumes no liability for damages consequent to the use of this
product. ICP DAS reserves the right to change this manual at any time
without notice. The information furnished by ICP DAS is believed to be
accurate and reliable. However, no responsibility is assumed by ICP DAS for
its use, nor for any infringements of patents or other rights of third parties
resulting from its use.
C
OPYRIGHT
Copyright © 2013 by ICP DAS. All rights are reserved.
T
RADEMARK
Names are used for identification only and may be registered trademarks of
their respective companies.
C
U
ONTACT
S
If you have any question, please feel to contact us. We will give you quick
response within 2 workdays.
Email: service@icpdas.com, service.icpdas@gmail.com
Version 1.2, Jan. 2015

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PISO-1730U and is the answer not in the manual?

Questions and answers

Related Manuals for ICP DAS USA PISO-1730U

Summary of Contents for ICP DAS USA PISO-1730U

  • Page 1 32-ch Optically Isolated DIO Board (Sink, NPN) Version 1.2, Jan. 2015 UPPORTS Board includes PISO-1730U. ARRANTY All products manufactured by ICP DAS are warranted against defective materials for a period of one year from the date of delivery to the original purchaser.

  • Page 2: Table Of Contents

    RIVER NSTALLING ROCEDURE ........................16 RIVER NSTALLATION ..........................18 ONFIRM THE UCCESSFUL NSTALLATION ......................21 TESTING PISO-1730U CARD ........................22 IRING ............................22 XECUTE THE ROGRAM ........................... 24 I/O CONTROL REGISTER .......................... 26 I/O A OW TO IND THE DDRESS ........................
  • Page 3 PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 6.3.4 INT Mask Control Register ........................... 31 6.3.5 Aux Status Register ............................31 6.3.6 Interrupt Polarity Register ........................... 31 6.3.7 Read/Write 8-bit Data Register ........................32 6.3.7 Read D/O Readback ............................. 32 6.3.9 Read Card ID Register...

  • Page 4: Packing List

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) Packing List The shipping package includes the following items: One PISO-1730U card hardware  Note!! One printed Quick Start Guide  If any of these items is One software utility CD missing or damaged, contact ...

  • Page 5: Introduction

    The PISO-1730U provides a Card ID switch. Users can set Card ID on a board and recognize the board by the ID via software when using two or more PIO-1730U cards in one computer.

  • Page 6: Specifications

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 1.2 Specifications Digital Input Isolation Voltage 3750 V (Using external power) Channels Sink or Source, Compatibility Photo coupler isolated channel with common power or ground Logic 0: 0 ~ 1 V...

  • Page 7: Hardware Configuration

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 2. Hardware Configuration 2.1 Board Layout PISO-1730U CON1 (D/O) CON2 (D/I) Isolation Bank DO Channel Power Ground Isolation Bank 0 DO_0~7 (CON1, Pin 05) (CON1, Pin19) Isolation Bank 1 DO_8~15 (CON1, Pin 28)

  • Page 8: Card Id Switch

    32-ch Optically Isolated DIO Board (Sink, NPN) 2.2 Card ID Switch The PISO-1730U has a Card ID switch (SW1) with which users can recognize the board by the ID via software when using two or more PISO-1730U cards in one computer. The default Card ID is 0x0.

  • Page 9: Pin Assignments

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 2.3 Pin Assignments CON1: 37-pin D-type female connector (Digital Output Connector).  CON2: 40-pin flat-cable connector (Digital Input Connector).  Extension Cable (CA-4037B): DB-40-Pin conversion DB-37-Pin Figure 2-1 User Manual/ Ver. 1.2/ Jan. 2015/ PMH-0025-11/ Page: 8...

  • Page 10: Isolated Dio Architecture

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 2.4 Isolated DIO Architecture The digital output and digital input (DIO) function supports external power mode. The DIO various configurations and wiring note is illustrated in the figure below. 2.4.1 Isolated D/I Architecture Isolated D/I Architecture with external power supply.

  • Page 11: Isolated D/O Architecture

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 2.4.2 Isolated D/O Architecture Isolated D/O Architecture. (Current Sinking)  (+) External Power 390 R R=6.8K D out (External) D out O.C. R=10K (-) GND External Power PISO-1730U Typical Application of D/O. (Current Sinking) ...

  • Page 12: Open Collector Wiring Notice

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 2.4.3 Open Collector Wiring Notice External Power Low Drive External Power (+) Channel R=3.9K Sink current 10V~30V 100mA External O.C. Out => 2N2222 Device R=10K Diode (-) GND PISO-1730U External Power (-)

  • Page 13: Hardware Installation

    This reduces the times to restart the computer. To install your PISO-1730U card, complete the following steps: Step 1: Installing PISO-1730U card driver on your computer first. detailed information...
  • Page 14 PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) Step 3: Shut down and power off your computer. Step 4: Remove all covers from the computer. Step 5: Select an empty PCI slot. User Manual/ Ver. 1.2/ Jan. 2015/ PMH-0025-11/ Page: 13...
  • Page 15 Step 6: Remove the PCI slot cover form the PC. Step 7: Remove the connector cover form the PISO-1730U card. Step 8: Carefully insert your PISO-1730U card into the PCI slot. User Manual/ Ver. 1.2/ Jan. 2015/ PMH-0025-11/ Page: 14...
  • Page 16 PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) Step 9: Tighten the captive Phillips screw. Confirm the PISO-1730U card is mounted on the motherboard. Step 10: Replace the computer cover. Step 11: Power on the computer. Follow the prompt message to finish the Plug&Play steps, please refer to...

  • Page 17: Software Installation

    32-ch Optically Isolated DIO Board (Sink, NPN) 4. Software Installation The PISO-1730U can be used in DOS, Linux and Windows 98/NT/2K and 32-bit/64-bit Windows XP/2003/Vista/7/8. This chapter shows you the detail steps to install these drivers. The recommended installation procedure for Windows is given in Sec. 4.1 ~ 4.3.
  • Page 18 PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) Step 3: Please install the appropriate driver for your OS. Click the item: “UniDAQ”. Click the item: “DLL for Windows 2000 and XP/2003/Vista 32-bit”. Double-Click “UniDAQ_Win_Setup_x.x.x.x_xxxx.exe” file in the “Driver” folder.

  • Page 19: Pnp Driver Installation

    Software Manual. The user manual is contained in: CD:\NAPDOS\PCI\UniDAQ\Manual\ http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/unidaq/manual/ 4.2 PnP Driver Installation Step 1: Turn off the computer and install the PISO-1730U card into the computer. For detailed information about the hardware installation of PISO-1730U card, please refer to Chapter 3 Hardware Installation.
  • Page 20 PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) Step 2: Power on the computer and system should find the new card and then continue to finish the Plug&Play steps. Note: Some Windows OS will load the driver automatically to complete the installation at boot.
  • Page 21 PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) Step 4: Click the “Finish” button. Step 5: Windows pops up “Found New Hardware” dialog box again. User Manual/ Ver. 1.2/ Jan. 2015/ PMH-0025-11/ Page: 20...

  • Page 22: Confirm The Successful Installation

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 4.3 Confirm the Successful Installation Make sure the PISO-1730U card installed is correct on the computer as follows: Step 1: Select the “Start”  “Control Panel” and then double click the “System”...

  • Page 23: Testing Piso-1730U Card

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 5. Testing PISO-1730U Card This chapter can give you the detail steps about self-test. In this way, user can confirm that PISO-1730 card well or not. Before the self-test, you must complete the hardware and driver installation.
  • Page 24 5. Power Supply (+24 V) connect to PCOM (Pin05) of the CON1/CON2. Power Supply GND connect to EGND (Pin19) of the CON1/CON2. Note: T he PISO-1730U suggests input voltage range as follow: Logic high: +9 ~ +24 V; Logic Low: 0 ~ 1V.

  • Page 25: Execute The Test Program

    Click this button to start test. Confirm the PIO-P32C32 series card had successfully installed to PC. It start s from 0. Note!! The PISO-1730U software is fully compatible with the PISO-P32C32 series software. User Manual/ Ver. 1.2/ Jan. 2015/ PMH-0025-11/ Page: 24...
  • Page 26 PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 2. Get DIO function test result. Click “Digital Output” item. Check channel 0, 2, 4, 6 Port0: DO0-7 Port1: DO8-15 Port2: DO16-23 Select the “Port 0” Port3: DO24-31 Click “Digital Input” item.

  • Page 27: I/O Control Register

    6.1 How to Find the I/O Address The plug&play BIOS will assign a proper I/O address to every PIO/PISO series card in the power-on stage. The fixed IDs for the PISO-1730U card are given as follows: Table 6-1: PISO-1730U (Rev 1.0 )

  • Page 28: The Assignment Of I/O Address

    Step 3: Remove all PISO-1730U cards from the PC. Step 4: Install one PISO-1730U card into the PC’s PCI_slot2 and run PIO_PISO.EXE. Then record the wSlotBus2 and wSlotDevice2 information. Step 5: Repeat Steps(3) and (4) for every PCI_slot and record all information from wSlotBus and wSlotDevice.
  • Page 29 PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) The above procedure will record all the wSlotBus and wSlotDevice information on a PC. These values will be mapped to this PC’s physical slot and this mapping will not be changed for any PIO/PISO cards.

  • Page 30: The I/O Address Map

    32-ch Optically Isolated DIO Board (Sink, NPN) 6.3 The I/O Address Map The I/O address for PISO-1730U card is automatically assigned by the main board ROM BIOS. The I/O address can also be re-assigned by the user. It is strongly recommended that users do not change the I/O address.

  • Page 31: Reset\ Control Register

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 6.3.1 RESET\ Control Register (Read/Write): wBase+0 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Reserved Reserved Reserved Reserved Reserved Reserved Reserved RESET\ When the PC’s power is first turned on, RESET\ signal is in a Low-state. This will disable all D/I/O operations.

  • Page 32: Int Mask Control Register

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 6.3.4 INT Mask Control Register (Read/Write): wBase+5 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 This register is designed for future applications, please do not change this register.

  • Page 33: Read/Write 8-Bit Data Register

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 6.3.7 Read/Write 8-bit Data Register (Read/Write): wBase+0xc0/ 0xc4/ 0xc8/ 0xcc Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 For example: outportb(wBase+0xc0,Val); /* write to DO 0~7 */ outportb(wBase+0xc4,Val);...

  • Page 34: Read Card Id Register

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) 6.3.9 Read Card ID Register (Read): wBase+0xd0 Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 For example: wCardID=inportb(wBase+0xd0); /* Read Card ID */...

  • Page 35: Appendix: Digital I/O Applications

    External Device 1 External Device 2 Figure A-1. Digital inputs/outputs for the PISO-1730U  Figure A-2 (PISO-1730U) shows the circuit diagram for external device 1  Figure A-3 (PISO-1730U) shows the circuit diagram for external device 2 SWITCH User Manual/ Ver. 1.2/ Jan. 2015/ PMH-0025-11/ Page: 34...
  • Page 36 LED17 LED27 LED18 LED 9 Figure A-2. The circuit diagram for external device 1 for D/O of PISO-1730U  Pin 19 is the GND signal for EGND.  Pin 05/14/28/37 is the voltage (+) signal for P COM (input 5 V ~24 V User Manual/ Ver.
  • Page 37 DN-37 POWER Vlotage Output POWER Figure A-3. The DI circuit diagram for external device 2 of PISO-1730U  Pin 19 is the GND signal for E GND.  Pin 05/14/28/37 is the voltage (+) signal for E COM (input 5 V ~24 V User Manual/ Ver.

  • Page 38: Appendix: Daughter Board

    PISO-1730U Card 32-ch Optically Isolated DIO Board (Sink, NPN) Appendix: Daughter Board A1. DB-37 and DN-37 DB-37: The DB-37 is a general purpose daughter board for  D-sub 37 pins. It is designed for easy wire connection via pin-to-pin. DB-37...
