Configuration
Protocol Manual
Parameter Data Structure
SPC3 evaluates the first seven data bytes (without user prm data), or the first
eight data bytes (with user prm data). The first seven bytes are specified
according to the standard. The eighth byte is used for SPC3-specific
communications. The additional bytes are available to the application.
Byte Bit Position
7
0 Lock
Reg
1
2
3
4
5
6
7
8 to
243
Byte 7 Spec_User_Prm_Byte
Bit Name
0 Dis_Startbit
1 Dis_Stopbit
2 WD_Base
3 to 4 Res
5 Publisher_Enable
6 to 7 Res
Page 22 of 70
6 5 4 3
Unio Sync Free WD
Req Req Req on
Significance
The start bit monitoring in the
receiver is switched off with
this bit
Stop bit monitoring in the
receiver is switched off with
this bit
This bit specifies the time
base used to clock the
watchdog.
WD_Base = 0: time base 10
ms
WD_Base = 1: time base 1 ms
To be parameterized with 0
DXB-publisher-functionality of
the SPC3 is activated with this
bit
To be parameterized with 0
Designation
2 1 0
Res Res Res Station status
WD_Fact_1
WD_Fact_2
MinTSDR
Ident_Number_High
Ident_Number_Low
Group_Ident
Spec_User_Prm_Byte
User_Prm_Data
Default State
Dis_Startbit = 1,
That is, start bit monitoring is
switched off.
Dis_Stopbit = 0
That is, stop bit monitoring is not
switched off.
WD_Base = 0
That is, the time base is 10 ms.
0
Publisher_Enable = 0, DXB-
request-telegrams are ignored;
Publisher_Enable = 1, DXB-
request-telegramme are processed
0
