Cutting Mill SM100
Translation
© Retsch GmbH, 42781 Haan, Retsch-Allee 1-5, Germany | 13.01.2020 Version 0002

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Retsch SM100

  • Page 1 Manual Cutting Mill SM100 Translation © Retsch GmbH, 42781 Haan, Retsch-Allee 1-5, Germany | 13.01.2020 Version 0002...
  • Page 2 Copyright © Copyright by Retsch GmbH Retsch-Allee 1-5 42781 Haan Germany...
  • Page 3: Table Of Contents

    Table of Contents Notes on the Manual ..........................6 Explanations of the Safety Instructions ..................... 7 General Safety Instructions ....................... 8 Repairs ............................... 9 Confirmation ............................10 Packaging, Transport and Installation ....................11 Packaging ............................11 Transport............................11 Temperature fluctuations and condensed water ................11 Conditions for the Installation Site ....................
  • Page 5 Notes on the Manual...
  • Page 6: Notes On The Manual

    This operating manual does not contain any repair instructions. If faults arise or repairs are necessary, please contact your supplier or get in touch with Retsch GmbH directly. Application technology information relating to samples to be processed is not included but can be read on the Internet on the respective device’s page at www.retsch.com.
  • Page 7: Explanations Of The Safety Instructions

    Notes on the Manual 1.1 Explanations of the Safety Instructions In this Operating Manual we give you the following safety warnings Serious injury may result from failing to heed these safety warnings. We give you the following warnings and corresponding content. WARNING Type of danger / personal injury Source of danger...
  • Page 8: General Safety Instructions

    Target group : All persons concerned with the machine in any form This machine is a modern, high performance product from Retsch GmbH and complies with the state of the art. Operational safety is given if the machine is handled for the intended purpose and attention is given to this technical documentation.
  • Page 9: Repairs

    Notes on the Manual 1.3 Repairs This operating manual does not contain any repair instructions. For your own safety, repairs may only be carried out by Retsch GmbH or an authorized representative or by Retsch service engineers. In that case please inform:...
  • Page 10: Confirmation

    Confirmation Bes tätigung Confirmation This operating manual contains essential instructions for operating and maintaining the device which must be strictly observed. It is essential that they be read by the operator and by the qualified staff responsible for the device before the device is commissioned. This operating manual must be available and accessible at the place of use at all times.
  • Page 11: Packaging, Transport And Installation

    Packaging, Transport and Installation Packaging, Transport and Installation 3.1 Packaging The packaging has been adapted to the mode of transport. It complies with the generally applicable packaging guidelines. NOTICE Storage of packaging – In the event of a complaint or return, your warranty claims may be endangered if the packaging is inadequate or the machine has not been secured correctly.
  • Page 12: Electrical Connection

    Packaging, Transport and Installation NOTICE Atmospheric humidity – Electronic and mechanical components may be damaged and the performance data alter to an unknown extent. • Do not exceed the admissible range for atmospheric humidity. 3.5 Electrical Connection WARNING When connecting the power cable to the mains supply, use an external fuse that complies with the regulations applicable to the place of installation .
  • Page 13: Type Plate Description

    Packaging, Transport and Installation 3.6 Type Plate Description Fig. 1: Type plate lettering 1 Device designation 2 Year of production 3 Part number 4 Serial number 5 Manufacturer’s address 6 CE marking 7 Disposal label 8 Bar code 9 Power version 10 Mains frequency 11 Capacity 12 Amperage...
  • Page 14: Removing The Transportation Aid

    Packaging, Transport and Installation 3.7 Removing the Transportation Aid Fig. 2: Removing the transport aid Only use the transport aid (TH) when lifting the device. The device weighs approx. 73 kg. Select secure lifting equipment that is approved for this weight. Keep the eyebolt (TH) for transportation at a later date.
  • Page 15: Frame Assembly

    Packaging, Transport and Installation 3.8 Frame assembly Fig. 3: Components of the stand The components come pre-assembled to simplify assembly of the frame. Fig. 4: Assembling the crossbar • Where necessary slightly loosen the four screws (TS) on the crossbar (TR). •...
  • Page 16 Packaging, Transport and Installation Fig. 5: Fastening the crossbar angle bracket NOTICE Ensure that the crossbar (TR) is aligned flush with the pre-assembled angle section (WS). Tighten the screw on the left and right of the angle section (SW). Fig. 6: Screwing the crossbar tight •...
  • Page 17 Packaging, Transport and Installation Fig. 7: Mounting the side protective caps • Place the four black plastic caps on the openings. Fig. 8: Mounting the front protective caps • Place the two caps on the ends of the roller track. Fig.
  • Page 18 Fig. 11: Screwing the stand onto the crossbar • Screw the stand (SQ) onto the crossbar. Fig. 12: Assembling the SM 100 • Then place the SM100 on the base frame. • Using the 4 screws, screw the SM100 housing tightly onto the base frame.
  • Page 19: Mounting The Feed Hopper

    Packaging, Transport and Installation 3.9 Mounting the Feed Hopper WARNING 1.W0004 Risk of injury to skin and hands Fast rotating cutting blade – There is a risk of injuring hands, fingers and skin. • Never operate the device without a feed hopper. NOTICE Transport safeguard –...
  • Page 20: Mounting The Feed Hopper

    Packaging, Transport and Installation 3.9.2 Mounting the Feed Hopper Fig. 14: Mounting the feed hopper • Open the grinding area door (T). • Pull the plunger (B) so it engages in the uppermost position. • Place the feed hopper (R) on the device (see diagram) CAUTION It is possible for the feed hopper (R) to fall from the device as long as it is not secured by the three socket screws.
  • Page 21: Installation Of The Device

    Packaging, Transport and Installation 3.10 Installation of the Device Installation height: maximum 2000 m above sea level NOTICE Installation – Depending on the operating status of the mill, there may be slight vibrations. • Place the mill on an even, flat and balanced supporting surface only. The supporting surface must be stable and must not vibrate.
  • Page 22 Packaging, Transport and Installation Fig. 15: Adjusting the height of the support structure Fig. 16: Adjusting the height of the support structure (detail) Designation SW17 open end wrench Top nut Bottom nut Set screw Proceed as follows to adjust the height of the support structure: •...
  • Page 23 Packaging, Transport and Installation 1 – 2° backwards tilt Front wheels Back wheels Fig. 17: Optimal alignment...
  • Page 24: Technical Data

    Technical Data Technical Data 4.1 Use of the Device for the Intended Purpose Target group: Operating companies, operators Designation of machine model: SM 100 This powerful cutting mill is used to grind elastic and fibrous products and product mixtures in batches or continuously.
  • Page 25: Emissions

    Technical Data 4.2 Emissions CAUTION Damage to hearing The level of noise can be high depending on the type of material, the knife used, the speed set and the duration of the grinding process. - Noise that is excessive in terms of level and duration can cause impaired or permanently damaged hearing.
  • Page 26: Dimensions And Weight

    Technical Data 4.7 Dimensions and Weight Height: 1675 mm Width: 582 mm Depth: 700 mm Weight: approx. 73 kg (without hopper, rotor and base frame) Fig. 18: Dimensions 4.8 Required Floor Space 1090 mm x 765 mm – no safety distances necessary...
  • Page 27: Operating The Device

    Operating the Device Operating the Device 5.1 Views of the Instrument Fig. 19: Front view...
  • Page 28 Operating the Device Fig. 20: Grinding area view...
  • Page 29: Overview Table Of The Parts Of The Device

    Operating the Device 5.2 Overview table of the parts of the device Description Function Element Safety guard for the feed hopper Prevents contact with the feed hopper Plunger Releases the material feed chute in pulled state. Pushes grinding material onto the rotor. Metering plunger Pushes the grinding material into the feed chute area of the fill plunger...
  • Page 30: Opening And Closing Of The Device

    Operating the Device 5.3 Opening and Closing of the Device CAUTION V0063 Possibility of personal injuries Injuries due to rotating rotor – Reaching into the turning rotor • Never open the grinding chamber door while the rotor or the motor is still rotating. •...
  • Page 31: Removing The Rotor

    Operating the Device NOTICE Wear or damage of the device Operation without grinding set − During operation of the device without grinding set, excessive wear or damage to the device may occur. • Operate the device only with a grinding set mounted. NOTICE Damage to mechanical components Blockages typical of cutting mills...
  • Page 32: Inserting The Filter Unit And Collecting Receptacle

    Operating the Device 5.6 Inserting the filter unit and collecting receptacle The filter unit serves as air outlet for the flow of air generated by the grinding rotors. Fig. 23: Attaching and removing the filter unit • Insert the bayonet lock (BV) on the filter unit (J) into the discharge flange (AV) as shown in the diagram.
  • Page 33: Switching On And Off

    Operating the Device 5.7 Switching On and Off Fig. 25: On/off switch You can switch the device on/off using the on/off switch (G). The motor starts up or is shut down when the switch is actuated. The switch disconnects the device from the mains. 5.8 Starting the grinding process NOTICE Only fill test material when the device is running because this may otherwise lead to motor...
  • Page 34: Cleaning And Service

    Cleaning and service Cleaning and service 6.1 Adjusting the cutting bars The cutting gap must be checked to ensure that the device is functioning satisfactorily (target distance 0.3mm). For this reason the cutting bars (SL) are arranged so that they can be shifted to permit adjustments to the cutting gap.
  • Page 35 Cleaning and service Fig. 28: Freely rotate the rotor Mind. 0,3mm Fig. 29: Adjust the cutting gaps • Using a feeler gauge (BL) check the cutting gap for all three cutting bars (SL). It should be at least 0.3 mm. The feeler gauge (BL) must be placed as shown in the diagram.
  • Page 36: Cleaning

    Cleaning and service Fig. 30: Cutting gap • By twisting the stud bolts (U) to the right, slide the cutting bar closer to the rotor blade and thereby reduce the cutting gap. Increase the cutting gap by twisting to the left [3]. •...
  • Page 37: Clean The Feed Hopper

    Cleaning and service WARNING 1.W0004 Risk of injury When device is not correctly assembled after cleaning – There is a risk of injury to the operator. • The device may only be cleaned by skilled personnel who have been sufficiently instructed in operating the device. The following components on this device can be removed or moved for cleaning purposes: –...
  • Page 38: Lift Up The Feed Hopper Safety Guard

    Cleaning and service 6.2.1.1 Lift up the feed hopper safety guard Fig. 36: Lifting up the feed hopper safety guard • Remove the cap cover (EK). • Loosen the screw (ES) on the feed hopper safety guard. • Lift up the feed hopper safety guard (A). If the feed hopper needs more thorough cleaning it can also be dismantled for cleaning.
  • Page 39: Remove The Feed Hopper

    Cleaning and service 6.2.1.2 Remove the feed hopper WARNING W0004 Risk of injury to skin and hands Fast rotating blades – There is a risk of injury to hands, fingers and skin. • Never operate the device without the feed hopper. Fig.
  • Page 40: Clean Grinding Area

    Cleaning and service 6.2.2 Clean grinding area Fig. 38: Removing the rotor • Open the grinding area door (T). • Pull the plunger (B) into the uppermost latching position. • Screw the removal grip (EG) onto the rotor and pull the rotor from the drive shaft.
  • Page 41: Disposal

    Disposal Disposal Please observe the respective statutory requirements with respect to disposal. Information on disposal of electrical and electronic machines in the European Community. Within the European Community the disposal of electrically operated devices is regulated by national provisions that are based on the EU Directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE).
