  • Page 1 FINESSE / STANDESSE SUPERIOR control Installation instruction v.1 20-05-20...

  • Page 3: Package Contents

    1. INSTALLATION 1.1 CONTROL MODULE Air curtains FINESSE are produced with universal connection interface. Air curtains FINESSE can be controlled by one of following control modules: BASIC, COMFORT, SUPERIOR. Control modules are required accessories and has to be orderot separatelly.
  • Page 4 řídícímu modulu Vzduchová clona je připojena k řídícímu modulu "Rychlých připojovacích konektorů" pomocí "Rychlých připojovacích konektorů" žte řídící modul do vzduchové clony 6.3-1 Vložte řídící modul do vzduchové clony 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 5: Connecting The Control

    1. INSTALLATION Connection to the regulation control panel and accessories Connect the remote control and accesso- ries to the terminals electronic board 1.2 CONNECTING THE CONTROL 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 6: Modbus Rtu

    Punto di miscelazione - alimentazione SMU - napájení SMU - napájení SMU - napájení 2VV. Creating innovative solutions for you and your business since 1995. ble: SMU, heater/ Sygnał sterujący ( do nastawienia : SMU,heater/ Control signal (adjustable: SMU, heater/ Управляющий...
  • Page 7 (Output for outdoor unit) (Output for outdoor unit) (Output for outdoor unit) Registre Commande Commande Commande CMSI CMSI CMSI exterieure) exterieure) exterieure) Air Rejeté á distance á distance á distance 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 8 The total length of all chained air curtains must not exceed 150 m! SLAVE SLA- SLA- no.1 no. 6 no.2 no. 7 no. 3 no. 8 no. 4 no. 9 no. 5 no. 10 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 9: Connecting External Accessories

    – Cable - Four-core with a cross-section of 0.5 mm Supply 24 V/ 50/60 Hz (24V external source, not included) , control tension 0-10V CAUTION! Not included with the product. 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 10 Interventions or changes to the internal connections are forbidden and shall result in the loss of warranty. • We recommend the use of accessories supplied by our company. Contact your supplier in case of doubts regarding the • use of non-original accessories. 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 11: Control Panels

    Terminals must be set if multiple panels are to be connected. They are found in the main electronics and the controller: Terminal settings Example of controller connection – Option 1: Electric connection – Option 1: 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 12 The heater overheats due to insufficient air flow. Check operational that the ventilators are in good order and that the air off automatically but not supply is not disrupted. heating 2VV. Creating innovative solutions for you and your business since 1995.

  • Page 13: Maintenance

    7.1 IF YOU ARE UNABLE TO REPAIR THE UNIT If you were unable to solve a problem, contact the supplier or the representative of 2VV. Warranty and post-warranty service are provided by the supplier or an authorised service included in the list available at the supplier’s.

  • Page 14: Wiring Diagram

    8. WIRING DIAGRAM FUSE RELAY NTC 10K RELAY RELAY RELAY RELAY 25 26 27 28 29 30 63 64 65 66 +12V SLOT CANH CANL Zkrátit 350mm NTC 10K 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 15 8. WIRING DIAGRAM NTC 10K 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 16 8. WIRING DIAGRAM FUSE RELAY 300mm RELAY NTC 10K RELAY RELAY RELAY 25 26 27 28 29 30 63 64 65 66 +12V SLOT CANH CANL 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 17 8. WIRING DIAGRAM 300mm 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 18 8. WIRING DIAGRAM FUSE NTC 10K RELAY RELAY NTC 10K RELAY RELAY RELAY 25 26 27 28 29 30 63 64 65 66 +12V SLOT CANH CANL 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 19 8. WIRING DIAGRAM NTC 10K 2VV. Creating innovative solutions for you and your business since 1995.
  • Page 20 In case of any doubt or query, do not hesitate to contact our sales or technical support departments. CONTACT Address: 2VV, s.r.o., Fáblovka 568, 533 52 Pardubice, Česká republika Internet: http://www.2vv.cz/ 2VV. Creating innovative solutions for you and your business since 1995.
