6．Structural Drawing and Replacement Parts
Replacement part
Component
Description
No.
(7) Valve assembly
(8)
Diaphragm assembly
(9)
Valve guide assembly
(10)
Plug
Plug assembly
(11)
（Including part (10))
The numbers in the table and structural drawings are consistent with the numbers in sections [10. How to Replace the Components] (P15-19)
and [11. Disassembly Drawing] (P20-21).
Construction/ Common replacement parts
(9)
(7)
(8)
Without pressure gauge/
With round type pressure gauge
(11) (10)
Piping
thread Semi-standard specification
type
-：Without backflow
function
－
K：With backflow
function
-：Relief
－
N：Non-relief
－ －
－
Rc / G
－
NPT
－
Rc
－
NPT
－
G
-10-
Part No.
AR20M-D AR30M-D
AR24P-060AS AR34P-060AS
AR24KP-560AS AR34KP-560AS
AR24P-150AS AR34P-150AS
AR24P-150AS-N AR34P-150AS-N
AR24P-050AS AR34P-050AS
AR24P-370AS-01
AR24P-370AS-N01
AR24P-320AS-01
AR24P-320AS-N01
AR24P-320AS-F01
AR40M-D
AR44P-060AS
AR44KP-560AS
AR44P-150AS
AR44P-150AS-N
AR44P-050AS
