- Page 1 INSTALLATION AND OPERATING MANUAL ITYS 6 - 10 kVA UPS www.socomec.com/itys-manuals...
- Page 2 ITYS 6-10 kVA - 551431A - SOCOMEC...
- Page 3 The reference information on safety is in English. For other languages please contact Socomec or your local distributor. The manufacturer will not be held liable for failure to follow the instructions in this manual which is also available at www.socomec.com...
- Page 4 Return-to-base warranty is provided: components and labour for repairs supplied free of charge, any products to be replaced must be returned to Socomec or authorised service centres, at the customer’s own risk and expense. The warranty is recognised within national territory. If the UPS is exported out of national territory, the warranty shall be limited to the cover of the parts used to repair the defect.
- Page 5 Court of Vicenza. Socomec retains the full and exclusive ownership rights over this document. Only a personal right to use the document for the application indicated by Socomec is granted to the recipient of such document. All reproduction, modification or dissemination of this document whether in part or whole and by any manner are expressly prohibited except upon Socomec’s express prior written consent.
-
Page 6: Table Of Contents
5.5.2. Access to terminal blocks (AC source to UPS) ....33 5.5.3. Access to battery connector (DC source to UPS)....36 ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 7 9.2. UPS specifications ..........44 ITYS 6-10 kVA - 551431A - SOCOMEC...
-
Page 8: Safety Instructions
(WEEE). Indicates that the item must not be disposed of in normal household waste but be separately collected and recycled. Environmental Protection Use Period (EPUP). Information, advice, assistance. Refer to the user manual. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 9: Safety Of Persons
- the user/installer attaches warning labels to all mains isolating switches located remotely from the area where the UPS is situated, in order to inform service personnel that the circuit is connected to a UPS. - an external isolating device is installed. ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 10 Using the product in critical applications could require compliance with statutory regulations and standards, specific local bylaws, or adaptation to SOCOMEC recommendations. For this type of use it is always advisable to contact SOCOMEC beforehand for confirmation regarding the capacity of products to meet required levels of safety, performance and reliability.
- Page 11 - Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes. It may be toxic. - Failed batteries can reach temperatures that exceed the burn thresholds for touchable. ITYS 6-10 kVA - 551431A - SOCOMEC...
-
Page 12: Product Safety
• The admissible storage temperature range is -25°C to +55°C without battery (-15°C to +40°C with battery). • TN-S/IT/TN-C/TT of electrical supply system may be connected by UPS. • This UPS may be provided with a maximum of 6 extension battery cabinets or equivalent. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 13: Special Precautions
• During the replacement of the Battery Module, it is imperative to use the same type and number of elements as the original Battery Module provided with the UPS to maintain an identical level of performance and safety. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 14: Introduction
• Smart charging method to expand battery life time. • EBM quantity auto detection. • Communication ports: RPO, Dry in, Dry out, intelligent slot, USB, RS232. • Dot-matrix LCD, in multi-languages. • ECO Mode. • Battery-free start. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 15: Environmental Protection
(WEEE). Battery The product contains lead-acid batteries that must be processed according to applicable local regulations concerning batteries. The battery may be removed to comply with regulations and in view of correct disposal. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 16: Recycling
By separating waste electrical and electronic equipment, you will help reduce the volume of waste sent for incineration or land-fills and minimise any potential negative impact on human health and environment. ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 17 Certain assemblies inside this product (for example, assemblies that contain a battery) may have an EPUP which is lower than the EPUP on this product. ITYS 6-10 kVA - 551431A - SOCOMEC...
-
Page 18: Product Overview
ITY3-TW100B Tower 10K (1-1) UPS ITY3-TW110B Tower 10K (3-1) UPS ITY3-TW060LB Tower 6KS (1-1) UPS 13,5 469 x 225 x 360 ITY3-TW100LB Tower 10KS (1-1) UPS 15,8 6K/10K(1-1) & 8.5K/10K(3-1) 38.0 (ref.) 416.0 ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 19 External battery (EBM): MODEL NAME DESCRIPTION NET WEIGHT (kg) DIMENSIONS (mm) D x W x H ITY3-EX100B Tower EBM 16*2 BAT 95.5 469 x 225 x 596 ITY3-EX100HB Tower EBM 16*1 BAT 55.5 36.2(ref.) 416.0 ITYS 6-10 kVA - 551431A - SOCOMEC...
-
Page 20: Front Panels
3.2. Front panels 6KS/10KS (1-1) 6K/10K (1-1) & 8.5K/10K (3-1) for all model 3.3. Rear panels 6KS (1-1) 10KS (1-1) ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 21 9. External battery connector 10. Maintenance bypass switch (optional, default yes) External battery (EBM): 11. EBM connector-1 12. EBM connector-2 13. Fuse board cover (replace EBM fuse) 14. EBM detection Box (RJ45 port) ITYS 6-10 kVA - 551431A - SOCOMEC...
-
Page 22: Lcd Panel
Load supplied with warning Yellow/Off Maintain request/in progress Yellow/Red Load supplied, but no longer protected Load not supplied due to alarm Red/Off Load not supplied, but the output will stop in a few minutes Yellow/Red/ No communication green ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 23 The buzzer will be temporality silenced if one or more alarms are active and silence button is pressed. The buzzer will beep again if any new alarm becomes active. Backlight The LCD backlight automatically dims after 10 minutes of inactivity. Press any button to restore the screen. ITYS 6-10 kVA - 551431A - SOCOMEC...
-
Page 24: Lcd Description
Off: no output 8 steps for 0%-100% load Load status Top bar flashing: UPS is overloaded On: general alarm Alarm icon Off: no alarm Eco mode Mode icon Standby mode No icon, normal mode ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 25: Display Functions
Clear active fault COMMANDS Reset history Clear events and faults Restore factory set Restore to default factory settings PARAMETERS Refer to chapter page 26 “3.7. User settings” SERVICE [Product name], [Serial number], [Firmware version] ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 26: User Settings
[enabled], [disabled] enabled Date / Time dd/mm/yyyy hh:mm 01/01/2020 00:00 LCD contrast 0 - 100% Note: if the UPS is used in IT neutral systems, the site wiring fault function should be disabled. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 27: Communication
The Dry in function can be configured (see Settings > Dry in). DRY IN COMMENTS Connector type 16 AWG Maximum wires External breaker specification 60 V DC/30 V AC 20 mA max Dry Out Dry IN Dry IN ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 28: Web/Snmp Card (Option)
With this card installed, the UPS can be connected directly to a LAN (RJ45 ethernet) and controlled remotely from a WEB browser using TCP/IP protocol. Reference should be made to the relevant literature for a full description of functionality. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 29: Installation
Discard or recycle the packaging in a responsible manner, or store it for future use. Packing materials must be disposed in compliance with all local regulations concerning waste. Recycling symbols are printed on the packing materials to facilitate sorting. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 30: Checking The Accessory Kit
• RS232 cable • • • Stabilizer bracket • • • Safety instructions • • • • Multilingual safety label guide • • • User manual • • • • : standard configuration ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 31: Installing The Unit
UPS between the holes. Fix the UPS to the floor with bolts (M8 bolts are recommended). Unit:mm 2 8 5 2 5 0 3 2 5 • EBM Install the EBM model, refer to UPS model installation as above, place it next to UPS. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 32: Power Cables Connection
In three phase input system UPS the bypass connects directly input phase R to the output: in this condition the load is connected to one phase like it is on single phases input system UPS. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 33: Access To Terminal Blocks (Ac Source To Ups)
This type of connection must be carried out by qualified electrical personnel. Before carrying out any connection, check that the upstream protection devices (Normal AC source and Bypass AC source) are open “O” (Off). Always connect the ground wire first. ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 34 2. Connect the AC cable to terminal blocks: 1-1 model: AC OUT AC IN 3-1 model: 1-1 configuration Short ‘UPS input terminal L1/L2/L3’ with ‘busbar’, then connect the AC cable. AC OUT AC IN ITYS 6-10 kVA - 551431A - SOCOMEC...
- Page 35 3-1 configuration AC OUT AC IN Note: for correct connection of the cables, it is recommended to connect these cables to the rear-panel as below: AC OUT AC IN ITYS 6-10 kVA - 551431A - SOCOMEC...
-
Page 36: Access To Battery Connector (Dc Source To Ups)
1. Extended runtime with up to 6 Extended Battery Modules (EBMs) per UPS. 2. If more than 2 EBMs are connected to the UPS, an additional cable of ground (10mm ) must be connected between UPS and EBMs. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 37: Operation
6. OPERATION 6.1. Starting the UPS using mains power Power on with utility Auto standby mode Auto bypass mode (enabled) UPS on inverter 1 sec ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 38: Starting The Ups Using Battery Power
Battery start can be disabled. Refer to page 26 chapter “3.7. User settings - Cold start”. UPS in Battery mode Touch for power on 1 sec 6.3. UPS shutdown UPS on bypass Disconnect mains mode (enable) 3 sec UPS shutting off Complete shutdown ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 39: Ups Maintenance
UPS to the mains power supply. It is recommended that the batteries are charged for 48 hours after long-term storage. If the batteries have not been charged over a six-month period, do not use them. Contact your service representative. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 40: Troubleshooting
Example = “Battery low”. • Faults are announced by a continuous beep and red LED, recorded into the Event log. Example = Out. short circuit. Use the following troubleshooting chart to determine the UPS alarm condition. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 41: Typical Alarms And Faults
Inside temperature of UPS is too high the ambient temperature. Amb. temp. alarm The ambient temperature is too high Check the environment ventilation Imminent shutoff Insufficient battery backup time Protect load equipment in time ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 42 Press On-Switch to turn on UPS. the power supply is available Emergency supply period Batteries are not fully charged / Charge the batteries for at least 12 shorter than nominal value batteries defect hours and then check capacity. ITYS 6-10 kVA - 551431A - SOCOMEC...
-
Page 43: Silencing The Alarm
Check the alarm condition and perform the applicable action to resolve the condition. If the alarm status changes or if the used press the "esc" button on the front panel for 3 seconds, the alarm beeps again, overriding the previous alarm silencing. ITYS 6-10 kVA - 551431A - SOCOMEC... -
Page 44: Specifications
43 A 53 A 61 A 53 A with 16pcs battery Rated current (3phase) 16.2 A 18 A with 16pcs battery Full range: 40Hz-70Hz Frequency range Normal mode: 45Hz-55Hz for 50Hz, 54Hz-66Hz for 60Hz ITYS 6-10 kVA - 551431A - SOCOMEC... - Page 45 (2) @ 220VAC input phase voltage, rated output power and maximum charging. Note: this is a category C3 UPS product. In a residential environment, this product may cause radio interference, in which case the user may be required to take additional measures. ITYS 6-10 kVA - 551431A - SOCOMEC...
- Page 46 MAIN OFFICE, CONTACT: SOCOMEC SAS 1-4 RUE DE WESTHOUSE 67235 BENFELD, FRANCE www.socomec.com 551431A...
