INSTRUCTION MANUAL
For...は専用機種。複数の場合は「/」で区切る。
不要の場合はとる。
形名を入力。 複数の場合は「/」で区切る。
3550
品名を入力。
BATTERY HiTESTER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3550 and is the answer not in the manual?

Questions and answers

Related Manuals for Hioki 3550

Summary of Contents for Hioki 3550

  • Page 1 INSTRUCTION MANUAL For...は専用機種。複数の場合は「/」で区切る。 不要の場合はとる。 形名を入力。 複数の場合は「/」で区切る。 3550 品名を入力。 BATTERY HiTESTER...

  • Page 3: Table Of Contents

    Contents Introduction Inspection Safety Precautions Organization of this Manual viii Chapter 1 Overview Chapter 2 Names and Functions of Parts Chapter 3 Specifications 3.1 General Specification 3.2 Measurement Range 3.2.1 Maximum Input Voltage 3.2.2 Floating Voltage 3.2.3 Dielectric Strength Chapter 4 Standard Measurement 4.1 Preparing for Measurement 4.2 Measurement Chapter 5 Advanced Measurement Functions...
  • Page 4 5.2 Measurement Value Memory Function 5.2.1 Memory 5.2.2 Clear 5.2.3 Readout 5.2.4 Printing 5.3 Beeper On/Off Function 5.4 Hold Function 5.5 Moving Average Function 5.6 Zero Adjust Function 5.7 Battery Low Warning 5.8 Auto Power Off 5.9 AC Four-Terminal Method 5.10 Internal Resistance of Lead-Acid Batteries 47 Chapter 6 Maintenance 6.1 Troubleshooting...

  • Page 5: Introduction

    ___________________________________________________________________ Introduction Thank you for purchasing the HIOKI "3550 BATTERY HiTESTER." To obtain maximum performance from the product, please read this manual first, and keep it handy for future reference. Inspection When you receive the product, inspect it carefully to ensure that no damage occurred during shipping.

  • Page 6: Safety

    ___________________________________________________________________ Safety This product is designed to conform to IEC 61010 DANGER Safety Standards, and has been thoroughly tested for safety prior to shipment. However, mishandling during use could result in injury or death, as well as damage to the product. Be certain that you understand the instructions and precautions in the manual before use.
  • Page 7 ___________________________________________________________________ The following symbols in this manual indicate the relative importance of cautions and warnings. Indicates that incorrect operation presents an DANGER extreme hazard that could result in serious injury or death to the user. Indicates that incorrect operation presents a WARNING significant hazard that could result in serious injury or death to the user.
  • Page 8 ___________________________________________________________________ Measurement categories (Overvoltage categories) This product conforms to the safety requirements for CAT I measurement products. To ensure safe operation of measurement products, IEC 61010 establishes safety standards for various electrical environments, categorized as CAT I to CAT IV, and called measurement categories.

  • Page 9: Precautions

    ___________________________________________________________________ Precautions Follow these precautions to ensure safe operation and to obtain the full benefits of the various functions. The floating voltage between input terminals and DANGER ground is 450V DC/AC. Attempting to measure voltages exceeding 450V with respect to ground could damage the product and result in personal injury.
  • Page 10 Using the product in such conditions could cause an electric shock, so contact your dealer or Hioki representative for replacements. (Model 9460) Be sure to connect the SOURCE and SENSE terminals (banana plugs), and TEMP SENSOR terminal (mini-plug) correctly.
  • Page 11 When sending the product for repair, remove the batteries and pack carefully to prevent damage in transit. Include cushioning material so the product cannot move within the package. Be sure to include details of the problem. Hioki cannot be responsible for damage that occurs during shipment.

  • Page 12: Organization Of This Manual

    viii ___________________________________________________________________ Organization of this Manual This manual consists of the following chapters. "Introduction", "Inspection", "Safety", "Precautions" include some important notes which you should read before using the unit. Chapter 1 Overview describes an outline of the unit, and lists its features. Chapter 2 Names and Functions of Parts lists the names of the parts of the unit, and the functions of all of the indications, terminals, and switches.

  • Page 13: Chapter 1 Overview

    ___________________________________________________________________ Chapter 1 Overview The 3550 is designed for measuring the internal resistance, open-circuit voltage, and terminal temperature of secondary batteries, including lead-acid batteries, nickel-cadmium batteries, nickel-metal hydride batteries, and lithium-ion batteries. Features Since it uses the AC four-terminal method to measure the internal resistance, it provides accurate results with the lead resistances and contact resistances eliminated.
  • Page 14 ___________________________________________________________________ ___________________________________________________________________ Chapter 1 Overview...

  • Page 15: Chapter 2 Names And Functions Of Parts

    ___________________________________________________________________ Chapter 2 Names and Functions of Parts This chapter explains the keys, input and output terminals, display, LED indicators, and leads. ___________________________________________________________________ Chapter 2 Names and Functions of Parts...
  • Page 16 ___________________________________________________________________ Front Panel Side Panel ___________________________________________________________________ Chapter 2 Names and Functions of Parts...
  • Page 17 ___________________________________________________________________ Keys and input/output terminals ● Turns the power on or off. POWER Ω key Ω key Selects the resistance range. 300m Ω key V key Selects the voltage range. V key Zero adjustment key. 0 ADJ Turns the beeper on and off. Locks out changes to the display.
  • Page 18 ___________________________________________________________________ LCD (view with all elements displayed) ● Display ● 1. Measured resistance 2. Temperature measurement value [comparator resistance lower limit setting] 3. Temperature measurement value [comparator resistance lower limit setting] Indicates the unit of resistance. Ω Indicates the unit of voltage. Indicates the unit of temperature.
  • Page 19 ___________________________________________________________________ Flashes once when the key is MEMO MEMO pressed. Appears when the battery voltage of the tester is low, to prompt the user to replace the battery. Appears during display of the comparator COMP.SET setting screen. Appears during display of the screen for setting the comparator resistance upper and lower limit values.
  • Page 20 ___________________________________________________________________ 9460 CLIP TYPE LEAD WITH TEMPERATURE SENSOR ● Clip (red) Mini-plug Temperature (TEMP.SENSOR) sensor Clip (black) Banana plug (black) Banana plug (red) SOURCE SENSE ___________________________________________________________________ Chapter 2 Names and Functions of Parts...

  • Page 21: Chapter 3 Specifications

    ___________________________________________________________________ Chapter 3 Specifications 3.1 General Specification Measurement method Resistance: AC four-terminal method. Temperature: platinum temperature sensor. A/D conversion gration method. Double inte Display LCD and LEDs (comparator output) Panel abbreviations HOLD COMP DATA and symbols Ω MEMO    COMP.SET VOLT Sampling rate 0.83 sets (resistance, voltage, and...
  • Page 22 ___________________________________________________________________ Beeper function Audible output for warning and fail results. Can be turned on and off. Auto power off Power off automatically after about 30 minutes. Comparator settings Resistance upper and lower limits and voltage lower limit. Number of Ten sets. comparator settings Comparator output LEDs for...
  • Page 23 ___________________________________________________________________ Printer interface Centronics (can be connected to the 9203 DIGITAL PRINTER) C(32 。 F to 104 。 F) Operating C to 40 temperature and 80 %RH (no condensation) humidity range C(14 。 F to 122 。 F) Storage temperature C to 50 and humidity range 80 %RH (no condensation)
  • Page 24 ___________________________________________________________________ Standards applying EN61326:1997+A1:1998+A2:2001 +A3:2003 Safety EN61010-1:2001 Pollution Degree 1, Measurement Category I (anticipated transient overvoltage 2500 V) Accessories 9460 CLIP TYPE LEAD WITH TEMPERATURE SENSOR 9382 CARRYING CASE Instruction Manual Dust cover (for the printer interface) Six LR6 alkaline batteries Options 9203 DIGITAL PRINTER 9425 CONNECTION CABLE...

  • Page 25: Measurement Range

    ___________________________________________________________________ 3.2 Measurement Range Conditions to guarantee accuracy: Temperature Humidity :80 %RH or less (no condensation) Zero adjustment :After zero adjustment for each range Warming up time :At least 10 minutes Period of guaranteed accuracy :1 year (1) Resistance Measurement Temperature coefficient: ( 0.01% rdg.

  • Page 26: Maximum Input Voltage

    ___________________________________________________________________ 3.2.1 Maximum Input Voltage The maximum input voltage is 50 VDC. Attempting DANGER to measure voltage in excess of the maximum input could destroy the product and result in personal injury or death. To avoid electrical hazards and damage to the product, do not apply voltage exceeding the maximum input to the measurement terminals.

  • Page 27: Floating Voltage

    ___________________________________________________________________ 3.2.2 Floating Voltage Between input terminals and ground, 450 VDC/AC maximum. Do not input voltage in excess of this floating DANGER voltage to the measurement terminal. This could result in injury or damage to the unit. When voltages higher than 30 Vrms, 42.4 Vpeak or battery circuits with more than 60 VDC are to be measured, be sure to establish the floating state first.
  • Page 28 ___________________________________________________________________ ___________________________________________________________________ Chapter 3 Specifications...

  • Page 29: Chapter 4 Standard Measurement

    ___________________________________________________________________ Chapter 4 Standard Measurement 4.1 Preparing for Measurement To avoid electric shock when replacing the batteries, WARNING first disconnect the leads from the object to be measured. Do not mix old and new batteries, or different types of batteries. Also, be careful to observe battery polarity during installation.
  • Page 30 ___________________________________________________________________ To avoid the possibility of explosion, do not short WARNING circuit, disassemble or incinerate batteries. Handle and dispose of batteries in accordance with local regulations. The " " indicator appears when battery voltage becomes low. NOTE Replace the batteries as soon as possible. Removing the batteries clears all measurement data from memory.

  • Page 31: Measurement

    ___________________________________________________________________ 4.2 Measurement To prevent electric shock, before using this tester, WARNING fit the supplied dust cover for the printer interface over the PRINT terminal. To avoid injury or damage to the product, do not attempt to measure AC voltage, or DC voltage exceeding 50 V.
  • Page 32 ___________________________________________________________________ 1. Connect the 9460 leads as shown in the figure below. Connect leads to all five terminals; SOURCE +/-, SENSE +/-, and TEMP SENSOR. Banana plugs Mini-plug Black TEMP SENSOR terminal SOURCE and SENSE terminals 2. Press the key to turn on the power and start POWER measurement.
  • Page 33 ___________________________________________________________________ measurement ranges. 5. When the measurement is completed, disconnect the leads from the tested battery and press the key to turn off POWER the power. When measuring the contact resistance of a relay or connector, NOTE be careful of the open-circuit voltage across the test leads. It may not always be possible to destroy an oxide layer on the terminals of the object being measured in order to obtain an accurate reading.
  • Page 34 ___________________________________________________________________ A temperature indication "---" means that the temperature sensor is not connected. The "---" indication may also appear if there is a break in the test lead circuit. Except for setting the auto power off mode and the moving average function, do not press the key in combination POWER...

  • Page 35: Chapter 5 Advanced Measurement Functions

    ___________________________________________________________________ Chapter 5 Advanced Measurement Functions 5.1 Comparator Function 5.1.1 What is the Comparator Function? The comparator function compares the measurement values with preset lower and upper limit values for internal resistance and voltage level, and determines which range the measurement falls into, based on the preset conditions.

  • Page 36: Comparator Settings

    ___________________________________________________________________ 5.1.2 Comparator Settings (1) Before changing the settings To set the comparator (upper and lower resistance limits and voltage comparison value), do the following: 1. Press and hold the key for at least 3 seconds. The COMP upper and lower resistance limit settings appear. 2.
  • Page 37 ___________________________________________________________________ (2) Setting the comparator number Change the comparator number with the DOWN keys. You can select any comparator number up to 10. (3) Setting the resistance range Press the resistance range key (Ω RANGE 300m ) corresponding to the resistance to be measured. The currently selected resistance range is displayed at the center on the screen.
  • Page 38 ___________________________________________________________________ (4) Setting the resistance limits 1. Using the key, move the flashing number to the most significant digit of the lower resistance limit setting at the lower left of the screen. Lower resistance limit Upper resistance limit 2. Set the lower and upper resistance limits with the keys.
  • Page 39 ___________________________________________________________________ (5) Setting the voltage range 1. Using the key, move the flashing number to the least significant digit of the upper resistance limit setting at the lower right of the screen. 2. Press the key again to display the voltage comparison value setting screen will appear.
  • Page 40 ___________________________________________________________________ (6) Setting the voltage comparison value 1. Using the key and the keys, set the DOWN voltage comparison value at the lower left of the screen. The allowable range of settings for the voltage comparison value is -3000 to 3000. Voltage range 2.

  • Page 41: Comparator Decision Result Table

    ___________________________________________________________________ 5.1.3 Comparator Decision Result Table The decision result is indicated by the LEDs and by the beeper, as shown in the following table. Resistance Lower resistance limit Upper resistance limit Voltage WARNING WARNING FAIL Voltage Amber *1 Amber comparison PASS WARNING FAIL...

  • Page 42: Switching The Comparator On And Off

    ___________________________________________________________________ 5.1.4 Switching the Comparator On and Off Pressing the key toggles the comparator function on COMP and off. When the comparator is on, the " " COMP indication appears in the display, and the comparator operates as measurements are taken. When the comparator is off, the "...

  • Page 43: Changing The Comparator Number

    ___________________________________________________________________ 5.1.5 Changing the Comparator Number To change the comparator number, do the following procedure. 1. Press and hold the key for at least 3 seconds. The COMP resistance comparator setting screen appears. " " appears at lower left of the screen. COMP.SET 2.

  • Page 44: Measurement Value Memory Function

    ___________________________________________________________________ 5.2 Measurement Value Memory Function To avoid damage to the product, do not apply voltage WARNING to the EXT.MEMO terminals. The currently measured values (resistance value, voltage value, temperature, and comparator result), taken as a set can be stored: up to 260 such sets of values can be held, and later displayed and printed as required.
  • Page 45 ___________________________________________________________________ Using the terminals, the same effect as the EXT. MEMO key can be obtained. MEMO 1. Using a blade screwdriver or a similar tool, insert the individual leads into the terminal apertures. (Leads are not supplied.) When inserting or removing the leads, push in the terminal button with a screwdriver as shown in the figure below.

  • Page 46: Clear

    ___________________________________________________________________ 2. Contact the leads together for at least 100 ms (use a switch) to obtain the effect of pressing the key. MEMO The " " indication appears in the display, and one set MEMO of measurement values and comparator results are saved in memory.

  • Page 47: Readout

    ___________________________________________________________________ 5.2.3 Readout Redisplay a measurement value from memory as follows. 1. Press the key. READ The " " indication appears in the upper right and the MEMO number of " " indication flashes. No.    means that the currently displayed readings are MEMO values recalled from memory.

  • Page 48: Printing

    ___________________________________________________________________ 5.2.4 Printing For safety, never connect the 3550 to the printer WARNING during measurement. To prevent electric shock, before using this tester, fit the supplied dust cover for the printer interface over the PRINT terminal. To avoid damage to the product, do not apply voltage to the PRINT terminal.
  • Page 49 ___________________________________________________________________ Output Example of the 9203 Output Example of the General-purpose Printer ___________________________________________________________________ Chapter 5 Advanced Measurement Functions...

  • Page 50: Beeper On/Off Function

    ___________________________________________________________________ 5.3 Beeper On/Off Function Pressing the key toggles the beeper on and off. When the beeper is on, the " " indication appears in the display, and the beeper sounds when there is a "Warning" or "Fail" result. When the beeper is off, the "...

  • Page 51: Moving Average Function

    ___________________________________________________________________ 5.5 Moving Average Function If the resistance measurement value is unstable, this can be corrected with the moving average function. This takes the average of four samples of the resistance value and displays the result. The moving average takes the sum of the current value and the previous three sampled values, and divides by four.
  • Page 52 ___________________________________________________________________ 5. When the above screen appears, press the key to POWER power the unit off. 6. Press the key again to power the unit on. POWER 7. To cancel the moving average function, in the moving average setting screen, press the key to cancel the moving average function.

  • Page 53: Zero Adjust Function

    ___________________________________________________________________ 5.6 Zero Adjust Function The zero adjustment function adjusts the zero position of the resistance and voltage ranges of this unit. The value read during zero adjustment is taken as zero, and used to calibrate subsequent measurements. 1. Short the SOURCE and SENSE of the 9460 CLIP TYPE LEAD WITH TEMPERATURE SENSOR together as shown in the figure below.

  • Page 54: Battery Low Warning

    ___________________________________________________________________ Shorting only the terminals will not display 0 V. SENSE Always make sure that both the terminals SENSE SOURCE are shorted together. If the leads are shorted but their ends are brought close to metal parts, the measured value may fluctuate as a result of electromagnetic induction.

  • Page 55: Auto Power Off

    ___________________________________________________________________ 5.8 Auto Power Off In the following states, if there is no switch operation for 30 minutes the unit automatically powers off. When the resistance value is "----" indication. During hold On the comparator setting screen During the printing output During reading the memory data For continuous measurement, in some cases it may be necessary to disable the auto power off function.
  • Page 56 ___________________________________________________________________ 3. Press the key again. HOLD 4. When the above screen appears, press the key to turn POWER off the power. 5. Press the key again to turn the power on. POWER 6. To set to the auto-power off, press the key in the auto HOLD power off setting screen and set the auto power off to 30...

  • Page 57: Ac Four-Terminal Method

    ___________________________________________________________________ 5.9 AC Four-Terminal Method The 3550 uses the AC four-terminal method, so that resistance measurement can be carried out with the resistance of the leads, and the contact resistance between the object to be measured and the leads canceled out. The following figure shows the principle of the AC four-terminal measurement method.
  • Page 58 ___________________________________________________________________ NOTE In the 3550, a synchronized wave detection system is used, whereby the internal impedance is separated into effective resistance and reactance, and the resistive component only displayed. Impedance Reactance Effective resistance ___________________________________________________________________ Chapter 5 Advanced Measurement Functions...

  • Page 59: Internal Resistance Of Lead-Acid Batteries

    ___________________________________________________________________ 5.10 Internal Resistance of Lead-Acid Batteries This shows the relationship between the capacity for lead- acid batteries and the initial value for internal resistance. (Quote: Text from battery fitters qualification lecture notes, Battery Industry Association) The terms CS, HS, and MSE appearing in the figure are battery types defined by JIS (Japanese Industrial Standards).
  • Page 60 ___________________________________________________________________ From the figure, MSE internal resistance can be read as approximately 1 mΩ (at 100Ah), or approximately 0.13 mΩ (at 1000 Ah). When the battery deteriorates, internal resistance rises to 1.5 to 2 times the initial value (reference value). With an MSE (seal type stationary lead-acid battery), battery condition is regarded as marginal when internal resistance reaches 1.5 times the initial value, and complete...

  • Page 61: Chapter 6 Maintenance

    ___________________________________________________________________ Chapter 6 Maintenance If damage is suspected, check the "Troubleshooting" section before contacting your dealer or Hioki representative. 6.1 Troubleshooting Symptom Cause Follow-up Nothing appears on Batteries are exhausted, or Replace the batteries or reinsert the screen when the not inserted.
  • Page 62 Include cushioning material so the instrument cannot move within the package. Be sure to include details of the problem. Hioki cannot be responsible for damage that occurs during shipment. Never modify the product. Only a Hioki service engineer can disassemble or repair the product.

  • Page 63: Message Reference

    ___________________________________________________________________ 6.2 Message Reference Message Meaning Follow-up FAIL Zero adjustment cannot be Connect correctly the lead and carried out. execute the zero adjustment. See Section 5.6, "Zero Adjust Function." Prnt Data is being sent to the Disappears when data output to the printer.
  • Page 64 ___________________________________________________________________ ___________________________________________________________________ Chapter 6 Maintenance...
  • Page 67 HIOKI 3550 BATTERY HiTESTER Instruction Manual Publication date: September 2006 Revised edition 10 Edited and published by HIOKI E.E. CORPORATION Technical Support Section All inquiries to International Sales and Marketing Department 81 Koizumi, Ueda, Nagano, 386-1192, Japan TEL: +81-268-28-0562 / FAX: +81-268-28-0568 E-mail: os-com@hioki.co.jp...
  • Page 68 2003-01 改訂  枠消す HEAD OFFICE 81 Koizumi, Ueda, Nagano 386-1192, Japan TEL +81-268-28-0562 / FAX +81-268-28-0568 E-mail: os-com@hioki.co.jp / URL http://www.hioki.co.jp/ HIOKI USA CORPORATION 6 Corporate Drive, Cranbury, NJ 08512, USA TEL +1-609-409-9109 / FAX +1-609-409-9108 3550A981-10 06-09H Printed on recycled paper...
