Quest Dry
Quest 110/150 Dual
Installation, Operation and Maintenance Instructions
Installation, Operation and Maintenance Instructions
– Read and Save These Instructions –
This manual is provided to acquaint you with the
dehumidifier so that installation, operation and maintenance
can proceed successfully. Ultimate satisfaction depends on
the quality of installation and a thorough understanding
of this equipment. The dehumidifier is built around tested
engineering principles and has passed a thorough inspection
for quality of workmanship and function.
Features:
•
High capacity
•
High efficiency
•
Environmentally friendly
•
Small Footprint
Quest 150
Specifications subject to change without notice.
Water Removal Rates (Pints/Day) @ 80°F 60% (AHAM)
Dehumidifier
Pints Removed
110 Dual
150 Dual
4201 Lien Rd
Madison, WI 53704
www.QuestClimate.com
1
Quest 110
Patent: thermastor.com/patents
Gallons/Liters
110
13.75/52
150
18.75/71
Toll-Free 1-877-420-1330
info@QuestClimate.com
09/20 Rev. A
TS-1175
Advertisement
Table of Contents
Related Manuals for Therma-Stor Quest 110 Dual
Summary of Contents for Therma-Stor Quest 110 Dual
- Page 1 Quest Dry Quest 110/150 Dual Installation, Operation and Maintenance Instructions Installation, Operation and Maintenance Instructions – Read and Save These Instructions – This manual is provided to acquaint you with the dehumidifier so that installation, operation and maintenance can proceed successfully. Ultimate satisfaction depends on the quality of installation and a thorough understanding of this equipment.
-
Page 2: Table Of Contents
Quest 110/150 Dual Installation, Operation and Maintenance Instructions Table of Contents Safety Precautions ..............3 1. Intended Application .............4 2. Registrations ................4 3. Specifications ...............4 4. Installation ................ 5 4.1 Location ................ 5 4.2 Electrical Requirements ..........5 4.3 Condensate Removal ........... 6 4.4 Hanging Diagram ............ -
Page 3: Safety Precautions
Quest 110/150 Dual Installation, Operation and Maintenance Instructions Safety Precautions Read the installation, operation and maintenance instructions carefully before installing and operating this device. Proper adherence to these instructions is essential to obtain maximum benefit from your Quest Dual Dehumidifier. READ AND SAVE THESE INSTRUCTIONS •... -
Page 4: Intended Application
Quest 110/150 Dual Installation, Operation and Maintenance Instructions 1. Intended Application for Quest Dual The Quest Dual Dehumidifier is designed to operate in temperatures between 56° and 95°F. In order to efficiently control humidity levels, the area in which the dehumidifier is to be operated must be free of water intrusion or excessive fresh (outside) air infiltration. -
Page 5: Installation
Quest 110/150 Dual Installation, Operation and Maintenance Instructions 4. Installation 4.1 Location The Quest Dual Dehumidifier can be installed in a variety of locations to meet the owner’s needs as listed below. In all cases keep the following cautions in mind: •... -
Page 6: Condensate Removal
Quest 110/150 Dual Installation, Operation and Maintenance Instructions 4.3 Condensate Water Removal Condensate drains by gravity via the drain port. Use 3/4” male NPT PVC pipe. A p-trap is recommended at the time of install, see diagram below. An optional condensate pump kit may be installed if a lift is required to dispose of the condensate. -
Page 7: Ducting
Quest 110/150 Dual Installation, Operation and Maintenance Instructions 4.5 Ducting 4.5A Supply Duct Kit (P/N 4033039) A factory designed supply duct kit can be purchased to accept 10” ducting to both outlets of the Quest Dual. Contact your dealer or call 1-877-420-1330 to order or go to www.questclimate.com/product-category/accessories. 4.5B Return Duct Kit (P/N 4039697) A factory designed return duct kit can be purchased to accept 12”... -
Page 8: Maintenance
Quest 110/150 Dual Installation, Operation and Maintenance Instructions 6. Maintenance WARNING! NOTE: Do not operate the unit without the filter or with a less effective filter. The heat exchange coils inside the unit could become clogged and require disassembly to clean. Filter non-compliance invalidates the product warranty. -
Page 9: Troubleshooting
Quest 110/150 Dual Installation, Operation and Maintenance Instructions 7.3 Troubleshooting FOR THE USER: If the unit does not work properly, please check the following: — Is the unit unplugged? — Is power to outlet on? (check switch, if applicable) — Is circuit breaker tripped? —... - Page 10 Quest 110/150 Dual Installation, Operation and Maintenance Instructions Blower does not run with fan switch in either position. Compressor runs briefly but cycles on and off. Loose connection in blower circuit. Obstruction prevents impeller rotation. Defective blower. Defective blower switch. Evaporator coil frosted continuously, low dehumidifying capacity.
-
Page 11: Wiring Diagram
Quest 110/150 Dual Installation, Operation and Maintenance Instructions Wiring Diagrams Quest 110 - 4034052 Rev. A 115 VAC, 60 Hz, SINGLE PHASE IMPELLER FAN SWITCH FAN ON FAN AUTO DEFROST THERMOSTATS COMPRESSOR CAPACITOR RELAY COMP Quest 150 - 4035828 Rev. A 4035828 1-877-420-1330 www.QuestClimate.com... -
Page 12: Service Parts List
Quest 110/150 Dual Installation, Operation and Maintenance Instructions Service Parts List Call your dealer or 1-800-533-7533. Part No Description 4034887-04 Evaporator (110) 4033859-04 Evaporator (150) 4035474 Compressor (110) 4030131 Compressor (150) 4029510 Filter/drier 4035868 Condenser (110) 4034099 Condenser (150) 4026360 Impeller (110) 4035463 Impeller (150) -
Page 13: Warranty
FIRST YEAR WARRANTY: Therma-Stor LLC warrants that, for one (1) year the Quest Dual dehumidifier will operate free from any defects in materials and workmanship, or Therma-Stor LLC will, at its option, repair or replace the defective part(s), free of any charge.
