Quest CDG 174
Quest Dry
Installation, Operation and Maintenance Instructions
Installation, Operation and Maintenance Instructions
– Read and Save These Instructions –
This manual is provided to acquaint you with the dehumidifier so that installation, operation and maintenance can
proceed successfully. Ultimate satisfaction depends on the quality of installation and a thorough understanding of
this equipment. The dehumidifier is built around tested engineering principles and has passed a thorough inspection
for quality of workmanship and function.
Specifications subject to change without notice.
4201 Lien Rd
Madison, WI 53704
www.QuestClimate.com
1
Toll-Free 1-877-420-1330
info@QuestClimate.com
TS-976
11/19 Rev. B
Advertisement
Table of Contents
Related Manuals for Therma-Stor Quest CDG 174
Summary of Contents for Therma-Stor Quest CDG 174
- Page 1 Quest CDG 174 Quest Dry Installation, Operation and Maintenance Instructions Installation, Operation and Maintenance Instructions – Read and Save These Instructions – This manual is provided to acquaint you with the dehumidifier so that installation, operation and maintenance can proceed successfully. Ultimate satisfaction depends on the quality of installation and a thorough understanding of this equipment.
-
Page 2: Table Of Contents
Quest CDG 174 Installation, Operation and Maintenance Instructions Table of Contents Safety Precautions ............4 1. Intended Application ............4 2. Registrations ................4 3. Specifications ............4 4. Operation ..............4 4.1 Transporting ............5 4.2 Location ..............5 4.3 Electrical Requirements ........5 4.4 Condensate Removal ...........5... -
Page 3: Safety Precautions
Quest CDG 174 Installation, Operation and Maintenance Instructions Safety Precautions Read the installation, operation and maintenance instructions carefully before installing and operating this device. Proper adherence to these instructions is essential to obtain maximum benefit from your Quest CDG 174. -
Page 4: Intended Application
Quest CDG 174 Installation, Operation and Maintenance Instructions 1. Intended Application for Quest Dual Dehumidifier The Quest Dual Dehumidifier is designed to operate in temperatures between 56° and 95°F. In order to efficiently control humidity levels, the area in which the dehumidifier is to be operated must be free of water intrusion or excessive fresh (outside) air infiltration. -
Page 5: Transporting
4.3 Electrical Requirements The Quest CDG 174 can be plugged into a grounded 15 Amp circuit. At 80°F, 60% RH, it draws 10 Amps. Due to the high percentage of a 15 Amp circuit’s capacity that the unit uses, the circuit should be dedicated to running it only. Amp draw decreases at lower loads and increases at higher loads. -
Page 6: Purge Button
The DEFROST light turns on when the unit is in defrost mode indicating when the compressor is off. DRYING TIP: Air’s ability to absorb moisture from wet surroundings and the Quest CDG 174’s ability to remove moisture from that air is greatly improved at higher temperatures. We recommend that the area to be dried be heated to over 70°F if possible. -
Page 7: Maintenance
5.1 Air Filter The Quest CDG 174 is equipped with a pleated fabric air filter that must be checked regularly. The standard filter is a MERV-11 high efficiency filter. Operating the unit with a dirty filter will reduce the dehumidifier’s capacity and efficiency and may cause the compressor to cycle off and on unnecessarily on the defrost control. -
Page 8: Technical Description
Installation, Operation and Maintenance Instructions 6.2 Technical Description The Quest CDG 174 uses a refrigeration system similar to an air conditioner’s to remove heat and moisture from incoming air, and to add heat to the air that is discharged (see Fig. 2). - Page 9 Quest CDG 174 Installation, Operation and Maintenance Instructions No dehumidification, air mover runs but compressor does not. Bad connection in compressor circuit Check to make sure humidistat is set high enough 3. Safety float switch closed, check pump reservoir 4. Defective compressor capacitor 5.
-
Page 10: Refrigerant Charging
Quest CDG 174 Installation, Operation and Maintenance Instructions Unit pumps water automatically but not when PURGE button is pushed. 1. Bad connection in PURGE button circuit 2. Defective control board Evaporator coil frosted continuously, low dehumidifying capacity. 1. Defrost thermistor loose or defective 2. -
Page 11: Thermistor Replacement
5. Replace the pump, hose, wiring, bolts, and cover in the reverse order 6.8 Gravity Drain Option If the condensate pump fails and cannot be replaced immediately, the Quest CDG 174 can be used by draining by gravity. Unplug the unit and remove the front cover. -
Page 12: Wiring Diagram
CAPACITOR 3 VIO 4 VIO 5 VIO 17 BRN 16 WHT COMPRESSOR RELAY 6 BLK 7 BLK 15 RED COMPRESSOR CAPACITOR 14 YEL 13, 18 WHT COMPRESSOR 15 RED Figure 3: Electrical schematic of Quest CDG 174 1-877-420-1330 www.QuestClimate.com info@QuestClimate.com... -
Page 13: Service Parts
Quest CDG 174 Installation, Operation and Maintenance Instructions 8 Service Parts Item Description Part No. Item Description Part No. Top Cover 4035206 Condenser Coil 4028566 Top Cover Hinge 4027267 Condensate Pump 4034605-01 Wheel 12” Gray 4026304 Fan Motorized Impeller 4026657 Cotter Pin 3/32”... -
Page 14: Warranty
Year One: Therma-Stor LLC warrants that, for one (1) year the Quest CDG 174 dehumidifier will operate free from any defects in materials and workmanship, or Therma-Stor LLC will, at its option, repair or replace the defective part(s), free of any charge.
