Page 1
System ramienia nośnego CP 180 Support arm system CP 180 CP 6212.900 CP 6218.150 CP 6218.600 CP 6218.740 CP 6218.050 CP 6218.200 CP 6218.620 CP 6218.820 CP 6218.100 CP 6218.210 CP 6218.640 CP 6218.110 CP 6218.300 CP 6218.700 Instrukcja montażu i obsługi...
Page 2
For mounting components required for connection to the housing, please refer to the support arm system 120 assembly instructions. Please ensure that the support arm system is securely and permanently fastened to the mounting surface! System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 3
Z zamkniętym lub otwartym profilem Z zamkniętym profilem nośnym nośnym With support section solid Rittal zaleca, aby ten odcinek profilu wykonywać w miarę możliwości za pomocą zamkniętego With support section solid or open profilu nośnego. Z otwartym profilem nośnym Rittal advises to use support arm section with solid support section if possible.
Page 4
TX45 M10 x 25 A10.5 M10 x 50 500 mm CP 6218.150 1000 mm CP 6218.110 2000 mm CP 6218.210 Bez nacinania gwintu! No threading! System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 5
18,0 kg CP 6218.700 10,3 kg CP 6218.620 Ø 25 Ø 19 3,6 kg CP 6218.600 1,5 kg CP 6218.640 0,6 kg CP 6212.900 Ø 180 Ø 180 4,2 kg CP 6218.300 System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 6
Ø 10 2 x Ø 5 x 20 CP 6212.380 CP 6212.600 CP 6212.620 CP 6212.700 CP 6212.740 CP 6218.600 CP 6218.700 2 x M5 x 16 = 2 Nm = 1 Nm System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 7
= 52 Nm Mocowanie za pomocą kołków/ Attachment by means of pins 4 x M12 Opcjonalnie: M10 2 x M10 x 25 2 x Ø 10 2 x Ø 10 Opcjonalnie Opcjonalnie System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 8
= 52 Nm 3 x M8 x 20 2 x Ø 10 2 x Ø 10 2 x M10 x 25 Opcjonalnie Opcjonalnie 7.2a 7.2b 3 x M8 x 20 7.2c = 35 Nm System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 9
4 x A10.5 = 52 Nm A10,5 = 30 Nm 2 x M5 x 16 = 1 Nm 7.2a 7.2b 7.2c 7.2d M10 x 55 M10 x 60 Opcjonalnie Opcjonalnie = 52 System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 10
CP 5050.423 4 x M10 x 50 3 x M8 x 20 = 52 Nm 4.2a 4.2b 3 x M8 x 20 4.2c = 35 Nm System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 11
4 x M10 x 50 2 x M5 x 16 4 x A10.5 = 52 Nm = 1 Nm System ramienia nośnego 120 Support arm system 120 System ramienia nośnego 180 Support arm system 180 System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 12
M6 x 25 M6 x 25 A6.1 = 9 Nm Obudowa z przyłączem ramienia nośnego Ø 130 mm Housing with support arm connection Ø 130 M6 x 25 A6.1 = 9 Nm System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 13
M6 x 25 A6.1 Obudowa z przyłączem ramienia nośnego Ø 180 mm = 9 Nm Housing with support arm connection Ø 180 Ø 100 4 x M6 4 x A6.1 = 9 Nm System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 14
Wstępnie zmontowany system ramienia nośnego wymaga odpowiednich zabezpieczeń podczas transportu! Pre-assembled support arm systems must be stabilised securely and protected appropriately for transportation! System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 15
Notatki/Notes System ramienia nośnego Rittal 180 – Instrukcja montażu...
Page 16
Climate control IT infrastructure Software & services RITTAL Sp. z o.o. The Park Warsaw – Budynek 3 · ul. Krakowiaków 48 · 02-255 Warszawa Tel.: (0 22) 310 06 00 · Fax: (0 22) 310 06 16 rittal@rittal.pl · www.rittal.pl...
