Instruction Manual IM01005031E
Eaton SPD Series
for mounting external to
electrical distribution equipment
Contents
Description
1.0 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2.0 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3.0 Operating features . . . . . . . . . . . . . . . . . . . . . . 9
4.0 Power Xpert SPD display menu . . . . . . . . . . 11
5.0 Power Xpert SPD user setup. . . . . . . . . . . . . 12
6.0 SPD display rotation . . . . . . . . . . . . . . . . . . . 21
7 .0 IEC approved models . . . . . . . . . . . . . . . . . . . 21
8.0 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . 22
9.0 Trouble shooting PX-SPD . . . . . . . . . . . . . . . . 23
10.0 Specifications. . . . . . . . . . . . . . . . . . . . . . . . 24
11.0 Ordering guidelines . . . . . . . . . . . . . . . . . . . 26
12.0 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Effective December 2020
Description
Page
Appendix G Web user error codes . . . . . . . . . . . 36
For additional information on the new PX-SPD
go to www.eaton.com/pxspd
Rev. 7
menu map - surge events . . . . . . . . 28
menu map - event log . . . . . . . . . . . 28
menu map - settings . . . . . . . . . . . . 29
menu map - identification . . . . . . . . 30
test sequence . . . . . . . . . . . . . . . . . 31
register map . . . . . . . . . . . . . . . . . . 32
. . . . . . . . . . . . . . . . . . 37
Page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SPD Series and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton SPD Series

Summary of Contents for Eaton SPD Series

  • Page 1: Table Of Contents

    Instruction Manual IM01005031E Effective December 2020 Rev. 7 Eaton SPD Series for mounting external to electrical distribution equipment Contents Description Page Description Page Appendix A Power Xpert SPD local display 1.0 Introduction ......2 menu map - surge events .

  • Page 2: Introduction

    ELECTRICAL SHOCK. ground while supporting power frequency voltage. The Eaton SPD Series is designed to mount on the wall (or other 1.4 Catalog numbering system vertical surface) as close as possible to the electrical cabinet.

  • Page 3: Installation

    You must refer to this diagram while wiring the SPD. CAUTION See Figure 9 - Figure 13. SPD Series type 1 and type 2 units do not require over current protection devices, fuses EATON SPD SERIES PRODUCTS MUST BE INSTALLED OR REPLACED or circuit breakers to operate correctly.
  • Page 4 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Figure 2. NEMA 1 (with flushmount) (suffix L) Eaton www.eaton.com...
  • Page 5 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Figure 3. NEMA 1 (suffix K) Figure 4. NEMA 4 - 4X (suffix N, P) (NEMA 4X not available with Power Xpert SPD) Eaton www.eaton.com...
  • Page 6 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Figure 5. NEMA 1 (with disconnect) (suffix M) Figure 6. NEMA 4-4X (with disconnect) (suffix O, Q) (NEMA 4X not available with Power Xpert SPD) Eaton www.eaton.com...
  • Page 7 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Figure 7. Flush-mount plate for 50-200 kA units in A NEMA 1 rated enclosure Eaton Catalog P/N: SPDGREYFLUSHMTKIT. Eaton www.eaton.com...
  • Page 8 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 BLUE / WHITE COMMON RED / WHITE NORMALLY OPEN ORANGE / WHITE NORMALLY CLOSED Figure 8. Sidemount form C wires Figure 11. 3-phase wye units Figure 9.

  • Page 9: Operating Features

    Effective December 2020 3.0 Operating features General The Eaton SPD Series comes in four feature packages: Basic, Standard, Standard with Surge Counter, and Power Xpert SPD. The operating specifics of each feature package are described below.
  • Page 10 Red LEDs: Illumination indicates a loss of protection, and that • one or more protective devices are now inactive and unavail- The Eaton Power Xpert SPD feature package display is shown in able for that phase. Red LEDs also indicate neutral to ground Figure 17 .

  • Page 11: Power Xpert Spd Display Menu

    Protection level – percentage of surge protection remaining in the device per phase. The Eaton Power Xpert SPD feature package includes a 20x4 Alarm status – status of the alarm “Protected” or “Active Alarm LCD display which on power up displays the device’s home Replace SPD”...

  • Page 12: Power Xpert Spd User Setup

    5.0 Power Xpert SPD user setup 5.1 General The Eaton Power Xpert SPD can be monitored through the local display or through a PC with a cat 5e cable and the PC’s web browser. Modbus, BACnet and HTTP are initially disabled to pro- vide cybersecurity protection.
  • Page 13 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 3. Left click on Ethernet and then right click to open the window shown below. Then click on Properties. Figure 25. Setting date and time 4.
  • Page 14 The change password window will open. Enter the default pass- word and then enter a new 6 digit alpha-numeric password and then click OK. Save password in a secure location to access the Web UI. If lost, contact Eaton’s Application Engineers, at 1-800- 809-2772, or email SPD@eaton.com. Eaton...
  • Page 15 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 PX-SPD enforces complex passwords and session time-out through User Management tab in the web UI. There are 4 levels of Password Complexity, defined as follows: Password complexity level –...
  • Page 16 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 The install certificate window will then open and then click on In the next window click on ‘Place all certificates in the follow- install certificate button.
  • Page 17 Figure 39. Select PX-SPD_Main_Processor Figure 36. Successful secure login 5.3.2 Upgrading firmware To update the firmware in the Power Xpert SPD, go to the Eaton website at www.eaton.com/PX-SPD and download the latest version firmware to a laptop or PC. Connect the laptop to the Power Xpert SPD via an ethernet cable and login to the SPD.
  • Page 18 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Login to the device and click on the General tab and verify the A dropdown will open displaying the options available to the SNTP server 1 has a green circle around it, as shown below.
  • Page 19 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Select the appropriate time zone from the dropdown list to the The Admin user can modify timeouts, number of concurrent right of Timezone. GMT-05:00 represents Eastern Standard Time, sessions and the number of failed login attempts.
  • Page 20 Refer to Appendix H for the BACnet register map. 5.3.5 Sensitivity setting Attention: Eaton does not recommend the customer modify the sensitivity setting without first contacting Eaton Customer Support at 1 800 809-2772 or email SPD@eaton.com.

  • Page 21: Spd Display Rotation

    7.0 IEC approved models The SPD display can be rotated on the SPD enclosure, up to 360 Eaton’s one-port low-voltage surge protective device delta mod- degrees. This allows you to position the display for the best visibil- els SPD120480D3M, SPD160480D3M and SPD200480D3M ity regardless of the position in which the SPD is installed.

  • Page 22: Troubleshooting

    Table 4, Troubleshooting chart. This troubleshooting chart identifies possible causes and solutions to the malfunc- tion. Further assistance may be obtained by calling Eaton’s Applications Engineers, at 1-800-809-2772 or email SPD@eaton. com, including being directed to the warranty process if appli- cable.

  • Page 23: Trouble Shooting Px-Spd

    One or more of the buttons were depressing during Clear buttons of any obstructions, if that doesn’t startup. resolve the matter contact Eaton Customer Support at 1-800-809-2772 or email SPD@eaton.com. LCD is turning off/on and there is no communication. Insufficient input voltage.

  • Page 24: Specifications

    Relay wire length (optional) 48” of 14AWG extend beyond the conduit hub RoHS compliant Internal disconnect (optional) Eaton 30 Amp FDC circuit breaker, type MCCB Input power frequency 50/60 Hz, Power Xpert SPD tested to 60 Hz only Power consumption (Basic units) 208Y, 220Y, 230L, 240S, 240D, and 240H voltage codes 0.5W...
  • Page 25 IEC 61643-11/EN 61643-11, Part 11: Test Class II. See Section 11.0 Ordering guidelines for specific models. Warranty 10 years, 15 years if you register on www.eaton.com/spd and then click the warranty registration icon. ROHS compliant Wire length and AWG Factory prewired with 48 inches of #10 AWG wire.

  • Page 26: Ordering Guidelines

    Time/date stamped surge events on phases A, B and C **Eaton’s delta catalog numbers SPD120480D3M, SPD160480D3M and SPD200480D3M meet the requirements of IEC 61643-11 / EN 61643-11, part 11: Test Class II, and are intended to be installed in applications with a degree of protection rated IP 20.

  • Page 27: Warranty

    ANY CONTRACT BETWEEN THE PARTIES. In no event will Eaton be responsible to the purchaser or user in contract, in tort (including negligence), strict liability or otherwise for any special, indirect, incidental or consequential damage or...

  • Page 28: Appendix A Power Xpert Spd Local Display Menu Map - Surge Events

    Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Appendix A Power Xpert SPD local display menu map - surge events ► >>> ► >>> ► >>> ► >>> Phase A LOW Event Log...

  • Page 29: Appendix C Power Xpert Spd Local Display Menu Map - Settings

    Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Appendix C Power Xpert SPD local display menu map - settings ENTER PASSWORD XXXXXX DATE: MM/DD/YYYY ► >>> ► >>> ► >>>...

  • Page 30: Appendix D Power Xpert Spd Local Display Menu Map - Identification

    Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Appendix D Power Xpert SPD local display menu map - identification ► >>> Catalog Number: IDENTIFICATION SPDxxxxxxx4x <<< ◄ ▼ ▲...

  • Page 31: Appendix E Power Xpert Spd Local Display - Test Sequence

    Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Appendix E Power Xpert SPD local display - test sequence 1. All LEDs turn red 6. Half pixels turn on 2. All LEDs turn yellow 7 .

  • Page 32: Appendix F: Power Xpert Spd Modbus Register Map

    Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Appendix F: Power Xpert SPD Modbus register map Power Xpert SPD Modbus register map (cont.) Register Name Attributes Description Product Serial Number UINT32 RO NV 32bit device serial number.
  • Page 33 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Power Xpert SPD Modbus register map (cont.) Register Name Attributes Description DHCP to Static IP addr lock (0) BOOL RW NV Default: FALSE...
  • Page 34 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Power Xpert SPD Modbus register map (cont.) Register Name Attributes Description 8207 Medium Surge Event Phase Indicator UINT8 RO Indicates in which the phase, medium surge event occurred.
  • Page 35 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Power Xpert SPD Modbus register map (cont.) Register Name Attributes Description 11499 Indicates the status of N-G Red LED BOOL RO Indicates the status of N-G red LED, 0:LED off 1:LED on. Indicates protection status on...

  • Page 36: Appendix G Web User Error Codes

    Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Power Xpert SPD Modbus register map (cont.) Register Name Attributes Description 12267 General log Index UINT16 RO Index points to the latest general event log...

  • Page 37: Appendix Hbacnet Map

    Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Appendix H BACnet map Analog objects Instance Object name Object description Object type Unit Access type COV increment Sensitivity Surge sensitivity No unit...
  • Page 38 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Appendix H BACnet map (Cont.) Device objects Object name Object type Access type Product Vendor Name BACnet Vendor Identifier Style Name...
  • Page 39 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev.7 to electrical distribution equipment Effective December 2020 Notes: Eaton www.eaton.com...
  • Page 40 Eaton SPD Series for mounting external Instruction Manual IM01005031E - rev. 7 to electrical distribution equipment Effective December 2020 Eaton Electrical Sector 1000 Eaton Boulevard Cleveland OH 44122 United States 877-ETN-CARE (877-386-2273 Eaton.com © 2020 Eaton Eaton is a registered trademark.
