Instruction Booklet IB158004EN
Eaton SPD Max Series
SPD Replacement
Instruction Manual
Effective October 2014
Contents
Description
Has Lost Protection . . . . . . . . . . . . . . . . . . . . . 3
Before Proceeding . . . . . . . . . . . . . . . . . . . . . . 3
3.0 SPD Max with Circuit Breaker . . . . . . . . . . . . . 4
4.0 SPD Max with Terminal Block . . . . . . . . . . . . . 7
6.0 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Page
Advertisement
Related Manuals for Eaton SPD Max Series
Summary of Contents for Eaton SPD Max Series
-
Page 1: Table Of Contents
Instruction Booklet IB158004EN Effective October 2014 Eaton SPD Max Series SPD Replacement Instruction Manual Contents Description Page 1.0 Determining Which SPD Device Has Lost Protection ..... 3 2.0 Confirm SPD Replacement Part Number... - Page 2 Instruction Manual This instruction manual details the field replacement of one or two Surge Protective Devices within an Eaton SPD Max Series device when the SPD Max is installed with the door hinge on the left when facing the device. Follow all Warnings and read this entire manual before servicing this device.
-
Page 3: Determining Which Spd Device Has Lost Protection
Protection Before Proceeding If the SPD Max Series device has a Catalog number ending in a R, Before proceeding, go to Appendix A and confirm the SPD replace- T, V or X, such as SPMxxxxxxxxR, your device contains one inter- ment part number you received matches the SPD Max Catalog Part nally mounted Surge Protective Device (SPD1). -
Page 4: Spd Max With Circuit Breaker
Effective October 2014 Instruction Manual 3.0 SPD Max with Circuit Breaker 1. Open the hinged door of the SPD Max Series enclosure by loos- WARNING ening, but not removing, the 7 screws holding the metal latches. ONLY LICENSED/QUALIFIED ELECTRICIANS WHO ARE TRAINED IN THE 2. - Page 5 Instruction Booklet IB158004EN Eaton SPD Max Series SPD Replacement Effective October 2014 Instruction Manual Figure 4. SPD Max Shown with the Load Side Dead Front Panel Open. Circuit Breaker Terminals Figure 5. Locate the Circuit Breaker Terminals. CAUTION 7 . Caution: Before proceeding verify no voltage is present on...
- Page 6 Instruction Booklet IB158004EN Eaton SPD Max Series SPD Replacement Effective October 2014 Instruction Manual 9. Carefully remove the neutral connection on the SPD (Wye and High Leg Delta models only) and ground ring terminal attached to the SPD (See Figure 6) and retain the hardware (screws and flat washers) for installation of the replacement SPD module.
-
Page 7: Spd Max With Terminal Block
National Electric Code (NEC), Canadian Electric Code (CEC), state and local codes, or other applicable country codes. 1. Open the hinged door of the SPD Max Series enclosure by loos- ening, but not removing, the 7 screws holding the metal latches. - Page 8 INSTALLATION AND SERVICE OF ELECTRICAL EQUIPMENT ARE TO INSTALL AND SERVICE THIS EQUIPMENT. HAZARDOUS VOLTAGES ARE PRESENT INSIDE THE SPD MAX SERIES ENCLOSURE DURING NORMAL OPERATION. FOLLOW ALL SAFE WORK PRACTICES AND LOCK OUT TAG OUT PROCE- DURES TO AVOID ELECTRICAL SHOCK AND ARC FLASH.
- Page 9 Instruction Booklet IB158004EN Eaton SPD Max Series SPD Replacement Effective October 2014 Instruction Manual Terminal Block Screws Figure 11. Location of Terminal Block and Terminal Block Screws. 7 . Caution: Before proceeding verify no voltage is present on the terminal block load terminals with the appropriate meter or voltage indicator verify that no voltage is present in any of the load side wiring.
- Page 10 Instruction Booklet IB158004EN Eaton SPD Max Series SPD Replacement Effective October 2014 Instruction Manual SPD Cable Hold Down Bracket and Hardware Screws and Flat Washers) Figure 13. Remove Four Mounting Screws. 10. Carefully remove the four screws securing the SPD module to the enclosure base (See Figure 13).
-
Page 11: Installation Of Replacement Spd Module
Instruction Booklet IB158004EN Eaton SPD Max Series SPD Replacement Effective October 2014 Instruction Manual 5.0 Installation of Replacement SPD Module CAUTION TO ACHIEVE THE BEST VPR PERFORMANCE, THE REPLACEMENT SPD MODULE’S PHASE WIRES SHOULD BE TRIMMED TO THE LENGTHS SPECI- FIED IN TABLE 1. - Page 12 13. Close the hinged door and secure the seven latches over the door and re-tighten the screws to 35 Lb-in.. 14. The Eaton SPD Max is now protecting critical electrical and elec- tronic equipment from damage by voltage transients and surges.
- Page 13 Instruction Booklet IB158004EN Eaton SPD Max Series SPD Replacement Effective October 2014 Instruction Manual Table 2. Appendix A. SPD Max Series Replacement SPD Catalog Part Numbers. Replacement SPD Replacement SPD SPM Max SPD Max Catalog Number Catalog Number Catalog Number...
-
Page 14: Warranty
Installation of replacement SPD module(s) does not extend the original manufacturer’s warranty period. Refer to the SPD MAX instruction booklet, IB158002EN, for complete warranty informa- tion. A copy of IB158002EN can be downloaded from the Eaton website at www.eaton.com/spd EATON www.eaton.com... - Page 15 Instruction Booklet IB158004EN Eaton SPD Max Series SPD Replacement Effective October 2014 Instruction Manual Notes: EATON www.eaton.com...
