- Page 1 TITAN DESIGN Instructions for ASSEMBLY and DISASSEMBLY of Temple Inclination...
- Page 2 1. DISASSEMBLING THE TEMPLE AC 336 (P 0000 11 0336 0000) Fold temple and press together directly Place disassembly stick as close as possible behind disassembly stick. to the inside of the hinge. (pictured red disassembly tool AC 336 not (pictured red disassembly tool AC 336 not currently available) currently available)
- Page 3 2. ASSEMBLING OF TEMPLE Support temple firmly by placing on the edge of Place opening of hook and decoration part a flat surface. in the same position. NOTE: Place pressure only on flat surface, not on lens fixation or decoration part.
- Page 4 3. ASSEMBLING OF TEMPLE Press in hook on hinge from the top down.
- Page 5 4. ADJUSTMENT OF INCLINATION Open temple up entirely Hold lens fixation firmly. Incline trim area TIP: Use universal mounting pliers for extra Hold temple with decoration part firmly. support.
