Summary of Contents for Silhouette Titan Minimal Art Series

  • Page 1 Titan Minimal Art Technical Instructions 2013...
  • Page 2 Inclination Inclinate here Picture shows exact position of inclination Hold titanium temple firmly at approx. 5 mm next to lens fixation. Adjust inclination at the beginning of the flat stamped part of the titanium temple but not beside lens fixation. Attention: do not bend temple!
  • Page 3 Inclination Inclinate here Picture shows handling procedure Hold titanium temple at firmly approx. 5 mm beside the lens fixation. Adjust inclination at the beginning of the flat stamped part of the titanium temple but not beside lens fixation. Attention: do not bend temple!
  • Page 4: Temple Shortening

    Temple Shortening Shorten Pull off temple with temple end diagonal cutter Squeeze metal inlay File down with round sharp edges pliers at the very end. Mount temple end.
  • Page 5 Do not over stretch or twist titanium temples as this may cause breakage.
