Summary of Contents for Silhouette SPX Connection

  • Page 1 SPX Connection Technical Instructions...
  • Page 2 Inclination 1. Hold lens fixation firmly. Enclose hinge and temple edge firmly and adjust inclination on titanium side Open temple completely as shown.
  • Page 3 Temple Opening Enlarge Reduce...
  • Page 4 Temple Disassembly 2. Close temple and press it through behind 1. Place temple removal tool at hinge, round part of temple removal tool. select neccessary diameter depending on distance between temple and lens. 3. Temple will get loose once clicked.
  • Page 5 Greasing the Hinge After cleaning, grease inside loop of hinge with high precision lubricant Teflon (P 0030) and mount temple.
  • Page 6 Temple Assembly 1. Place side part exactly at the holes in 2. Press temple into side part using round part the SPX temple. of temple removal tool.
  • Page 7 Adjusting of Temple Curve temple using large movements . Metal needle inside temple enables cold adjusting of temple ends. If necessary, slight heating to a maximum of 70°C is possible but never bend temple!
