SpectraMax ABS Instrument Installation Guide
To unpack the instrument:
1. Open the top of the box.
2. Lift the accessories tool box and the instrument from the package, and then place the
instrument on a level surface.
3. Remove the packing material from both ends of the instrument, remove the instrument
from the plastic bag, and then set the instrument down carefully on a level surface.
Connecting Instrument Cables
The power cord and USB cable connect to the ports on the rear of the instrument.
Illustration
1. Make sure that the power switch that is on the rear of the instrument is in the
Off position.
2. To use a computer to operate the instrument, connect the appropriate end of the
supplied USB cable to the USB port that is on the rear of the instrument, and then
connect the other end to a USB port on the computer.
6
Part Number
5064799
4400-0002 or 4400-0036
Note: Before you connect or disconnect the power cord, make sure that the power
switch that is on the rear of the instrument is in the Off position.
Description
USB computer connection cable, 3 meter (9.8 foot)
Power cord, 1 meter (3.3 foot)
