Riversoft
Water Softener
INSTALLER
MANUAL
WATER PURIFICATION

Advertisement

Table of Contents
loading

Related Manuals for Pentair Riversoft

Summary of Contents for Pentair Riversoft

  • Page 1 Riversoft Water Softener INSTALLER MANUAL WATER PURIFICATION...

  • Page 2: Table Of Contents

    Installer Manual Riversoft - Table of content Table of content Generalities ......... . 5 1.1.
  • Page 3 Volumetric regeneration ....... . . 47 5.7. Time clock regeneration (Riversoft 4 only) ....47 5.8.
  • Page 4 Installer Manual Riversoft - Table of content Operation ......... . . 55 7.1.

  • Page 5: Generalities

    Riversoft protects water pipes and connected water-carrying systems from scaling, respectively from malfunctions and damage caused by scaling; • the water softener series Riversoft is designed for continuous supply of water for different family sizes depending on the chosen model. Ref. MKT-IM-045 / A - 13.03.2020...

  • Page 6: Abbreviations Used And Glossary

    Installer Manual Riversoft - Generalities 1.5. Abbreviations used and glossary Assy............Assembly BLFC ............Brine Line Flow Controller DF............Down Flow DLFC ............Drain Line Flow Controller Inj ............Injector QC............Quick Connect Regen ............Regeneration SBV............Safety Brine Valve TC ............

  • Page 7: Procedure For Technical Support

    Pentair Quality System EMEA products benefit, under specific conditions, from a manufacturer warranty that may be invoked by Pentair’s direct customers. Users should contact the vendor of this product for applicable conditions and in case of a potential warranty claim.

  • Page 8: Safety

    Installer Manual Riversoft - Safety Safety 2.1. Safety pictograms definition CAUTION WARNING   Warns of a risk of minor injury or Warns against serious personal injury major material damage to the device and damage to health. or environment. DANGER MANDATORY ...

  • Page 9: Hazards

    Installer Manual Riversoft - Safety NOTE  Ensure that the serial label and the safety tags on the device are completely legible and clean. If necessary, replace them with new tags and put them in the same places. 2.3. Hazards All the safety and protection instructions contained in this document must be observed in order to avoid temporary or permanent injury, damage to property or environmental pollution.

  • Page 10: Hygiene And Sanitization

    Installer Manual Riversoft - Safety 2.4. Hygiene and sanitization 2.4.1. Sanitary issues Preliminary checks and storage • Check that the brine tank and the brine well are clean and free from burr, debris or any scraps; • check the integrity of the packaging. Check that there is no damage and no signs of contact with liquid to make sure that no external contamination occurred;...

  • Page 11: Hygiene Measures

    Installer Manual Riversoft - Safety 2.4.2. Hygiene measures DANGER  Do not use with water that is micro-biologically unsafe or of unknown quality without adequate disinfection before or after the softener. WARNING  Water softeners using sodium chloride for regeneration will add sodium to the water.

  • Page 12: Description

    Installer Manual Riversoft - Description Description 3.1. Introduction to softeners 3.1.1. Softening principles Softening is an ion exchange process where the hard ions are getting exchange by soft ions, typically sodium or potassium. This is achieved by placing the water in contact with an ion exchange resin and ensuring the contact time is appropriate for the flow rate to produce.
  • Page 13 Installer Manual Riversoft - Description The service and regeneration reaction can be done over and over, so softening systems last years. A softener consists of different components: • a tank, filled with softening resin; • a valve, that will direct the inlet water flow on the resin bed so that the softening or regeneration reaction can take place;...

  • Page 14: System Service & Regeneration Cycles (8-Cycles Operation)

    Installer Manual Riversoft - Description 3.1.2. System service & regeneration cycles (8-cycles operation) Service (downflow) — cycle C0 Untreated water is directed down through the resin bed and up through the riser tube. The hardness ions attach themselves to the resin and are removed from the raw water being exchanged on the resin beads against sodium ions.
  • Page 15 Installer Manual Riversoft - Description SERVICE BACKWASH BRINE DRAW/SLOW RINSE C1 and C5 REPRESSURIZE RAPID RINSE BRINE REFILL C4 and C6 Soft water Hard water Inlet Drain Media bead Outlet Media tank Brine Valve Brine tank Ref. MKT-IM-045 / A - 13.03.2020...

  • Page 16: Technical Specifications

    Installer Manual Riversoft - Description 3.2. Technical specifications 3.2.1. General Riversoft with bypass configuration Brine tank connection Inlet Drain Outlet Bypass Riversoft with manifold Overflow configuration Brine tank connection Inlet Drain Manifold Outlet Overflow Softener type Riversoft 4..........4 L Riversoft 8..........

  • Page 17: Performance Flow Rate Characteristics

    Installer Manual Riversoft - Description 3.2.2. Performance flow rate characteristics NOTE  Flow rates are indicative data. Maximum flow rate to produce in order to respect the required service velocity for an optimal ion exchange upon resin manufacturers recommendation, regardless of the inlet pressure.
  • Page 18 Drain line ..........½" Overflow drain line ......... ½" Electrical Controller Operating Voltage ....12 VAC (requires use of Pentair Water supplied transformer) Input Supply Frequency......50 or 60 Hz Motor Input Voltage ........ 12 VAC Controller Power Consumption ..... 6 W average Protection rating........

  • Page 19: Outline Drawing

    Installer Manual Riversoft - Description 3.3. Outline drawing Riversoft 4 Bypass configuration Manifold configuration Riversoft 8 Bypass configuration Manifold configuration Ref. MKT-IM-045 / A - 13.03.2020 19 / 90...
  • Page 20 Installer Manual Riversoft - Description Riversoft 15 Bypass configuration Manifold configuration Riversoft 30 Bypass configuration Manifold configuration 20 / 90 Ref. MKT-IM-045 / A - 13.03.2020...

  • Page 21: Description And Components Location

    Installer Manual Riversoft - Description 3.4. Description and components location Display Delayed regeneration indicator Time button Salt button Regeneration button Camshaft indicator Regeneration setting button Injector & screen Refill flow controller Valve connection Cover locker Flow indicator Motor Optical sensor...
  • Page 22 Installer Manual Riversoft - Description Manifold configuration Outlet Locking bars Brine tank tube connection Manifold Bypass configuration Turbine Inlet Cable gland D rain Locking bars Outlet 90° Elbow Drain Brine tank tube connection Bypass Meter cable Inlet Flow controller Flow controller...

  • Page 23: Softener's Available Options

    Installer Manual Riversoft - Description 3.5. Softener’s available options 3.5.1. Safety brine valve To avoid overflow and to get a better softener operation, a safety brine valve can be installed. Operation Remove the softener covers, see 8.5.2. Covers removal (softener and valve), page 63.

  • Page 24: Installation

    Installer Manual Riversoft - Installation Installation 4.1. Warnings CAUTION  Do not lay down or flip over the softener at any time. The media may paste to the upper distributor thus obstructing its slots and may therefore compromise the softener operation.

  • Page 25: Water

    Installer Manual Riversoft - Installation 4.3.2. Water CAUTION  Do not treat water over 38°C, hot water would damage the softener and void warranty. If you are on a private well system, check minimum water pressure with an accurate gauge (gauges on older water systems are often inaccurate).

  • Page 26: Mechanical

    Installer Manual Riversoft - Installation • the power outlet must be grounded; • to disconnect power, unplug the AC cable from its power source; • do not use any extension cord; • locate cord where it cannot be accidentally unplugged or cause any bodily harm.

  • Page 27: Integration Constraints

    Installer Manual Riversoft - Installation 4.4. Integration constraints Location of a water treatment system is important. The following conditions are required: CAUTION  The surface for installation (platform or floor) must be solid, flat and level. MANDATORY  Drain must be capable of handing a maximum backwash flow rate of 19 L/min.

  • Page 28: Softener Connection To Piping

    Installer Manual Riversoft - Installation 4.5. Softener connection to piping  To prevent your softener from incoming sediment and iron particles, Pentair recommends the installation of a 100 μm pre-filter upstream the unit. MANDATORY  The unit should be installed in accordance with the manufacturer’s recommendations and meet all applicable plumbing codes.

  • Page 29: Installation Layout

    Installer Manual Riversoft - Installation 4.5.2. Installation layout Bypass configuration Softener Power supply Hard water pipe Soft water pipe Drain water pipe ½" overflow line Drain Manifold configuration Softener Power supply Hard water pipe A manual bypass system have to be...

  • Page 30: Tools And Material Required For Installation

    Installer Manual Riversoft - Installation 4.5.3. Tools and material required for installation NOTE  Not all listed tools may be necessary for installation. Read installation procedures before starting to determine if additional tools are necessary. NOTE  Valves, grounding straps, wire, clamps and wall pipes are not supplied with the water softener.

  • Page 31: Inspection/Preliminary Assembly

    Installer Manual Riversoft - Installation 4.5.4. Inspection/preliminary assembly 4.5.4.1 Inspection MANDATORY  Any missing or faulty equipment must be specified on the transport documents. Notify the transporter company and supplier immediately. NOTE  In some case, some damage can only be observed when commissioning the softener.
  • Page 32 Installer Manual Riversoft - Installation Make necessary piping changes for connecting the softener inlet and outlet to the home piping. Make sure not to reverse inlet and outlet. Installation of supplied bypass is mandatory, see 4.5.2. Installation layout, page 29.

  • Page 33: Water Supply Line And Bypass Connections

    Installer Manual Riversoft - Installation 4.5.6. Water supply line and bypass connections 4.5.6.1 Water supply line The connections should be hand tightened using PTFE (plumber’s tape) on the threads if using the threaded connection type. In case of heat welding (metal type connection), the connections should not be made to the valve when soldering.
  • Page 34 Installer Manual Riversoft - Installation • The diagrams above illustrate how the flexible piping connection should be mounted; • in order to adequately compensate the tank elongation the flexible tubes must be installed horizontally; • should the flexible piping connection be installed in vertical position, instead of compensating the elongation, it will create additional stresses on the valve &...
  • Page 35 Installer Manual Riversoft - Installation 4.5.6.2 Bypassing • Softener with bypass configuration: a bypass valve system is provided with the installation kit. • Softener with manifold configuration: a bypass valve system have to be installed upstream the installation (not provided in the installation kit).
  • Page 36 Installer Manual Riversoft - Installation 4.5.6.3 Bypass assembly NOTE  The following procedure is only valid for softener with bypass configuration. The bypass assembly connects to the water system by means of a connector assembly. The connector is secured to the plumbing and then inserted into the bypass. Clips are used to hold it in place.
  • Page 37 Installer Manual Riversoft - Installation 4.5.6.4 Bypass tips • Before removing a clip on the softener, shut off water supply and relieve system pressure. Do not forget to put back the clip on the softener before opening water supply. •...

  • Page 38: Drain Line Flow Controller

    Installer Manual Riversoft - Installation 4.6. Drain line flow controller The DLFC requires assembly before use. NOTE  The plumbing connectors should not be installed. See 4.5.6.2 Bypassing, page 35. Using a PTFE (plumber’s tape), wrap it over threads of the flow controller (2).

  • Page 39: Drain Line Connection

    Installer Manual Riversoft - Installation 4.6.1. Drain line connection NOTE  Standard commercial practices are expressed here. Local codes may require changes to the following suggestions. Check with local authorities before installing a system. CAUTION  The drain line plastic elbow must always be hand-tighten without using the elbow as a lever....
  • Page 40 Installer Manual Riversoft - Installation If available, use a floor drain or sump drain, but it is also possible to use a sump pit, dry well, clothes washer drain, laundry tub or sanitary sewer line with sink type trap. The drain line should be as short as possible and the unit should not be more than 12.2 m from the drain.

  • Page 41: Brine Line Connection

    Installer Manual Riversoft - Installation 4.6.2. Brine line connection NOTE  The brine line is internal and is already connected. 4.6.3. Overflow line connection In the event of a malfunction, the brine tank overflow fitting will direct “overflow” to the drain instead of spilling on the floor.

  • Page 42: Electrical Connection

    Installer Manual Riversoft - Installation 4.6.4. Electrical connection 4.6.4.1 Softener connection NOTE  Use the fairlead (1)to block the power supply cable and prevent accidental disconnection. Manifold configuration Bypass configuration Power supply Power supply 4.6.4.2 Meter connection NOTE  During shipping, the cable from the back of the controller to the meter assembly may have been disconnected.
  • Page 43 Installer Manual Riversoft - Installation 4.6.4.3 Controller connection AC transformer cable connection Motor and optical sensor cable connection Meter cable connection AC transformer cable connection Ref. MKT-IM-045 / A - 13.03.2020 43 / 90...

  • Page 44: Programming

    Installer Manual Riversoft - Programming Programming NOTE  Menus are displayed in a defined and incremental order. NOTE  After 5 seconds without keypad input, the unit returns to normal operation mode and display the time of day. NOTE ...

  • Page 45: Commands

    Installer Manual Riversoft - Programming 5.2. Commands 1. Camshaft indicator A column of windows provides a visual indicator of the camshaft rotation. The manual regeneration button when pressed initiates either a - Manual delayed regeneration or immediate regeneration. regeneration button 3.

  • Page 46: Quick Program Guide

    Installer Manual Riversoft - Programming 5.3. Quick program guide Parameter Default Units of Range of values Notes description value measure hour: Time of day 0:00 - 23:59 12:00 minute From 0.2 kg to 1.0 kg by increments of 0.05 kg;...

  • Page 47: Brine Dosage

    5.0 m to 9.5 m by increments of 0.5 m (10 increments). 5.7. Time clock regeneration (Riversoft 4 only) Set the time between each regeneration. Press until desired interval appears then release. → Range from 0 through 30; 0 = Disabled;...

  • Page 48: Calendar Override Setting

    Installer Manual Riversoft - Programming 5.8. Calendar override setting The controller needs a method to set days between regeneration for regulatory requirements and in cases when the flow sensor has failed. Press and hold for 3 seconds. → The programmed calendar override is displayed.

  • Page 49: History Values

    Installer Manual Riversoft - Programming 5.11. History values The controller features a review level that displays the operation history of the system. To access history values : Press and hold simultaneously for 3 seconds. → To view the "H" levels.

  • Page 50: Commissioning

    Installer Manual Riversoft - Commissioning Commissioning 6.1. Softener commissioning 6.1.1. Water filling, draining and waterproofness inspection Once the previous initial programming steps are performed, and that the softener is in place and hydraulically connected to the main water line (see 4.5.5. Softener installation, page 31), the unit can be started up.

  • Page 51: Quick Cycling

    Installer Manual Riversoft - Commissioning 4. Fill the media tank with water. → While the controller is in cycle C1 (Backwash), open the water supply valve very slowly to approximately the ¼ open position. CAUTION  If opened too rapidly or too far, media may be lost out of the tank into the valve or the plumbing.

  • Page 52: Startup

    (1) setting iteratively until the residual hardness correspond to the value used when programming the hardness parameter. NOTE  Pentair advise to set a residual hardness between 50 and 100 mg/L of CaC0 52 / 90 Ref. MKT-IM-045 / A - 13.03.2020...

  • Page 53: Additional Tips

    Installer Manual Riversoft - Commissioning 6.1.4. Additional tips • When the controller is first plugged in, it may display the message "E3", this means that the controller is rotating to the home position. If the "E2" is displayed, check that the incoming power frequency matches the controller;...

  • Page 54: Sanitization By Electrochlorination Process

    Installer Manual Riversoft - Commissioning 6.2.2.1 5.25% Sodium hypochlorite If stronger solutions are used, such as those sold for commercial laundries, adjust the dosage accordingly. Dosage Polystyrene resin: set 1.25 mL per liter of resin. Brine tank softeners Backwash the softener and add the required amount of hypochlorite solution to the well of the brine tank.

  • Page 55: Operation

    Installer Manual Riversoft - Operation Operation 7.1. Display 7.1.1. During operation • The current time in 24 hours is displayed on 2 digits (minutes are not displayed). • The flow indicator blinks ON and OFF when water is flowing. 7.1.2. During regeneration •...

  • Page 56: Immediate Regeneration

    Installer Manual Riversoft - Operation 7.2.2. Immediate regeneration Press and hold for 3 seconds to initiate immediate manual regeneration. → The controller will display a cascading symbol "--" as it cycles to backwash. → The controller will proceed through a complete regeneration.

  • Page 57: Maintenance

    The maintenance and service operation must be done by qualified personnel only. Failure in respecting this may void the warranty NOTE  According to your softener configuration (Riversoft 4, 8, 15 or 30), the maintenance procedure might be slightly different due different lids. In all cases the same principle is applicable. 8.1.

  • Page 58: Regeneration Test

    Installer Manual Riversoft - Maintenance 8.1.3. Regeneration test 1. Check condition of brine tank and any associated equipment. 2. Check salt level in brine tank. 3. Initiate regeneration test. → Check brine draw during brine draw stage and make sure of proper function.

  • Page 59: Maintenance Instructions

    Installer Manual Riversoft - Maintenance Items 1 year 2 year 3 year 4 year 5 year Optical sensor Check Check Check Check Replace Inlet hardness Check Check Check Check Check Check/adapt Check/adapt Check/adapt Check/adapt Check/adapt Residual mixing screw if mixing screw if...

  • Page 60: Adding Salt

    8.3. Adding salt  Scan this QR code to download the Salt Reminder application from Pentair in order to ensure refilling the salt in the brine tank when required.  Do no fill the brine tank with too much salt if you are approaching to brine tank cleaning date.
  • Page 61 Installer Manual Riversoft - Maintenance Ref. MKT-IM-045 / A - 13.03.2020 61 / 90...

  • Page 62: Recommendations

    Installer Manual Riversoft - Maintenance 8.4. Recommendations 8.4.1. Use original spare parts CAUTION  To ensure correct operation and safety of the device, only use original spare parts and accessories recommended by the manufacturer. Parts to keep in stock for potential replacements are motor and optical sensor, controller, transformer, injectors, flapper kit, o-ring kit, refill controller and DLFC.

  • Page 63: Covers Removal (Softener And Valve)

    Installer Manual Riversoft - Maintenance 8.5.2. Covers removal (softener and valve) Operation CAUTION  Do not pull on the cables. Release the connectors from controller (2) by pressing on their locking clips. Remove the softener cover (1). Turn the locking clip (3) on the left to unlock the controller (2).

  • Page 64: Brine Tank And Brine Well Cleaning

    Installer Manual Riversoft - Maintenance 8.5.3. Brine tank and brine well cleaning Operation Remove the softener cover (1). Open the brine tank cover (4). Remove the remaining salt from brine tank (5). Remove the brine well cover (3). Remove the remaining brine from brine well (2).
  • Page 65 Installer Manual Riversoft - Maintenance Ref. MKT-IM-045 / A - 13.03.2020 65 / 90...

  • Page 66: Cleaning The Refill Flow Controller

    Installer Manual Riversoft - Maintenance 8.5.4. Cleaning the refill flow controller Operation Remove the softener cover, see 8.5.2. Covers removal (softener and valve), page 63. Using a Torx key, unscrew and extract the refill flow controller (3). Clean the refill flow controller (3) using compressed air or with a soft brush.

  • Page 67: Cleaning Injector And Injector Screen

    Installer Manual Riversoft - Maintenance 8.5.5. Cleaning injector and injector screen Operation Remove the softener cover, see 8.5.2. Covers removal (softener and valve), page 63. Using a Torx key, unscrew and extract the injector cap (3). CAUTION  Take care not to damage the injector (2)....

  • Page 68: Controller Replacement

    Installer Manual Riversoft - Maintenance 8.5.6. Controller replacement Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. CAUTION  Do not pull on the cables. Release the connectors (1) from controller by pressing on their locking clips.

  • Page 69: Other Wear And Tear Parts

    Installer Manual Riversoft - Maintenance 8.5.7. Other wear and tear parts 8.5.7.1 Cleaning the backwash flow controller Operation NOTE  The following procedure is only applicable in the bypass configuration. Remove the softener cover, see 8.5.2. Covers removal (softener and valve), page 63.
  • Page 70 Installer Manual Riversoft - Maintenance 8.5.7.2 Manifold/bypass removal Operation NOTE  Depending on the installation configuration, the valve may be equipped with a manifold or a bypass. The following procedure applies to both configuration. Remove the softener cover, see 8.5.2. Covers removal (softener and valve), page 63.
  • Page 71 Installer Manual Riversoft - Maintenance 8.5.7.3 Motor and camshaft replacement Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Disconnect the motor (2) from the optical sensor (1). Loosen the two screws (4) and remove the clamp (3).
  • Page 72 Installer Manual Riversoft - Maintenance 8.5.7.4 Optical sensor replacement Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Remove the motor and camshaft, see 8.5.7.3 Motor and camshaft replacement, page 71. The optical sensor (1) is clipped on the front edge of the top plate, gently press on the clips to release the optical sensor (1) from its location.
  • Page 73 Installer Manual Riversoft - Maintenance PAGE INTENTIONALLY LEFT BLANK Ref. MKT-IM-045 / A - 13.03.2020 73 / 90...
  • Page 74 Installer Manual Riversoft - Maintenance 8.5.7.5 Cleaning / replacing flappers Operation Remove the softener and valve covers, see 8.5.2. Covers removal (softener and valve), page 63. Remove the motor and camshaft, see 8.5.7.3 Motor and camshaft replacement, page 71. Remove the optical sensor, see 8.5.7.4 Optical sensor replacement, page 72.
  • Page 75 Installer Manual Riversoft - Maintenance Ref. MKT-IM-045 / A - 13.03.2020 75 / 90...
  • Page 76 Installer Manual Riversoft - Maintenance 8.5.7.6 Disassembling/assembling valve from/on tank Operation Remove the softener cover, see 8.5.2. Covers removal (softener and valve), page 63. Release the tube (1) from push-fit fitting (2). Unscrew, counter-clockwise, the valve (4) from tank (3).
  • Page 77 Installer Manual Riversoft - Maintenance ¼ turn ½ turn Point 0 Point 0 Ref. MKT-IM-045 / A - 13.03.2020 77 / 90...

  • Page 78: Troubleshooting

    Installer Manual Riversoft - Troubleshooting Troubleshooting 9.1. Controller Err. code Cause Solution Program settings have been Press any button. If "E 1" does not corrupted. clear. Replace the controller. Disconnect and reconnect the power. If Controller power does not match 50 or problem is not solved, replace 60 Hz.

  • Page 79: Valve

    Installer Manual Riversoft - Troubleshooting 9.2. Valve Issue Cause Reset and recovery Valve disc cannot close because of Flowing or Remove debris. debris. dripping water at drain or brine line Replace the spring. See 8.5.7.5 Valve stem return spring is weak.

  • Page 80: System

    Installer Manual Riversoft - Troubleshooting 9.3. System Issue Cause Reset and recovery Control brine dosage setting and Improper regeneration. repeat regeneration. Hard water Leaking of external bypass valve. Replace bypass valve. leakage after O-ring around riser pipe damaged. Replace o-ring.

  • Page 81: Spare Parts

    Installer Manual Riversoft - Spare parts Spare parts NOTE  There are no user serviceable parts in the AC wall mount adapters, motor or control board. 10.1. Softener Ref. MKT-IM-045 / A - 13.03.2020 81 / 90...
  • Page 82 Softener back cover for 30, 15 and 8 models CABCOVCYLID Softener front cover for 30, 15 and 8 models 368606H14#9-EU Autotrol 368 valve for Riversoft 30 model (no bypass) 368606BPJ33#10- Autotrol 368 valve for Riversoft 30 model (with bypass) 368606F14#7-EU Autotrol 368 valve for Riversoft 15 model (no bypass)
  • Page 83 Installer Manual Riversoft - Spare parts Packaging Item Part number Description quantity CM-BASE13 Tank base support for 4 model Q-0818-A8 Tank for 8 model Q-0613-A8S Tank for 4 model 27827 Riser tube for 30 and 15 models 3028254 Riser tube for 8 and 4 models...

  • Page 84: Valve

    Installer Manual Riversoft - Spare parts 10.2. Valve Packaging Item Part number Description quantity AC Wall Mount Adapters 1000813 230 VAC, 50 Hz, British plug 1000814 230 VAC, 50 Hz, European plug Kit, service, valve 368-606b 4001891 Kit, service, valve 368-606b, 14, WD...
  • Page 85 Installer Manual Riversoft - Spare parts Packaging Item Part number Description quantity 3022012 Top plate 1235373 Module, sensor, photo interrupter 1234170 Top plate screw no 8 x 9/16” 3022017 Spring, top plate 3022014 Camshaft, 7 cycle 1000589 Pillow block cap...

  • Page 86: Piping

    Installer Manual Riversoft - Spare parts 10.3. Piping Manifold configuration Bypass configuration 86 / 90 Ref. MKT-IM-045 / A - 13.03.2020...
  • Page 87 Installer Manual Riversoft - Spare parts Packaging Item Part number Description quantity 3031825 Kit, O-ring manifold 4000970 ¾” BSP adapter - black 3027832 Fixing clip 4000886 368 Bypass 40576 I/O clip 4001604 Kit, 1” BSP connectors 4000996 Drain elbow, plastic, ½"...

  • Page 88: Disposal

    This will help to reduce the impact on the environment, health, safety and help to promote recycling. Pentair does not collect used product for recycling. Contact your local recycling center for more information.
  • Page 89 Installer Manual Riversoft - Disposal PAGE INTENTIONALLY LEFT BLANK Ref. MKT-IM-045 / A - 13.03.2020 89 / 90...
  • Page 90 www.pentairaquaeurope.com...
