1.4.2 Load diagram

IRB 1200 - 7/0.7
xx1300000371
Product specification - IRB 1200
3HAC046982-001 Revision: O
0,60
0,50
0,40
0,30
3 kg
0,20
4 kg
5 kg
6 kg
7 kg
0,00
0,10
0,00
© Copyright 2021 ABB. All rights reserved.
1 kg
2 kg
0,20 0,30
L (m)
