Installation
10
3.2
Installation conditions
3.2.1
Methods of installation
The analyzer can be mounted in three ways:
• As a standalone desktop unit
• Mounted to the wall (option F1)
• Mounted on a base frame (option F2)
Fig. 1:
Dimensions
785 (30.9)
600 (23.6)
TOCII CA72TOC
400 (15.8)
50
(1.97)
mm (inch)
Endress+Hauser
a0012435
