TOCII CA72TOC
Endress+Hauser
Step Display
REPLACE HOSE P1/4
NEW VOLUME DELIVERED x.x ml
[>] START/STOP PUMP 1 (60sec)
[E] TO CONFIRM
16
REPLACE HOSE P1/4
CONNECT HOSE P1
[E] TO CONFIRM
17
REPLACE HOSE P1/4
SWITCH VALVE TO BYPASS
FILL HOSE WITH SAMPLE
[>] START/STOP PUMP 1 (100%)
[E] TO CONFIRM
18
REPLACE HOSE P1/4
FILL STRIP AND SEPARATION CHAMBERS
Description
Press the [E] key.
1. Connect hose P1 at the pressure side.
2. Press the [E] key.
1. Set the manual valve to bypass.
2. Using pump P1, pump the sample as
far as the strip chamber.
3. Press the [E] key.
Automatic filling of the strip chamber,
conditioning of the strip chamber with
active acid dosing
XXX
Maintenance
