Maintenance
100
1
2
3
4
5
P1
Fig. 56: Strip and separation chamber
1 pH sensor
2 Strip chamber cover
3 Strip chamber thread adapter nut
4 Coupling
5 Strip chamber
6 Coupling (drain)
7 Separation chamber thread adapter nut
Step Display
1
S E R V I C E
PUMPS
CALIBRATION
CLEANING
FILTERS
8
9
10
11
12
13
14
SCREEN FLUSH
POWER-FLUSH
BYPASS-SCREEN
STRIPPER+SEPARATION
OPEN GAS CICUIT
COMBUSTION PIPE
LEAKAGE TEST
TOCII CA72TOC
6
7
6
9
7
P2
10
11
8
12
13
14
Separation chamber
Separation chamber cover
Magnetic stir bar
Glass bead
Glass frit
O-ring
Coupling (stripping gas connection)
