To Operate Mouthvent; To Operate Top Vents; To Remove/Replace Shield - Arai Defiant-X Operation Instructions Manual

CLOSE CLOSE
OPEN
CLOSE
①
④
CLOSE CLOSE
CLOSE OPEN
②
⑤
English

TO OPERATE MOUTHVENT

To open, slide the tab on each side outward. To close, slide each tab as shown.

TO OPERATE TOP VENTS

Simply push the switches/levers on each vent to open/close the vents.
NOTE :
Do not use oils or waxes to lubricate vents or other moving parts.
If you must lubricate such components, sparingly use the silicone lubricant
supplied with your helmet for eyeport trim dressing.
③

TO REMOVE/REPLACE SHIELD

To remove, place shield in the fully open position ①. Push the side pod
release lever from the front edge of the side pod backward ② to release
the side pod ③.
⑥
Then lower the shield until the brass stud of the shield moves into the red
hole of the base plate ④. Remove the shield from the spring clips ⑤＆⑥,
and repeat for the other side.
5
