4) TouchLink
Step 2. The indicator
will start blinking green
and stay solid for 10s
when pairing is
succeded. Time out
15mins.
Step 3. Bring the
remote within 10cm of
the smart dimmer and
set the remote into
TouchLink
commissioning.
Note:
a. When both devices (dimmer and remote) are not included in a Zigbee Network, each
dimmer can link with max. one remote.
b. When both devices are included in the same Zigbee network, each dimmer can link with
max 30 remotes.
c. For Philips Hue Hubs and Amazon Echo Plus, add remote and device to network first then
touchlink.
5) Find and Bind
Note: Make sure the device and remote already added to the same Zigbee network
Step 1. Press the reset
button for 5 times.
Step 3. Set the remote
into find and bind mode
and enable it to find and
bind commisioning.
Please refer to the
manual for instructions.
Trailing Edge
Trailing Edge
Step 1. Press the
reset button for 4
times.
Step 4. The light will
blink 10 times when
Touchlink succeded.
Step 2. The indicator
will start blinking
yellow and stay solid
for 10s.
Step 4. There shall be
an indication on the
remote that it binds
the device successfully
and can control it.
