EcoDim Eco-Dim.10 Zigbee User Manual page 4

Smart Dimmer Module 250W LED
Item NO. Eco-Dim.10 Zigbee
Trailing Edge
√ Zigbee support
√ Suitable for several home automation apps
√ Voice support (Amazon Alexa & Google Assistant / Homey)
√ Works with push-button (momentary switch)
√ Optimal dimmable & light stability
√ Suitable for 250W LED
√ Saves and restores the last status after a power failure
√ MIN and MAX light adjustment and dimming speed
√ Suitable for 90% of all LEDs
√ Does not require a neutral wire, 3 wired connection available
√ Soft start system
√ Noiseless dimming
Min. Setting
To set the minimum light level.
Max. Setting
To set the maximum light level.
Dimming Speed. Setting
To set dimming speed.
LED Indicator
Indicates resets and when the dimmer is
in pairing mode
Reset Button
To set the dimmer to factory setting or to
pair mode.
1
