MIN adjustment: Switch on the lights, insert a screwdriver in MIN and
turn to the left. When the light becomes unsteady, turn slightly back to
the right so that the light remains steady.
MAX adjustment: Switch on the lights, insert a screwdriver in MAX and
turn to the right. When the light becomes unsteady, turn slightly back to
the left so that the light remains steady.
Dimming Speed adjustment: Insert a screwdriver in Speed, clockwise to
increase the dimming speed when you push the momentary switch, vice
versa.
4. Zigbee Setting
1). Factory Reset
Step 2. When the led
indicator stays red for
10S the reset is
finished.
Please Note:
This procedure should only be used when the primary controller is
inoperable.
All configuration will be reset after the device is reset or removed from the
network.
Trailing Edge
Step 1. Press the
reset button for
5s.
