BALI TV UNIT OMO
Assembly Instructions -
Dimensions
Width - 120cm
Depth - 40cm
Height - 45cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
xxx/xxxx
xxx/xxxx
issue 2 12/08/'16

Advertisement

loading
Need help?

Need help?

Do you have a question about the BALI TV UNIT OMO and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos BALI TV UNIT OMO

  • Page 1 BALI TV UNIT OMO Assembly Instructions - xxx/xxxx Please keep for future reference xxx/xxxx Dimensions Width - 120cm Depth - 40cm Height - 45cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
  • Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly Check you have all the Do not stand on the panels, this We do not components and tools listed on could cause damage. recommend the use pages 2 and 3.
  • Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline:08456 400800 Please check you have all the panels listed below T op Right side (120 x 39.7cm) (39.6 x 39cm) Bottom Left side (108.2 x 38cm) (39.6x 39cm) F r o n t s id e w i t h b a n d ing...
  • Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Locking pin x 17 Locking nut x 17 Short wood dowel x 14 Long wood dowel x 4 Foot pad x 6...
  • Page 5 Assembly Instructions Step 1 Step 1 and 2 Fitting lock pin Note: Assemble on a soft level surface or on the original packing material to avoid damaging the unit or your floor. Note: It would be useful to ask someone to help you at this stage.
  • Page 6 Assembly Instructions Step 3 and 4 Fitting center and bottom and bottom support a:First Insert Short Dowels into Center right Center left Attach the Center right and Center left 6 onto the Bottom with Long wood screw to tighten. Use Long wood screw fix Bottom post Fitting right side and left side .
  • Page 7 Assembly Instructions Step 5 and 6 Fitting foot pad a:Sides,Stick Foot pad onto the unit. Fitting the top panel Note: It would be useful to ask someone to help you at this stage. Insert Long wood dowel into Right side Left side Insert Short wood dowel into Center right...
  • Page 8 Assembly Instructions Step 7 and 8 Fitting back. se Screws to fix Back panel onto the unit. Fitting doors brackets and doors knobs. Use Screws to fix Door brackets onto Doors Use Screws to fix Handles onto Doors...
  • Page 9 Assembly Instructions Step 9 and finish Finishing the door Note: It would be useful to ask someone to help you at this stage. Use Screws to fix Doors onto the unit. Fitting adjustable shelf. Insert Shelf support into the holes in the unit. Note:Adjust the shelf supports to the desired height.
