Wide Media Unit
Assembly Instructions -
Dimensions
Width - 60.5 cm
Depth - 19.6 cm
Height -113 cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline
Argos = 0345 6400800
Please keep for future reference
457/2156
625/9563
651/5070
issue 05/08/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Wide Media Unit
Summary of Contents for Argos Wide Media Unit
- Page 1 Wide Media Unit Assembly Instructions - 457/2156 Please keep for future reference 625/9563 651/5070 Dimensions Width - 60.5 cm Depth - 19.6 cm Height -113 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly To reduce Check you have all the During assembly do not stand the likelihood of components and tools listed on or put weight on the product, this could cause damage.
- Page 3 If you have damaged or missing components, Components - Panels call the Customer Helpline Argos = 0345 6400800 Please check you have all the panels listed below Unfinished edge Unfinished edge Top panel x 1 (60.5 x 13.1cm) Bottom panel x 1 (60.5 x 19.6cm)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Nail x 38 38mm Screw x 12 30mm dowel x 56 Stickers x 8 12mm Screw x 2...
- Page 5 Assembly Instructions Step 1 Step 1 Insert dowels Insert dowel into middle panels b: Insert dowel into shelf panel side panel X 16...
- Page 6 Assembly Instructions Step 2 Step Attaching panels a: Attaching panel using dowel Finished edge as shown. Attention to the position of shelf...
- Page 7 Assembly Instructions Step 2 Step Attaching panels b: Attaching the side panels with screw c: Attaching the top panel onto unit with screw...
- Page 8 Assembly Instructions Step 2 Step Attaching panel d: Attaching the bottom panel onto unit with screw Step 3 Step Attaching back panels a: Turn the unit up side down. Lift with care.
- Page 9 Assembly Instructions Step 3 Step Attaching back panels b: Attaching the back panel . One piece first, using nail Don’t put the nail too close to the corner to avoid the screw penetrate the panel. suggest to add a nail in the middle of the back panel to reinforce the structure X 38...
- Page 10 Assembly Instructions Step 3 Step Attaching back panels d: Fit the wall strap onto the back of unit with screw Step 4 Step Paste sticker Paste sticker onto the screws on top panel and side panels.
- Page 11 Drill 7mm hole and insert wall plug Before drilling, check wall for hidden pipes and cables. Reposition storage unit and fix wall strap using screw If you need help or have damaged or missing parts, call the Customer Helpline Argos = 0345 6400800...
-
Page 12: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
