Venice - Entertainment Unit
Assembly Instructions -
Dimensions
Width - 117cm
Depth - 39cm
Height - 48.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
365/5397
339/1077
MADE IN
BRITAIN
Issue 2 - 20/01/15
Advertisement
Related Manuals for Argos Venice Entertainment Unit
Summary of Contents for Argos Venice Entertainment Unit
- Page 1 Venice - Entertainment Unit Assembly Instructions - 365/5397 Please keep for future reference 339/1077 Dimensions Width - 117cm Depth - 39cm MADE IN Height - 48.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 2 - 20/01/15...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 21kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below (D1968A) Left Side Right Side (D1900A) (D1901A) (1166 x 391mm) (448 x 389mm) (448 x 389mm) Drawer Front...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 large metal dowels into the holes shown on the back of the drawer front Note: Tighten metal dowels up fully against...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 7 Fit the wedgefixes Turn the drawer assembly over. Slide 3 wedgefixes into the small groove located on the back of the drawer front 3 into the small groove in the drawer back Once in place, tighten up the screws in the wedgefixes Runners must be...
- Page 8 Step 9 screw screw screw Prepare the left side Fit runner to the left side The 1st screw uses the 2nd hole in from the Front edge front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 9 Assembly Instructions Step 10 screw screw screw Prepare the right side Fit runner to the right side The 1st screw uses the 2nd hole in from the front of the runner. The 2nd and 3rd screws use the holes that line Front up with the other panel edge...
- Page 10 Assembly Instructions Step 11 Prepare the upright Gently tap the 2 mini blocks into the holes on the upright orientated as shown. Step 12 Prepare the top Screw 4 small metal dowels into the holes Mini blocks on in the top this surface Note: Tighten metal dowels up fully against...
- Page 11 Assembly Instructions Step 13 Join the top and right side Push the right side onto the top The 2 small metal dowels fitted to the top must slide into the top of the 2 hollow core locking nuts fitted to the right side .
- Page 12 Assembly Instructions Step 15 Fit the shelf Push the shelf onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the shelf Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
- Page 13 Assembly Instructions Step 17 Fit the 2 plinths Push the plinths onto the right side Use a screwdriver to tighten the large locking fitted to each plinth Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
- Page 14 Assembly Instructions Step 19 Fit the shelf to the upright Attach the shelf the upright using 2 screws Step 20 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the foldy back Square up the unit by making sure that...
- Page 15 Lift with care. Drawer If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 16 ALR3129...
