Page 1 Industrial PC Platform NY-series Industrial Panel PC Hardware User's Manual NYP££-££0 NYP££-££1 NYP££-££2 NYP££-££3 NYP££-££4 Industrial Panel PC W555-E2-12...
Page 2 Every precaution has been taken in the preparation of this manual. Nevertheless, OMRON assumes no responsibility for errors or omissions. Neither is any liability assumed for damages resulting from the use of the information contained in this publica- tion.
Page 3: Intended Audience
Introduction Introduction Thank you for purchasing the Industrial Panel PC. This manual contains information that is necessary to use the Industrial Panel PC (hereafter also named Panel PC). Please read this manual and make sure you understand the functionality and per- formance of the Panel PC before attempting to use it.
Page 4 Introduction NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 5: Sections In This Manual
Sections in this Manual Sections in this Manual Overview System Configurations Hardware Specifications Installation Operating Procedures Maintenance Appendices NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 6: Table Of Contents
CONTENTS CONTENTS Introduction ......................1 Intended Audience............................1 Applicable Products ............................1 Sections in this Manual ................... 3 Manual Information....................9 Page Structure..............................9 Special Information ............................10 Terms and Conditions Agreement................ 11 Warranty, Limitations of Liability ........................11 Application Considerations ..........................12 Disclaimers ..............................13 Safety Precautions....................
Page 7 CONTENTS Section 1 Overview Intended Use .........................1-2 Hardware Features.........................1-3 ID Information Label ......................1-4 Product Configuration Panel PC ..................1-5 Overall Setup Procedure .......................1-7 Industrial PC Platform Overview ..................1-8 1-6-1 Industrial Monitor ........................1-8 1-6-2 Industrial Box PC ........................1-9 1-6-3 Industrial Panel PC ........................1-9 Section 2 System Configurations Configuration for NYB and NYP ...................2-2...
Page 8 CONTENTS 3-10-6 USB Type-A to USB Type-B Cables ..................3-27 3-10-7 NY Monitor Link Cables ......................3-28 3-10-8 Industrial Monitor ........................3-31 3-10-9 Power Supply ..........................3-31 3-10-10 UPS ............................3-32 3-10-11 UPS Communication Cable ......................3-32 Section 4 Specifications General Specifications ......................4-2 4-1-1 Dimensions and Weight ......................4-2 4-1-2 General Electrical Specifications....................4-5 4-1-3...
Page 9 CONTENTS 5-5-1 Connector Identification ......................5-41 5-5-2 Connection Procedure ......................5-43 Initial Power ON ........................5-45 5-6-1 Initial Power ON Procedure.......................5-45 5-6-2 Windows Startup First Time ......................5-47 Install Software ........................5-49 Connect UPS ........................5-50 5-8-1 Connect UPS Using the USB Connector ..................5-51 5-8-2 Connect UPS Using the I/O Connector ..................5-53 Create Backup and Repair Data ..................5-56 Section 6 Operating Procedures...
Page 10 CONTENTS Index NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 11: Manual Information
Manual Information Manual Information This section provides information about this manual. Page Structure The following page structure is used in this manual. 5 Installation Unpack This section provides details on how to unpack the Industrial Panel PC. 5-1-1 Unpack Procedure Check the package for damage.
Page 12: Special Information
Manual Information Special Information Special information in this manual is classified as follows: Precautions for Safe Use Precautions on what to do and what not to do to ensure safe usage of the product. Precautions for Correct Use Precautions on what to do and what not to do to ensure proper operation and performance. Additional Information Additional information to read as required.
Page 13: Terms And Conditions Agreement
Omron’s exclusive warranty is that the Products will be free from defects in materials and workmanship for a period of twelve months from the date of sale by Omron (or such other period expressed in writing by Omron). Omron disclaims all other warranties, express or implied.
Page 14: Application Considerations
ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED IN CONTRACT, WARRANTY, NEGLIGENCE OR STRICT LIABILITY. Further, in no event shall liability of Omron Companies exceed the individual price of the Product on which liability is asserted. Application Considerations...
Page 15: Disclaimers
Disclaimers Performance Data Data presented in Omron Company websites, catalogs and other materials is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of Omron’s test conditions, and the user must correlate it to actual application requirements. Actual performance is subject to the Omron’s Warranty and Limitations of Liability.
Page 16: Safety Precautions
Safety Precautions Safety Precautions Definition of Precautionary Information The following notation is used in this manual to provide precautions required to ensure safe usage of the Industrial Panel PC. The safety precautions that are provided are extremely important to safety. Always read and heed the information provided in all safety precautions.
Page 17: Warnings
Safety Precautions Warnings WARNING Disassembly and Dropping Do not attempt to disassemble, repair, or modify the product in any way. Doing so may result in malfunction or fire. Installation Always connect to a ground of 100 Ω or less when installing the product. Ensure that installation and post-installation checks of the product are performed by per- sonnel in charge who possess a thorough understanding of the machinery to be instal- led.
Page 18 Safety Precautions Actual Operation Security setting adjustments should only be performed by the engineer in charge that possesses a thorough understanding of the security settings. Selecting non-recommend- ed security settings can put your system at risk. Changing BIOS information is only allowed for the engineer in charge that possesses a thorough understanding of the BIOS settings because it can change the behavior of the product.
Page 19: Cautions
Safety Precautions Cautions CAUTION Installation When installing or removing a PCIe card, avoid touching the sharp edges of the sheet metal frame tab. Injury may result. Wiring The product has an internal non-isolated DC power supply. Circuit ground (0 VDC) and frame ground are connected together.
Page 20: Precautions For Safe Use
Precautions for Safe Use Precautions for Safe Use Disassembly, Dropping, Mounting, Installation and Storage • Do not drop the product or subject it to abnormal vibration or shock. Doing so may result in product malfunction or burning. • When unpacking, check carefully for any external scratches or other damages. Also, shake the product gently and check for any abnormal sound.
Page 21: Power Supply Design And Turning On/Off The Power Supply
• Correctly perform wiring and setting, and ensure that the shutdown by the UPS can be executed. • Always use the SMART monitoring feature for storage devices that do not comply to the Omron Storage Device Specifications. Monitor the operating temperature and vibrations to ensure they stay within the environmental specifications of the storage device.
Page 22: Operation
Precautions for Safe Use Operation • Do not carry out the following operations when accessing a USB device or an SD Memory Card. • Turn OFF the power supply of the product. • Press the Power Button of the product. •...
Page 23: Cleaning, Maintenance And Disposal
Precautions for Safe Use Cleaning, Maintenance and Disposal • Do not use corrosive substances to clean the product. Doing so may result in the failure or malfunc- tion. • Periodically check the installation conditions in applications where the product is subject to contact with oil or water.
Page 24: Precautions For Correct Use
• Ensure the selected operating system supports ACPI to enable operating system shutdown using the power button. • Download the enhanced Video Driver from the OMRON Download Center and install it on the Indus- trial PC. Wiring •...
Page 25: Actual Operation And Operation
Precautions for Correct Use Actual Operation and Operation • After an OS update or a peripheral device driver update for the product is executed, the product be- havior might be different. Confirm that operation is correct before you start actual operation. •...
Page 26: Cleaning And Maintenance
Precautions for Correct Use Cleaning and Maintenance • Do not use corrosive substances to clean the product. • Turn OFF the product or disable the touchscreen for cleaning with water. NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 27: Regulations And Standards
EMC Directive EMC Directive OMRON devices that comply with EU Directives also conform to the related EMC standards so that they can be more easily built into other devices or the overall machine. The actual products have been checked for conformity to EMC standards.
Page 28: Conformance To Kc Certification
Software Licenses and Copyrights This product incorporates certain third party software. The license and copyright information associat- ed with this software is available at http://www.fa.omron.co.jp/nj_info_e/. NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 29: Related Manuals
Related Manuals Related Manuals The following manuals are related. Use these manuals for reference. Related Panel PC Manual Cat. Model- Manual name Application Description NY-series Op- W616 Learning all software related informa- An introduction to the Panel PC is erating Sys- tion about the Industrial Panel PC.
Page 30: Industrial Monitor Manual
Related Manuals Industrial Monitor Manual This table contains the related manual of the Industrial Monitor. Cat. Manual name Model-ID Application Description Industrial Monitor Us- W554 NYM12W-C1£££ Learning all basic infor- An introduction to the er’s Manual NYM15W-C1£££ mation about the Indus- Industrial Monitor is NYM19W-C1£££...
Page 31: Terminology And Abbreviations
Term / Abbreviation Description Industrial PC Platform An integrated range of OMRON products designed for use in any industrial applica- tion that will benefit from advanced PC technology Industrial Monitor An industrial monitor with a touchscreen as the user interface designed to work in...
Page 32: Software
Terminology and Abbreviations Software Term / Abbreviation Description ACPI Advanced Configuration and Power Interface protocol for operating systems Application Programming Interface BIOS Basic Input Output System. The first software run by a PC when powered on. Developer Any person involved with the development of software Daylight Saving Time Enhanced Write Filter FBWF...
Page 33: Revision History
Revision History Revision History A manual revision code appears as a suffix to the catalog number on the front and back covers of the manual. W555-E2-12 Cat. No. Revision code Revision Date Revised content code April 2021 Updated BIOS details for ®...
Page 34 Revision History Revision Date Revised content code • May 2017 Added operating system Windows 10 IoT Enterprise LTSB • Added Storage Device Considerations • Modified UPS configuration procedure • Minor modifications • December UL implementation • 2016 KC Standard implementation •...
Page 35 Overview This section provides general information about the Industrial Panel PC. Intended Use ....................1-2 Hardware Features ..................1-3 ID Information Label..................1-4 Product Configuration Panel PC..............1-5 Overall Setup Procedure ................1-7 Industrial PC Platform Overview ..............1-8 1-6-1 Industrial Monitor ....................
Page 36: Overview
1 Overview Intended Use The Industrial Panel PC is intended to be used as a panel mounted industrial PC in factory automation environments. This Panel PC can be configured with Windows, Linux or a realtime operating system (RTOS). It can be used with third party software to serve as a powerful PC platform. A user can access the Panel PC for control, configuration and supervisory operations using the inte- grated touchscreen display.
Page 37: Hardware Features
An extra (optional) DVI interface is available for connection to a second additional monitor. • NY Monitor Link interface The interface combines video signals and USB signals for a connection to an OMRON Industrial Monitor using a single NY Monitor Link cable up to 100 meter.
Page 38: Id Information Label
Power rating details and optional UL related information Custom ID A custom ID [NYC£££-££££££££] (Optional) Only applicable for customized IPC platform products. Standards and QR The applicable standards and a QR code for OMRON internal use. code LOT number and Production details, consisting of: serial number •...
Page 39: Product Configuration Panel Pc
1 Overview Product Configuration Panel PC This section provides an overview of the product configurations available for the Industrial Panel PC. The product configuration is visible in the model-ID that is mentioned on the ID information label of the Panel PC. The structure of the model-ID is: NYP££-£££££-££££££££.
Page 40 W: Wide Touchscreen C: Projected Capacitive Touch type Frame type 1: Panel mounted Material finish 0: Aluminum, painted black 1: Aluminum, Nickel plated Built-in options 0: None Logo 0: OMRON 2: Customization NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 41: Overall Setup Procedure
1 Overview Overall Setup Procedure This section gives the overall setup procedure for the Industrial PC. This manual presents this information in the same order as the following setup procedure. To setup the Industrial PC: Familiarize yourself with the Industrial PC •...
Page 42: Industrial Pc Platform Overview
In line with OMRON’s established quality standards, each element in the Industrial PC Platform, rang- ing from the standalone Industrial Box PC to the touchscreen Industrial Monitor, is engineered with long-life components and built to the most advanced design standards.
Page 43: Industrial Box Pc
1 Overview 1-6-2 Industrial Box PC The Industrial Box PC is designed to meet the specific needs of the industrial environment. Design simplification and future-proof architecture minimize the risk of failure. In addition, new PC features can be seamlessly incorporated, without the need for wholesale redesign. Examples are IPCs with a Machine Controller or IPCs designed specifically for an Autonomous Mobile Robot (AMR).
Page 44 1 Overview 1-10 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 45: System Configurations
System Configurations This section provides an overview of the system configurations for the Industrial Panel Configuration for NYB and NYP..............2-2 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 46: Configuration For Nyb And Nyp
2 System Configurations Configuration for NYB and NYP The Industrial PC supports the following hardware configurations. Ports Ethernet NYB and NYP-series IPC base layer expansion PCIe Card layer HDD / SSD Operating System & Software Utilities & APIs SD Memory Card RS-232C NYML...
Page 47: Hardware
Hardware This section provides an overview of the hardware of the Industrial Panel PC. Layers and Components ................3-3 3-1-1 Cooling Layer ....................3-4 3-1-2 Base Layer ...................... 3-5 3-1-3 Expansion Layer (Optional)................3-6 3-1-4 Display Layer....................3-7 LED Indicators ....................3-8 3-2-1 LED Indicators Display Layer ................
Page 48 3 Hardware 3-10-7 NY Monitor Link Cables................. 3-28 3-10-8 Industrial Monitor ..................3-31 3-10-9 Power Supply ....................3-31 3-10-10 UPS ....................... 3-32 3-10-11 UPS Communication Cable................3-32 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 49: Layers And Components
3 Hardware Layers and Components This section shows the layers of the Industrial Panel PC. Item Name Description Cooling layer Layer to cool the base layer Depending on the product configuration fans can be present and the thick- ness can vary. Base layer The layer with the CPU and the main interfaces The connector layout and the installed option board depend on the product...
Page 50: Cooling Layer
3 Hardware 3-1-1 Cooling Layer This section gives details on the cooling layer. The cooling layer will dissipate excessive heat from the Panel PC. Thickness and design details of the cooling layer can vary, depending on the product configuration. Cooling layer with re- The cover provides access to: •...
Page 51: Base Layer
3 Hardware 3-1-2 Base Layer This section shows the component names and functions for the base layer. The base layer houses most of the functionality of the Panel PC. Frontside Backside The connector layout and the available components can differ depending on the product configuration. Refer to 1-4 Product Configuration Panel PC on page 1-5 for configuration details.
Page 52: Expansion Layer (Optional)
3 Hardware Item Name Description ID information label Label containing model-ID, LOT No. and other product specific infor- mation. Refer to 1-3 ID Information Label on page 1-4 for label de- tails. License label The license label contains the product key for the operating system (optional).
Page 53: Display Layer
3 Hardware 3-1-4 Display Layer This section shows the component names and functions for the display layer. The main function of the display layer is to show content and interact with the user. Item Name Description Mounting brackets Retractable mounting brackets to secure the display layer on a mounting surface Ground terminal Provides a ground terminal for the Panel PC...
Page 54: Led Indicators
3 Hardware LED Indicators The Industrial Panel PC has LED indicators located at the base layer and at the display layer. These LED indicators provide the current operating status of the Industrial Panel PC. 3-2-1 LED Indicators Display Layer The display layer has a logo LED and a Status LED indicator. The Status LED indicator provides the same information as the Power and Error LEDs on the base layer.
Page 55 3 Hardware Logo LED The Logo LED brightness can be changed with the Industrial Monitor Utility. Additional Information The Logo LED brightness is adjustable with the Industrial Monitor Utility. Refer to NY-series Operating Systems and Software Utilities Manual (Cat. No. W616) for Indus- trial Monitor Utility details.
Page 56: Led Indicators Base Layer
3 Hardware 3-2-2 LED Indicators Base Layer The base layer has four LED indicators that show the operating status of the Industrial Panel PC. Models with an Expansion layer have a second row with four LED indicators that have the same func- tion.
Page 57 3 Hardware ERR LED Indicator The Error LED (ERR) indicates the presence and type of an error within the Industrial Panel PC. Color Status Meaning • Not lit The 24 VDC power is not supplied • No error is present •...
Page 58: Power Button
3 Hardware Power Button The power button is located at the base layer. The power button is used to manually switch the Panel PC ON and OFF. Additional Information • Refer to 6-2 Power ON on page 6-3 for ON details. •...
Page 59: Connectors
3 Hardware Connectors This section gives an overview of the connectors located at the base layer of the Industrial Panel PC. 3-4-1 Power Connector The power connector on the Panel PC is used to supply 24 VDC power to the Panel PC. The power connector is supplied with the Panel PC.
Page 60: Usb Connectors
3 Hardware Additional Information • Refer to 4-2-2 I/O Connector Specifications on page 4-21 for specifications. • Refer to 5-4-4 Wire the I/O Connector on page 5-38 for wiring details. • Refer to 5-5 Connect on page 5-41 for connection details. 3-4-3 USB Connectors Two USB connectors support USB 2.0 and two USB connectors support USB 3.0 specifications.
Page 61: Ethernet Connectors
3 Hardware 3-4-4 Ethernet Connectors The Ethernet connectors provide 3 individual Ethernet ports on the Industrial Panel PC. Each port offers 10BASE-T/100BASE-TX/1000BASE-T Ethernet speeds. Additional Information • Refer to 4-2-4 Ethernet Connector Specifications on page 4-26 for specifications. • Refer to 5-5 Connect on page 5-41 for connection details. 3-4-5 DVI Connector The DVI interfaces supported on this connector are dependent on the configuration of the Industrial...
Page 62: Rs-232C Connector (Optional)
3 Hardware 3-4-6 RS-232C Connector (Optional) Depending on the product configuration an optional RS-232C connector is available. Additional Information • Refer to 1-4 Product Configuration Panel PC on page 1-5 for configuration details. • Refer to 4-2-7 RS-232C Connector Specifications on page 4-30 for specifications. •...
Page 63: Ny Monitor Link Connector (Optional)
3 Hardware 3-4-8 NY Monitor Link Connector (Optional) Depending on the product configuration an optional NY Monitor Link connector is available. The NY Monitor Link interface connector connects an OMRON Industrial PC to the OMRON Industrial Monitor. Industrial PC Industrial Monitor Additional Information •...
Page 64: Ethernet Connector (Optional)
3 Hardware 3-4-9 Ethernet Connector (Optional) Depending on the product configuration an optional Ethernet connector is available. The port offers 10BASE-T/100BASE-TX/1000BASE-T Ethernet speeds. Additional Information • Refer to 1-4 Product Configuration Panel PC on page 1-5 for configuration details. • Refer to 4-2-4 Ethernet Connector Specifications on page 4-26 for specifications. •...
Page 65: Sd Memory Card Slot
3 Hardware SD Memory Card Slot The SD Memory Card slot is located at the base layer. The SD Memory Card slot on the Industrial Panel PC accepts SD Memory Cards with the following specifications. • SDHC type (SD 2.0 specification) •...
Page 66: Cfast Card Slot (Optional)
3 Hardware CFast Card Slot (Optional) Depending on the product configuration an optional CFast Card slot is located at the rear side of the base layer. The CFast Card slot accepts CFast Cards that comply with the CFast 2.0 specification. Additional Information Refer to 3-10-3 CFast Cards on page 3-25 for details.
Page 67: Drive Bays
3 Hardware Drive Bays The drive bays are located in the expansion layer. The drive bays in the Industrial Panel PC accept 2.5 inch Hard Disk Drives (HDD) or Solid State Drives (SSD). Depending on the model one or two drives are supported. Additional Information •...
Page 68: Pcie Card Slot
3 Hardware PCIe Card Slot The PCI Express (PCIe) Card slot is located in the expansion layer. The PCI Express (PCIe) Card slot of the Industrial Panel PC can accept various PCIe Cards for specif- ic hardware needs. The PCIe Card connectors are available behind the cover A and the PCIe Card is mounted in the PCIe drawer B .
Page 69: Spare Parts
3 Hardware Spare Parts The following spare parts for the Industrial Panel PC are available. 3-9-1 Battery One battery is located inside the Panel PC. The battery supplies power to the real-time clock. The battery is: • not replaceable for products with a cooling layer that has a non-removable cover. The non-replaceable battery has a lifetime for at least 10 years at 40°C.
Page 70: Accessory Kit
The Accessory Kit can contain accessories that are not applicable to your model. Refer to 1-4 Product Configuration Panel PC on page 1-5 for details. 3-9-4 Connectors Details for the recommended connectors are provided below. OMRON is not responsible for the operation or performance of any other connector. Model Appearance Specifications NY000-AK01 Power Connectors for Omron Industrial PCs.
Page 71: 3-10 Optional Hardware
The following optional hardware is available for the Industrial Panel PC. 3-10-1 SD Memory Cards SD Memory Card details are provided below. OMRON is not responsible for the operation, performance or write life of any other brand of SD Memo- ry Card. Model Appearance...
Page 72: Hdd And Ssd Storage Devices
Storage Device Considerations For a storage device that is not an OMRON NY000-A£££ consider the following: • OMRON is not responsible for the operation, performance or write life of any storage device other than those supplied by OMRON. • Test and measure the environmental performance of the intended storage device before actual op- eration, using the SMART monitoring feature of the selected storage device.
Page 73: Dvi Cables
90 mm 3-10-6 USB Type-A to USB Type-B Cables USB Type-A to USB Type-B cable details are provided below. OMRON is not responsible for the operation or performance of any other brand of USB Type-A to USB Type-B cable. Model Appearance...
Page 74: Ny Monitor Link Cables
3 Hardware 3-10-7 NY Monitor Link Cables Depending on the installation situation specific cables are recommended for an NY Monitor Link (NYML). Refer to: • NYML Recommendations up to 20 m on page 3-28 for details. • NYML Recommendations up to 100 m on page 3-29 for details. •...
Page 75 3 Hardware NYML Recommendations up to 100 m Patch Cables A with different lengths can be used. Use a DIN rail socket B when connecting patch cables to infrastructures. Use installation cable C inside infrastructures. Max 5 m Max 90 m Max 5 m Infrastructure Monitor...
Page 76 3 Hardware NYML Recommendations for Custom Cables The following table lists the recommended cables and connectors for custom NY Monitor Link cables. Intra cabinet or Inter cabinet and Item light industrial en- Inter cabinet harsh industrial vironment environment Maximum length 25 m 100 m 100 m...
Page 77: Industrial Monitor
Additional Information Refer to the OMRON website for specifications and manuals. 3-10-9 Power Supply Details for the recommended power supply are provided below. OMRON is not responsible for the operation or performance of any other power supply. Model Appearance Specifications S8VK-G£££24 Output voltage: 24 VDC S8VK-X£££24A-EIP...
Page 78: 3-10-10 Ups
• Refer to 4-1-3 Power Consumption Specifications on page 4-6 for power consumption de- tails. • Refer to the OMRON website for S8BA specifications or to the UPS S8BA User's Manual (Cat. No. U702) for the UPS manual. Note that the power consumption details determine the output current/capacity of your UPS.
Page 79: Specifications
Specifications This section provides specifications of the Industrial Panel PC. General Specifications ................. 4-2 4-1-1 Dimensions and Weight .................. 4-2 4-1-2 General Electrical Specifications..............4-5 4-1-3 Power Consumption Specifications..............4-6 4-1-4 Power Supply Specifications ................4-8 4-1-5 CPU Specifications..................4-9 4-1-6 Memory Specifications ..................
Page 80: General Specifications
4 Specifications General Specifications This section provides general specifications of the Industrial Panel PC. 4-1-1 Dimensions and Weight The dimensions and weights can differ depending on the configuration. The following tables provide specification details per configuration. NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 81 4 Specifications 12" Display The following table provides specification details on dimensions and weights for the Industrial Panel PC with 12" display. Refer to the image in 4-1-1 Dimensions and Weight on page 4-2 for X, Y, Z and R details. Model Specifications Model Details...
Page 82 4 Specifications 19" Display The following table provides specification details on dimensions and weights for the Industrial Panel PC with 19" display. Refer to the image in 4-1-1 Dimensions and Weight on page 4-2 for X, Y, Z and R details. Model Specifications Model Details...
Page 83: General Electrical Specifications
4 Specifications 4-1-2 General Electrical Specifications The following table provides the general electrical specifications. Item Specifications Rated power supply voltage 24 VDC Allowable power supply voltage range 20.4 to 28.8 VDC Power supply standard SELV Grounding method Ground to less than 100 Ω Inrush current At 24 VDC: 12 A / 6 ms max.
Page 84: Power Consumption Specifications
Refer to 1-4 Product Configuration Panel PC on page 1-5 for product configuration details. Installed drives Drives Power consumption Bay A Refer to 4-1-7 Storage Device Specifications on page 4-14 for Omron drive details. For other drives refer to the applicable specifications for Bay B maximum power consumption details. CFast Card Slot...
Page 85 4 Specifications Additional Information Ensure to use a power supply with sufficient capacity. Refer to 4-1-4 Power Supply Specifications on page 4-8 for details. NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 86: Power Supply Specifications
4 Specifications 4-1-4 Power Supply Specifications The minimum power supply requirements depend on the maximum power consumption of the Panel PC. Refer to 4-1-3 Power Consumption Specifications on page 4-6 for details. With a UPS installed the minimum power requirements are: Minimum power requirements Model Power supply...
Page 87: Cpu Specifications
4 Specifications 4-1-5 CPU Specifications This section gives the specifications of the CPUs that are available for the Industrial Panel PC. Refer to 1-4 Product Configuration Panel PC on page 1-5 for product configuration details. ® ® NY£1C Intel Celeron 2980U CPU Specifications ®...
Page 88 4 Specifications ® ® NY£2C Intel Celeron 3965U CPU Specifications ® ® CPU specifications for an Intel Celeron 3965U CPU. Item Specifications Cores / Threads 2 / 2 CPU base frequency 2.2 GHz Maximum turbo frequency Cache 2 MB Cooling details Passive cooling (fanless) Graphics controller Intel ®...
Page 89 4 Specifications ® ™ NY£35 Intel Core i5-7300U CPU Specifications ® ™ CPU specifications for an Intel Core i5-7300U CPU. Item Specifications Cores / Threads 2 / 4 CPU base frequency 2.6 GHz Maximum turbo frequency 3.5 GHz Cache 3 MB Cooling details Passive cooling (fanless) Graphics controller...
Page 90: Memory Specifications
4 Specifications 4-1-6 Memory Specifications This section provides the memory specifications of the Industrial Panel PC. DDR4 ECC The following table provides specification details of the DDR4 memory. Model Specifications Item 8 GB 16 GB Memory configuration 2 x 4 GB 2 x 8 GB Memory type DDR4 ECC...
Page 91 4 Specifications DDR3L Non-ECC The following table provides specification details of the DDR3L memory. Model Specifications Item 2 GB 4 GB 8 GB 16 GB Memory configuration 1 x 2 GB 1 x 4 GB 2 x 4 GB 2 x 8 GB Memory type DDR3L Non-ECC Package memory for-...
Page 92: Storage Device Specifications
4 Specifications 4-1-7 Storage Device Specifications This section provides the specifications of the storage devices. Hard Disk Drive Specifications Specifications for the Hard Disk Drive (HDD) are provided in the table below. Model Specifications Item 320 GB 500 GB 1 TB NY000-AH00 NY000-AH01 NY000-AH02...
Page 93 4 Specifications Solid State Drive Specifications Specifications for the Solid State Drive (SSD) are provided in the table below. Model Specifications Item 32 GB 64 GB 128 GB 256 GB 500 GB 1 TB NY000- NY000- NY000- NY000- NY000- NY000- NY000- NY000- Model...
Page 94 4 Specifications CFast Card Specifications Specifications for the CFast Drive are provided in the table below. Model Specifications Item 64 GB 128 GB 256 GB NY000-AT00 NY000-AT01 NY000-AT02 Model Type Max. power consumption 0.9 W Max. sequential 530 MB/s read speed Max.
Page 95: Pcie Card Specifications
4 Specifications 4-1-8 PCIe Card Specifications The PCI Express (PCIe) Card slot of the Industrial Panel PC accepts various cards for specific hard- ware needs. Ensure that, according to the PCIe hardware specifications, the indent A is present in the PCIe Card. The PCIe Card specifications depend on the CPU and thus on the product configuration.
Page 96 4 Specifications NY£1E-£1 PCIe Card Slot Specifications ® ® The table below provides PCIe Card slot details for Industrial Panel PCs with an Intel Xeon E3-1515M v5 CPU. Item Specifications Configuration X4 (4 lanes) up to Gen 3 Card height Standard height cards, 4.20 inches (106.7 mm) Card length Half-length cards, 6.6 inches (167.65 mm)
Page 97 4 Specifications NY£25-£1 PCIe Card Slot Specifications ® ™ The table below provides PCIe Card slot details for Industrial Panel PCs with an Intel Core i5-4300U CPU. Item Specifications Configuration X1 (1 lane) up to Gen 2 Card height Standard height cards, 4.20 inches (106.7 mm) Card length Half-length cards, 6.6 inches (167.65 mm) Power consumption...
Page 98: Connector Specifications
4 Specifications Connector Specifications This section provides the Connector Specifications of the Industrial Panel PC. 4-2-1 Power Connector Specifications The power supply connector is locked when inserted to prevent unintentional disconnection. The connector can only be inserted the correct way. The connector is a Phoenix Contact type SPC5/2-STCL-7.62 BK (1711708).
Page 99: I/O Connector Specifications
4 Specifications Locking and Removing the Power Connector The power connector automatically locks into place when the black part of the connector is held and pushed in. Pushing both orange sliders B towards the end of the connector A will release the lock when remov- ing the connector.
Page 100 4 Specifications I/O Connector Pin Details The pin details of the I/O connector. The pin layout represents the I/O connector on the Panel PC. The I/O signals connected must be powered from a power supply which conforms to the SELV stand- ards.
Page 101 4 Specifications I/O Connector Power Status Output Details This section provides details of the Power Status Output relay. The Power Status Output is a relay between pin 1 and 2 of the I/O Connector.  Power ON Power Status Output Operation This section provides power ON details of the Power Status Output operation.
Page 102 4 Specifications Product ON Shutdown Shutdown Product OFF start finished Closed (ON) Relay Open (OFF) Power supply removed Closed (ON) Relay Open (OFF) Additional Information Refer to 5-4-4 Wire the I/O Connector on page 5-38 for I/O connector wiring details. Lock and Remove the I/O Connector The I/O connector locks into place when the black part of the connector is held and pushed in.
Page 103: Usb Connector Specifications
4 Specifications 4-2-3 USB Connector Specifications The Industrial Panel PC includes four USB connectors. Two connectors provide version 2.0 perform- ance and two connectors provide version 3.0 performance. Details of the USB interface connectors are provided below. The connector layout represents the USB connectors on the Panel PC. Interface Connector Details per Connector •...
Page 104: Ethernet Connector Specifications
4 Specifications 4-2-4 Ethernet Connector Specifications Details of the RJ45 Ethernet connectors are provided below. The Ethernet connector locks automatically to prevent unintentional disconnection. Base layer: 3 RJ45 connectors Base layer: 1optional RJ45 connector The set of 3 RJ45 Ethernet connectors is available on the base layer of all models. Ethernet Connector Specification Details Details of the RJ45 Ethernet connectors are provided below.
Page 105 4 Specifications Ethernet Connector LED Indicators Details of the RJ45 Ethernet connectors in the base layer are provided below. Each connector has LED indicators that display the link, activity and speed status. Item Indicator Color Status Description Link/Act Yellow Not lit No link Link Flashing...
Page 106: Dvi Connector Specifications
4 Specifications 4-2-5 DVI Connector Specifications DVI is the standard video interface for the Panel PC. Additional Information • Refer to 4-1-5 CPU Specifications on page 4-9 for graphics controller details. • Refer to 5-4-2 Ground on page 5-28 for grounding details. •...
Page 107: Dvi-D Connector Specifications
4 Specifications 4-2-6 DVI-D Connector Specifications The optional video interface on the Panel PC uses a DVI dual link connector. Item Specification Video interface Digital only Resolution Up to 1920 x 1200 pixels at 60 Hz Type Dual link Maximum DVI cable length Dependent upon connected monitor type and resolution Additional Information •...
Page 108: Rs-232C Connector Specifications
4-2-8 NY Monitor Link Connector Specifications The optional NY Monitor Link connector connects an OMRON Industrial Monitor with an OMRON In- dustrial PC that has an NY monitor link connector. The NY Monitor Link communication is a combination of video and USB information.
Page 109 4 Specifications Industrial PC Industrial Monitor NY Monitor Link Connector LED Indicators The connector has LED indicators Connected A and Video B . NYML Indica- Item Color Status Description Con- Yellow Not lit Not connected nected Connected USB communication active Video Green Not lit...
Page 110: Display Specifications
4 Specifications Display Specifications This section provides the display specifications of the Industrial Panel PC. WARNING Do not use the input functions of the touchscreen in applications that involve human life, in applications that may result in serious injury, or for emergency stop switches. Precautions for Correct Use The touchscreen supports 5 simultaneous touches.
Page 111 4 Specifications The touchscreen can be operated when wearing gloves. Confirm you can operate the touchscreen with gloves before actual operation. This is the estimated time before brightness is reduced by half at room temperature. The life expectancy is drastically shortened if used at high temperatures. If the brightness is set to very low, it causes flickering or the screen will be too dark to use.
Page 112: Environmental Specifications
4 Specifications Environmental Specifications This section provides environmental specifications of the Industrial Panel PC. 4-4-1 Operation Environment Specifications The following table provides general environmental specifications for the Industrial Panel PC. Specifications Item 12.1 inch 15.4 inch 18.5 inch Ambient operating tem- 0 to 55°C perature Ambient storage tempera-...
Page 113: Temperature And Humidity Specifications
4 Specifications 4-4-2 Temperature and Humidity Specifications The maximum ambient operating temperature depends on the model, mounting orientation, and stor- age device type. The following tables provide ambient temperature and humidity details and temperature specifications per model. Temperature and Humidity Graphs The maximum ambient operating temperature and ambient humidity are specified per storage device type.
Page 114 4 Specifications • Operate the Panel PC with a SSD or CFast within the ambient temperature and humidity ranges as shown in the following graph. Operating temperature- Operating humidity range temperature-humidity range Temperature [°C] Additional Information Refer to the ambient temperature specifications per CPU type for CPU-specific limitations. •...
Page 115 4 Specifications NYP1C-£1 Temperature Specifications Ambient operating temperature specifications for model NYP1C-£1. ® ® This Panel PC has an Intel Celeron 2980U CPU. Configuration Product Orienta- Mounting Angle 1 x HDD 320 GB / tion 1 or 2 x SSD 1 x HDD 1 TB 500 GB Landscape and...
Page 116 4 Specifications NYP2A-£0 Temperature Specifications Ambient operating temperature specifications for model NYP2A-£0. ® ® This Panel PC has an Intel Atom x5-E3940 CPU. Storage device type Product Orientation Mounting Angle CFast Card Landscape and 0° to 45° 0 to 50°C Portrait Landscape 45°...
Page 117 4 Specifications NYP2C-£1 Temperature Specifications Ambient operating temperature specifications for model NYP2C-£1. ® ® This Panel PC has an Intel Celeron 3965U CPU. Configuration Product Orienta- Mounting Angle HDD 320 GB / 500 tion HDD 1 TB Landscape and 0° to 45° 0 to 45°C 5 to 35°C 0 to 30°C...
Page 118 4 Specifications NYP27-£0 Temperature Specifications Ambient operating temperature specifications for model NYP27-£0. ® ® This Panel PC has an Intel Core i7-7820EQ CPU. Configuration Product Orientation Mounting Angle Landscape and 0° to 135° 0 to 55°C Portrait Refer to 1-4 Product Configuration Panel PC on page 1-5 for model details. 90°...
Page 119 4 Specifications NYP35-£0 Temperature Specifications Ambient operating temperature specifications for model NYP35-£0. ® ™ This Panel PC has an Intel Core i5-7300U CPU. Storage device type Product Orientation Mounting Angle CFast Card Landscape and 0° to 45° 0 to 50°C Portrait Landscape 45°...
Page 120: Recycling Specifications
4 Specifications 4-4-3 Recycling Specifications The following table provides recycling information for the Industrial Panel PC. Part Recycle specifications Battery Chemical waste PCIe Card and other electrical components Electrical waste Precautions for Safe Use Dispose of the product and batteries according to local ordinances as they apply. Dispose in accordance with applicable regulations.
Page 121: Installation
Installation This section provides all installation details for the Industrial Panel PC. Unpack ......................5-2 5-1-1 Unpack Procedure................... 5-2 5-1-2 Items Supplied....................5-3 Install Options ....................5-4 5-2-1 Install a Drive....................5-4 5-2-2 Install the PCIe Card ..................5-8 Mount......................5-14 5-3-1 Installation Method in Control Panels............
Page 122: Unpack
5 Installation Unpack This section provides details on how to unpack the Industrial Panel PC. 5-1-1 Unpack Procedure Check the package for damage. If there is any visible damage: • Take photos of the package and save them. • Inform your supplier immediately. Open the package.
Page 123: Items Supplied
5 Installation 5-1-2 Items Supplied This section describes the items supplied with your Industrial Panel PC. • Industrial Panel PC • Documentation: • Safety Precautions sheets (English and Japanese) • General Compliance Information and Instructions for EU • Standards and Certifications sheet •...
Page 124: Install Options
5 Installation Install Options This section describes the installable options for the Industrial Panel PC. 5-2-1 Install a Drive A drive is a storage device for the Industrial Panel PC. Additional Information • Depending on the product configuration 0, 1 or 2 drives can be pre-installed. Refer to 1-4 Product Configuration Panel PC on page 1-5 for details.
Page 125 5 Installation Pull the metal shielding cover out of the Panel PC. Rotate and then remove the break out part from the drive bracket. Align the connectors of the drive as shown A on the bracket. Then insert the replacement drive in the bracket and insert the 4 mounting screws .
Page 126 5 Installation Insert the bracket with the drive in the correct bay. Refer to 3-1-3 Expansion Layer (Optional) on page 3-6 for bay details. Ensure the bracket is completely in the Panel PC with an extra push. The drive bracket will lock into place when it is fully inserted. Insert the metal shielding cover.
Page 127 5 Installation Mount the drive cover. The lock lever will click when closed correctly. Finalize the drive installation when the Panel PC installation is completed. • For a drive that requires an operating system: 1) Install an operating system 2) Power OFF and then Power ON 3) Ensure the drive is functional and confirm normal operation.
Page 128: Install The Pcie Card
5 Installation 5-2-2 Install the PCIe Card Prepare the following items: • The PCIe Card. A PCIe Card is not supplied with the Panel PC. Additional Information • Depending on the product configuration a PCIe card can be pre-installed. Refer to 1-4 Product Configuration Panel PC on page 1-5 for details. •...
Page 129 5 Installation Remove the Card Clip from the PCIe Drawer. There are two types of Card Clips available. Use the steps applicable to your type. CAUTION When installing or removing a PCIe card, avoid touching the sharp edges of the sheet metal frame tab. Injury may result. Card Clip Card Clip Sheet metal frame tab...
Page 130 5 Installation Place the PCIe Card in the PCIe Drawer. Ensure to insert the PCIe Card in the correct opening. Ensure the thin sheet metal frame is positioned between the PCIe Card and the PCIe Drawer to ensure a good conductive contact. 5-10 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 131 5 Installation Place the Card Clip A in the PCIe Card and PCIe Drawer. There are two types of Card Clips available. Use the steps applicable to your type. CAUTION When installing or removing a PCIe card, avoid touching the sharp edges of the sheet metal frame tab.
Page 132 5 Installation Slide the Card Support so that it supports the side of the PCIe Card. The card should be in small groove so there is support below and above the card. Rotate the Card Support to lock it in place. Insert the PCIe Drawer in the Panel PC and then insert the two crosshead screws that hold the PCIe Drawer in place.
Page 133 5 Installation Remove the PCIe cover if the PCIe Card has external connectors. 1) Push the lock lever 2) Tilt the PCIe cover 3) Remove the PCIe cover The PCIe Card is installed. 5-13 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 134: Mount
5 Installation Mount This section describes how to mount the Industrial Panel PC in either a landscape or portrait orienta- tion in a control panel. WARNING Ensure that installation and post-installation checks of the product are performed by personnel in charge who possess a thorough understanding of the machinery to be installed.
Page 135: Product Orientation
5 Installation 5-3-2 Product Orientation The Industrial Panel PC can be mounted in a landscape A or portrait B orientation. Do not install the Industrial Panel PC in any of the following orientations. 5-15 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 136: Temperature
5 Installation 5-3-3 Temperature The temperature inside a control panel may be at least 10 to 15°C higher than outside the panel. Im- plement the following measures against overheating at the installation site and in the control panel, and allow a sufficient margin for the temperature. Distance for Cooling Adequate airflow around the Industrial Panel PC is required.
Page 137 Panel PC. • Do not install the Panel PC directly above any heat-generating equipment, such as heaters or transformers. • Do not install the Panel PC in a location exposed to direct sunlight. OMRON product OMRON product Natural Cooling ...
Page 138: Humidity
5 Installation OMRON product OMRON product Forced Air Circulation  Room Cooling Cool the entire room where the control panel is located. Cooler Control panel Room Cooling Low Temperatures The Panel PC may not start normally if the temperature is below 0°C when the power is turned ON.
Page 139: Atmosphere
Installation Location Install the Panel PC as far away as possible from high-voltage (600 V or higher) and power devices to ensure safe operation and maintenance. Example of Recommended Equipment Arrangement OMRON product Control panel Control panel High-voltage...
Page 140 • Keep the wiring between the transformer and the Panel PC as short as possible, twist the wires well, and keep the wiring separate from high-voltage and power lines. Power circuits Power supply for general operations circuits I/O power supply for Omron product I/O power supply for Omron product Noise Unit power supply for Omron product...
Page 141 5 Installation Wire External I/O Signal Lines Observe the following points when wiring the external I/O signal lines. • To absorb reverse electromotive force when an inductive load is connected to an output signal, con- nect a surge suppressor near the inductive load in an AC circuit, or connect a diode near the induc- tive load in a DC circuit.
Page 142 5 Installation External Wiring Wiring, and noise countermeasures in particular, are based on experience, and it is necessary to closely manage wiring based on experience and information in the manuals.  Wiring Routes Each of the following combinations includes different signal types, properties, or levels. They will cause the signal-to-noise ratio to drop due to factors such as electrical induction.
Page 143 200 mm Ground of 100 Ω or less Example: Separating an OMRON product from Power Lines  Wiring Ducts Whenever possible, route the cables and wires through wiring ducts. Install the wiring ducts so that it is easy to route the wires from the Industrial Panel PC directly into the duct.
Page 144 5 Installation  Other Precautions Basic I/O Units have both plus and minus commons, so pay attention to the polarity when wiring. 5-24 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 145: Prepare The Mounting Surface
5 Installation 5-3-8 Prepare the Mounting Surface The Industrial Panel PC can be mounted in a landscape or portrait orientation. The mounting hardware is integrated into the back of the Panel PC. Model Specifications Item 12.1 inch 15.4 inch 18.5 inch Panel cutout -0 +1 -0 +1...
Page 146 5 Installation Ensure the mounting surface conforms to following requirements. Standards conformance Material Mounting panel requirements IP65 Steel Thickness 1.6 to 6.0 mm Aluminum Thickness 2.5 to 6.0 mm Create an opening in the mounting surface. The table before step 1 gives an overview of the cut out dimensions for the Panel PC. Prepare a rectangular cut out with the dimensions X1 and Y1.
Page 147: Mount The Industrial Panel Pc
5 Installation 5-3-9 Mount the Industrial Panel PC Ensure the panel cut out is ready before beginning the mounting procedure. Tools required: Torque screw driver with hexagon 2 mm bit. The Industrial Panel PC is equipped with 8 (12", 15") or 9 (19") retractable mounting brackets on the back of the Panel PC.
Page 148: Wire
5 Installation Wire This section describes how to wire the Industrial Panel PC. 5-4-1 Wiring Warnings and Cautions This section describes the Warnings and Cautions when wiring the Industrial Panel PC. WARNING Provide safety measures in external circuits to ensure safety in the system if an ab- normality occurs due to malfunction of the product or due to other external factors af- fecting operation.
Page 149 5 Installation CAUTION The product has an internal non-isolated DC power supply. Circuit ground (0 VDC) and frame ground are connected together. When connecting a non-isolated device or a non-isolated interface to the product, take appropriate actions to avoid communica- tion failures or damage to the mentioned ports.
Page 150 5 Installation Considerations for Earthing Methods Local potential fluctuations due to lightning or noise occurred by power devices will cause potential fluctuations between ground terminals of devices. This potential fluctuation may result in device mal- function or damage. To prevent this, it is necessary to suppress the occurrence of a difference in elec- trical potential between ground terminals of devices.
Page 151 5 Installation Equipotential Bonding System Equipotential bonding is an earthing method in which steel frames and building structures, metal ducts and pipes, and metal structures in floors are connected together and make connections to the earth trunk line to achieve a uniform potential everywhere across the entire building. We recommend this earthing method.
Page 152 5 Installation Star Earthing If the earthing method used for the building is not equipotential bonding or the earthing system is un- known, choose (a) from among the earthing methods given below. a. Connecting devices and noise sources to separate earth electrodes This is an earthing method to separately ground an earth electrode of the device that is connected with a communications cable or other devices and an earth electrode of a high-power device that could be a noise source, such as a motor or inverter.
Page 153 5 Installation Daisy Chain This is an earthing method to connect the device that is connected with a communications cable, other devices, and a device that could be a noise source using a daisy-chain topology to a common earth electrode. This earthing method is not recommended because the device that could be a noise source may inter- fere electromagnetically with other devices.
Page 154 5 Installation Ground Connection Details This section provides details about the ground connection. Use the ground terminal on the backside of the monitor to ground your Industrial Panel PC. The washers and screw A are pre-mounted at the Industrial Panel PC. Remove the pre-mounted washers and screw A and then mount the ground connection wire C to the Panel PC B using the washers and screw A .
Page 155: Wire The Power Connector
5 Installation 5-4-3 Wire the Power Connector This section describes how to wire the power connector. Precautions for Safe Use • Do not perform a dielectric strength test. • Always use the recommended uninterruptible power supply (UPS) to prevent data loss and other system file integrity issues caused by unexpected power interruption.
Page 156 Maximum AWG according to UL/cUL • Power Supply Connector DC Power Supply The OMRON S8VK-series power supply is recommended for use with the Industrial Panel PC. Additional Information • Refer to 3-10-9 Power Supply on page 3-31 for more information.
Page 157 5 Installation Power Connector Wiring Procedure Use the following procedure to wire the power connector. Ensure the power connector is not connected to the Panel PC. 7 mm Remove the sheath from the power supply wires. Precautions for Safe Use Observe the following precautions to prevent broken wires.
Page 158: Wire The I/O Connector
5 Installation 5-4-4 Wire the I/O Connector This section describes how to wire the I/O connector. I/O Connector Wiring Materials Use the supplied I/O connector to connect the inputs and outputs to the Industrial Panel PC. Recommended I/O conductor sizes for the connector are provided in the table. Wire type Conductor cross-section Solid conductor...
Page 159 5 Installation Description Internal Circuit Details Power ON Input The Power ON Input and the UPS Mode Input are bi-directional and isolated. Each input can be wired as sinking (NPN) or sourc- ing (PNP). Wire these according to the output device connected to UPS Mode Input the inputs.
Page 160 5 Installation I/O Connector Wiring Procedure Use the following procedure to wire the I/O connector. Ensure the I/O connector is not connected to the Panel PC. 7 mm Remove the sheath from the wires. Precautions for Safe Use Observe the following precautions to prevent broken wires. •...
Page 161: Connect
5 Installation Connect This section describes how to connect the Industrial Panel PC. 5-5-1 Connector Identification An overview of the connectors of the base layer. Item Name Description Power connector Lockable power connector I/O connector 2 inputs (UPS signal and power OFF control) and 1 output (power state) USB 3.0 connector 2 USB 3.0 connectors...
Page 162 5 Installation Item Name Description Option port Interface connection options for peripheral devices or an additional monitor: • RS-232C connector (default) • DVI-D connector • NY Monitor Link connector • RJ45 Gb Ethernet connector 5-42 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 163: Connection Procedure
Additional Information • Refer to 5-3 Mount on page 5-14 for mounting details. • Refer to 3-10 Optional Hardware on page 3-25 for the cables advised by Omron. Refer to individual cable specifications for cable bending requirements and connector clear- ance.
Page 164 5 Installation Connect the I/O connector. Hold the black part A when inserting the connector, this enables the auto-locking mechanism. Do not tilt the orange levers B because this will unlock the connector. Connect an external monitor such as the Industrial Monitor. Connect the monitor to the DVI connector and tighten the fastening screws or use the optional NYML connector.
Page 165: Initial Power On
Connect an optional keyboard and/or mouse. Additional Information • If using an OMRON Industrial Panel PC, this may not be required because it has touch func- tionality. • Do not connect additional storage devices before the installation of the operating system completed.
Page 166 The Panel PC is ON and if an operating system is installed it will start. Precautions for Safe Use Always use the SMART monitoring feature for storage devices that do not comply to the Omron Storage Device Specifications. Monitor the operating temperature and vibrations to ensure they stay within the environmental specifications of the storage device.
Page 167: Windows Startup First Time
Select the language carefully, the selected system language can not be changed. • Legal stuff like license agreements • Windows 10: Select Accept to accept the combined Windows and OMRON license agree- ments. • Windows 7: Select Accept separately for Windows and for the OMRON utilities.
Page 168 Adjust the backlight, Logo LED, and Status LED brightness of the connected monitor(s) to your settings. Additional Information • Use the Industrial Monitor Utility to adjust the display and/or the connected OMRON Industrial Monitor. • Verify that the Panel PC is responding to finger touches on the touchscreen of the product.
Page 169: Install Software
5 Installation Install Software Install applicable software and activate Windows. Additional Information Refer to NY-series Operating Systems and Software Utilities Manual (Cat. No. W616) for de- tails. 5-49 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 170: Connect Ups
PC can shutdown normally without data loss. The Panel PC can automatically start up again when the power is restored. To connect the Panel PC to the OMRON S8BA UPS use one of the following two options: • The USB connector and Power Attendant Lite Utility Software.
Page 171: Connect Ups Using The Usb Connector
• Drivers for the S8BA UPS from this OMRON website. • Installation files and manual for the Power Attendant Lite Utility from this OMRON website. • Installation files and manual for the UPS Settings Utility (Windows only) from this OMRON web- site.
Page 172 5 Installation UPS (S8BA) 24 VDC Power Supply (S8VK) Output Industrial PC Input AC (L) 24 VDC AC (N) 0 VDC Refer to the UPS S8BA User's Manual (Cat. No. U702) for details. Refer to 5-4-3 Wire the Power Connector on page 5-35 for wiring details. Supply power to the Power Supply.
Page 173: Connect Ups Using The I/O Connector
• For all other Panel PCs following software can be downloaded: • Drivers for the S8BA UPS from this OMRON website. • Installation files and manual for the UPS Settings Utility (Windows only) from this OMRON web- site. Precautions for Safe Use •...
Page 174 5 Installation Refer to 3-10-10 UPS on page 3-32 for more information. For Panel PCs that do not have Windows pre-installed: Download the above mentioned soft- ware. Wire the S8BA UPS. 1) Wire the input of the UPS to the output of the Power Supply. 2) Wire the output of the UPS to the power connector of the Panel PC.
Page 175 5 Installation Test the created software program and ensure it functions correctly. Simulate a power interruption and confirm a correct shutdown of the Panel PC. • Start the Panel PC • Start applications • Create a power interruption • Monitor the shutdown sequence and confirm a correct shutdown sequence The UPS is connected and configured.
Page 176: Create Backup And Repair Data
5 Installation Create Backup and Repair Data Ensure the operating system, software and data can always be restored when required. There are different software tools to create a backup and repair data. Select the Backup and Repair procedure or procedures that are most suitable for your situation. Precautions for Correct Use Refer to NY-series Operating Systems and Software Utilities Manual (Cat.
Page 177 Operating Procedures This section provides the operating procedures for the Industrial Panel PC. Touchscreen Operation ................. 6-2 Power ON ......................6-3 6-2-1 Power ON Using the Power Button ..............6-3 6-2-2 Power ON Using the Power ON/OFF Input............. 6-3 6-2-3 Auto Power ON ....................
Page 178: Touchscreen Operation
6 Operating Procedures Touchscreen Operation WARNING Water or other liquid present on the touchscreen surface may create false touch be- havior and unexpected operation. Wipe away liquid on the touchscreen before opera- tion. CAUTION When using a system with multiple touchscreens, multiple users can perform simulta- neous operations.
Page 179: Power On
6 Operating Procedures Power ON This section provides Power ON details. Precautions for Correct Use Do not turn ON the power supply to the product when a part of a human body or a conductive object is touching the surface of the touchscreen. Doing so will cause the touchscreen function- ality to be disabled.
Page 180: Auto Power On
6 Operating Procedures 6-2-3 Auto Power ON The Panel PC can be configured to start up when power is supplied to the power connector. The Power Loss Control BIOS setting controls this behavior. Set the Power Loss Control setting to Turn ON to activate the Auto Power ON function. Additional Information Refer to A-1 BIOS on page A-2 for BIOS details.
Page 181: Power Off
6 Operating Procedures Power OFF This section provides Power OFF details. Before following power OFF procedures below, check that the Industrial Panel PC is ON by examining the LED indicators on the Panel PC. 6-3-1 Power OFF Using the Power Button Ensure all programs are closed.
Page 182: Power Off Using The Power On/Off Input
6 Operating Procedures 6-3-3 Power OFF Using the Power ON/OFF Input Ensure all programs are closed. If required, close all active programs. Supply a 24 VDC signal to the Power ON/OFF Input (pins 3 and 4) of the I/O connector. The input signal must remain ON for a minimum of 60 ms and a maximum of 750 ms to be correctly detected by the Industrial Panel PC.
Page 183: React To Product Messages
6 Operating Procedures React to Product Messages The Industrial Panel PC uses the Industrial PC Tray Utility icon A in the system tray area B of Win- dows to present Warnings and Errors. Check the Industrial PC Tray Utility icon for a Warning or Error symbol. A Warning or Error symbol displayed on the Industrial PC Tray Utility icon indicates a product mes- sage.
Page 184: React To Windows Messages
6 Operating Procedures React to Windows Messages Windows uses the Windows Action Center icon A in the system tray area B of Windows to present Warnings and Errors. Windows 10 Windows 7 Check the Windows Action Center icon for a Warning or Error symbol. A Warning or Error symbol displayed on the Windows Action Center icon indicates a Windows mes- sage.
Page 185: Maintenance
Maintenance This section provides an overview of all maintenance tasks for the Industrial Panel PC. Preventive Maintenance ................7-2 7-1-1 Preventive Maintenance Schedule..............7-2 7-1-2 Clean the Touchscreen Surface ..............7-3 7-1-3 Clean the Panel PC..................7-4 7-1-4 Check the Gasket Seal..................7-5 Corrective Maintenance.................
Page 186: Preventive Maintenance
Refer to 3-2 LED Indicators on page 3-8 for LED details. Monitor storage devices that do not Refer to Storage Device Considerations on page 3-26 for details. comply to the Omron specifications Clean the display Refer to 7-1-2 Clean the Touchscreen Surface on page 7-3 for display cleaning details.
Page 187: Clean The Touchscreen Surface
7 Maintenance Periodically but at least every 6 Reference months • For a cooling layer with removable Refer to 7-2-2 Remove the Cover on page 7-8 to check the label. cover: • Refer to 7-2-4 Replace the Battery on page 7-11 to replace the bat- •...
Page 188: Clean The Panel Pc
7 Maintenance 7-1-3 Clean the Panel PC Clean the Panel PC periodically in order to keep it in the best operating condition. Wipe the Panel PC with a dry, soft cloth. Precautions for Safe Use Do not use corrosive substances to clean the product. Doing so may result in the failure or malfunction.
Page 189: Check The Gasket Seal
7 Maintenance 7-1-4 Check the Gasket Seal The gasket prevents liquid from penetrating the mounting surface. A damaged gasket can lead to Panel PC or other hardware failures. Check the gasket on all 4 sides of the Panel PC. The gasket should be visible as a thin black line that has no dents or damage. Precautions for Safe Use As the rubber gasket will deteriorate, shrink, or harden depending on the operating environ- ment, periodical inspection is necessary.
Page 190: Corrective Maintenance
WARNING Do not attempt to disassemble, repair, or modify the product in any way. Doing so may result in malfunction or fire. Contact your local OMRON representative if the corrective maintenance actions did not solve the problem. 7-2-1 Warning and Error Messages Warning and Error messages are provided by the Industrial Panel PC when there is a potential prob- lem that may cause downtime.
Page 191 7 Maintenance Windows Action Center The Windows Action Center provides information on Windows related warnings and errors. The Windows Action Center indicates security and maintenance issues. Some examples: • Virus protection (Important) Windows did not find anti-virus software on this computer. •...
Page 192: Remove The Cover
7 Maintenance 7-2-2 Remove the Cover Applicable for products with a cooling layer that has a removable Cover. The Cover of the cooling layer provides access to the following items. • Battery • Fan Unit (applies to products with active cooling) The inside of the Cover contains a label with the battery replacement date.
Page 193: Replace The Fan Unit
7 Maintenance 7-2-3 Replace the Fan Unit The fans are mounted in the Fan Unit. Use the following procedure to replace the Fan Unit. Precautions for Safe Use If the storage period of the replacement fan exceeds 6 months, check the performance of the Fan Unit directly after replacement.
Page 194 7 Maintenance Replace the complete Fan Unit. 1) Push the lever to unlock the Fan Unit. 2) Lift the lever to tilt the Fan Unit. 3) Remove the complete Fan Unit. Insert the new Fan Unit in the Panel PC. Ensure the end of the Fan Unit A is positioned under the fan guide B .
Page 195: Replace The Battery
7 Maintenance 7-2-4 Replace the Battery Applicable for products with a cooling layer that has a removable cover. Precautions for Safe Use • The Battery may leak, rupture, heat, or ignite. Never short-circuit, charge, disassemble, heat, or incinerate the Battery or subject it to strong shock. •...
Page 196 7 Maintenance Lift the battery from the compartment. Disconnect the battery from the battery connector Connect the new battery to the battery connector. Place the new battery in the Panel PC. Ensure the wires are at the side of the battery and not on top of the battery. If the wires are on top of the battery this might make closing and opening the cover more difficult.
Page 197: Replace A Drive
7 Maintenance 7-2-5 Replace a Drive Use the following procedure to replace a drive. Prepare the new drive. Additional Information • Refer to 1-4 Product Configuration Panel PC on page 1-5 for the installed drive model. • Refer to 3-10-4 HDD and SSD Storage Devices on page 3-26 for the available drive models. •...
Page 198 7 Maintenance Pull the metal shielding cover out of the Panel PC. Insert the drive cover in the drive bracket bay and move it down so that it locks in the drive bracket. 7-14 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 199 7 Maintenance Remove the drive bracket from the Panel PC using the drive cover. Remove the 4 mounting screws and then remove the drive from the drive bracket. 7-15 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 200 7 Maintenance Align the connectors of the replacement drive as shown A on the bracket. Then insert the re- placement drive in the bracket and insert the 4 mounting screws . Tighten these screws with a torque of 0.35 N·m. Insert the bracket with the replacement drive into the correct bay of the Panel PC.
Page 201 7 Maintenance Insert the metal shielding cover. Mount the drive cover. The lock lever will click when closed correctly. Restore the drive data. • For an Industrial PC with a Windows operating system refer to the restore procedure in the section Corrective Maintenance to restore data.
Page 202: Replace The Pcie Card
7 Maintenance 7-2-6 Replace the PCIe Card Use the following procedure to replace the PCIe Card. Prepare: • The PCIe Card Additional Information Refer to 4-1-8 PCIe Card Specifications on page 4-17 for PCIe specifications. • The PCIe Card mounting materials: Card Clip and Card Support These are supplied with the Industrial Panel PC.
Page 203 7 Maintenance Push the notch at the bottom of the Card Support up and rotate the Card Support. Slide the Card Support away from the card to create space and to remove it. Remove the Card Clip from the PCIe Drawer. There are two types of Card Clips available.
Page 204 7 Maintenance Remove the PCIe Card from the PCIe Drawer. The PCIe Card is now removed. Place the replacement PCIe Card in the PCIe Drawer. Ensure the PCIe Card is inserted into the correct opening. 7-20 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 205 7 Maintenance Place the Card Clip A in the PCIe Card and PCIe Drawer. There are two types of Card Clips available. Use the steps applicable to your type. CAUTION When installing or removing a PCIe card, avoid touching the sharp edges of the sheet metal frame tab.
Page 206 7 Maintenance Slide the Card Support so that it supports the side of the PCIe Card. Rotate the Card Support to lock it in place. Ensure the Card Support contacts the PCIe Card with the small groove so that there is support below and above the PCIe Card.
Page 207: Replace The Cfast Card
7 Maintenance 7-2-7 Replace the CFast Card Use the following procedure to replace the CFast Card. Prepare the new CFast Card. Additional Information • Refer to 1-4 Product Configuration Panel PC on page 1-5 for the installed CFast Card model. •...
Page 208 7 Maintenance Insert the replacement CFast Card A into the slot of the Panel PC. Ensure the CFast Card A is completely in the Panel PC with an extra push using the CFast Card slot cover. If the CFast Card can not go in completely then the CFast Card orientation is incorrect. Re- move the CFast Card, turn it upside down and reinsert it.
Page 209 Appendices BIOS ....................... A-2 A-1-1 BIOS Overview....................A-2 A-1-2 BIOS for 4 generation CPUs................. A-4 A-1-3 BIOS for 7 generation CPUs............... A-13 A-1-4 BIOS for Atom CPUs..................A-43 DVI Connector Pin Details ................A-49 A-2-1 DVI-I Connector Pin Details ................A-49 A-2-2 DVI-D Connector Pin Details.................
Page 210: A-1 Bios
Appendices A-1 BIOS This section provides the BIOS information of the Industrial Panel PC. WARNING Changing BIOS information is only allowed for the engineer in charge that possesses a thorough understanding of the BIOS settings because it can change the behavior of the product.
Page 211 Appendices The menu bar gives access to following pages: • Main • Advanced • Chipset • Security • Boot • Save & Exit BIOS Navigation and Function Keys The right part of the BIOS screens is divided in two parts. Top part.
Page 212: Bios For 4 Th Generation Cpus
Appendices BIOS Password & Write Protection A BIOS password protects the BIOS setup program from unauthorized access. This ensures that users cannot change the system configuration without authorization. With an assigned BIOS pass- word, the BIOS prompts the user for a password on a setup entry. If the password entered is wrong, the BIOS setup program will not launch.
Page 213 Appendices BIOS - Advanced This section provides Advanced BIOS information for 4 generation CPUs. Changeable BIOS Advanced parameters and their factory default values: Item Default / Remark Disabled Machine Control Graphics Primary Graphics Device Auto Internal Graphics Device Auto IGD Pre-Allocated Graphics Memory IGD Total Graphics Memory 256M Primary IGD Boot Display Device...
Page 214 Appendices Item Default / Remark PCI & PCI Express PCI Express Gen 2 Set- Completion Timeout Default tings ARI Forwarding Disabled AtomicOp Requester En- Disabled able AtomicOp Egress Block- Disabled IDO Request Enable Disabled IDO Completion Enable Disabled LTR Mechanism Enable Disabled End-End TLP Prefix Disabled...
Page 215 Appendices Item Default / Remark PCI & PCI Express GbE Channel 0 PCI Express Port 0 Enabled ASPM Disabled GbE Channel 1 PCI Express Port 1 Enabled ASPM Disabled PCI Express Port 0, 1 (x4 PEG1 Speed Auto PEG1 ASPM Disabled Gen3) PEG1 De-emphasis Con-...
Page 216 Appendices Item Default / Remark CPU Information Display of CPU parame- ters Set Boot Freq Ratio Enabled *2 *1 Hyper-Threading Active Processor Cores Limit CPUID Maximum Disabled Execute Disable Bit Enabled Intel Vitalization Technology Enabled Hardware Prefetcher Enabled Adjacent Cache Line Prefetch Enabled Enabled *2 *1...
Page 217 Appendices Item Default / Remark SMART Settings Disabled Smart Self Test UEFI Network Stack UEFI Network Stack Disabled NVMe Configuration No NVME device found Intel® Ethernet NIC Configuration Link Speed Auto Negotiated Connection I218-LM - Wake On LAN Enabled Unique MAC Address Blink LEDs ®...
Page 218 Appendices BIOS - Chipset This section provides Chipset information for 4 generation CPUs. Changeable BIOS Chipset parameters and their factory default values: Item Default / Remark Platform Controller Hub PCI Express Clock Gating Disabled (PCH) DMI Link ASPM PCH Side Disabled DMI Link Extended Synch Control Disabled...
Page 219 Appendices BIOS - Boot Provides Boot information and configuration settings. Changeable BIOS Boot parameters and their factory default values: Item Default / Remark Quiet Boot Disabled Setup Prompt Timeout Bootup NumLock State Battery Support Auto (Battery Manager) Remain Off Power Loss Control CSM &...
Page 220 Appendices BIOS - Security Provides security information like BIOS Password and HDD information. WARNING Security setting adjustments should only be performed by the engineer in charge that possesses a thorough understanding of the security settings. Selecting non-recom- mended security settings can put your system at risk. Changeable BIOS Security parameters and their factory default values: Item Default / Remark...
Page 221: Bios For 7 Th Generation Cpus
Appendices A-1-3 BIOS for 7 generation CPUs The BIOS settings for 7 generation CPUs. Refer to the CPU information in 1-4 Product Configuration Panel PC on page 1-5 for generation de- tails. The BIOS is divided in the pages Main, Advanced, Chipset, Security, Boot and Save&Exit. BIOS - Main The main setup screen gives platform information about the BIOS, Board Information, Firmware Revi- sion, MAC Addresses and information about the number of Boots and the Running Time.
Page 222 Appendices BIOS - Advanced This section provides Advanced BIOS information for 7 generation CPUs. Changeable BIOS Advanced parameters and their factory default values are grouped with the combi- nation of your CPU type and the BIOS version. CPU type BIOS version Refer to Up to version BV£££008 BIOS - Advanced BIOS up to version 008 on...
Page 223 Appendices  BIOS - Advanced BIOS up to version 008 This section provides Advanced BIOS information for 7 generation CPUs: ® ™ • Intel Core i5-7300U with a BIOS version up to BU£££008 ® ® • Intel Celeron 3965U with a BIOS version up to BV£££008 For all other CPU types or BIOS versions refer to BIOS - Advanced on page A-14 for details.
Page 224 Appendices Item Default / Remark SW Guard Extensions (SGX) Software Controlled Select Owner EPOCH input type No Change in Owner EPOCHs CPU Flex Ratio Override Disabled Hardware Prefetcher Enabled Adjacent Cache Line Prefetch Enabled Intel (VMX) Virtualization Technology Enabled PECI Enabled Active Processor Cores Enabled...
Page 225 Appendices Item Default / Remark Power & Performance CPU - Power Man- Boot performance mode Max Non-Turbo Per- agement Control formance Intel ® SpeedStep ™ Enabled Race To Halt (RTH) Enabled Intel ® Speed Shift Technology Enabled HDC Control Enabled Enabled Turbo Mode CPU - Power Management Control /View/Configure Turbo Options...
Page 226 Appendices Item Default / Remark Power & Performance GT - Power Manage- Maximum GT frequency Default Max Frequen- ment Control PCH-FW Configura- Comms Hub Support Disabled tion JHI Support Disabled Core Bios Done Message Enabled Firmware Update Me FW Image Re-Flash Disabled Configuration PTT Configuration...
Page 227 Appendices Item Default / Remark Platform Settings UCSI Retry Workaround Disabled Firmware Configuration Test PS2 Keyboard and Mouse Enabled Pmic Vcc IO Level Disabled Pmic Vddq Level Disabled SLP_SO# VM Disabled Power Sharing Manager Disabled Wireless device Disabled Enable Wireless Charge Support Disabled Enable FFU support Disabled...
Page 228 Appendices Item Default / Remark PCI Configuration PCI Latency Timer 32 PCI Bus Clocks PCI-X Latency Timer 64 PCI Bus Clocks VGA Palette Snoop Disabled PERR# Generation Disabled SERR# Generation Disabled Above 4G Decoding Disabled PCI Hot-Plug Settings BIOS Hot-Plug Support Enabled PCI Buses Padding I/O Resoruces Padding...
Page 229 Appendices  BIOS - Advanced BIOS version 115 and higher This section provides Advanced BIOS information for 7 generation CPUs: ® ™ • Intel Core i5-7300U with a BIOS version BU£££115 and higher ® ® • Intel Celeron 3965U with a BIOS version BV£££115 and higher For all other CPU types or BIOS versions refer to BIOS - Advanced on page A-14 for details.
Page 230 Appendices Item Default / Remark Overcurrent Protection Disabled Legacy USB Support Enabled xHCI Hand-off Enabled USB Mass Storage Driver Support Enabled USB Transfer Timeout 20 sec Device Reset Timeout 20 sec Device Power-up Delay Selection Auto Generic Ultra HS-COMBO Auto ®...
Page 231 Appendices  BIOS - Advanced for CPU Type Intel ® ® Core i7-7820EQ ® ® This section provides Advanced BIOS information for the 7 generation CPU type Intel Core i7-7820EQ. For all other CPU types refer to BIOS - Advanced on page A-14 for details. Changeable BIOS Advanced parameters and their factory default values: Item Default / Remark...
Page 232 Appendices Item Default / Remark Trusted Computing Security Device Support Enable SHA-1 PCR Bank Enabled SHA256 PCR Bank Enabled Pending operation None Platform Hierarchy Enabled Storage Hierarchy Enabled Endorsement Hierarchy Enabled TPM2.0 UEFI Spec Version TCG_2 Physical Presence Spec Version Device Select Auto RTC Wake Settings...
Page 233 Appendices BIOS - Chipset This section provides Chipset information for 7 generation CPUs. Changeable Chipset parameters and their factory default values are grouped with the combination of your CPU type and the BIOS version. CPU type BIOS version Refer to •...
Page 234 Appendices  BIOS - Chipset BIOS up to version 008 This section provides Chipset information for 7 generation CPUs: ® ™ • Intel Core i5-7300U with a BIOS version up to BU£££008 ® ® • Intel Celeron 3965U with a BIOS version up to BV£££008 For all other CPU types or BIOS versions refer to BIOS - Chipset on page A-25 for details.
Page 235 Appendices Item Default / Remark Processor Memory Configuration / Memory Training Algorithms (Integrated Write Voltage Centering 2D Enabled Components) Read Voltage Centering 2D Enabled Late Command Training Enabled Round Trip Latency Enabled Turn Around Timing Training Enabled Rank Margin Tool Disabled Memory test Disabled...
Page 236 Appendices Item Default / Remark Processor Memory Configuration Force Single Rank Disabled (Integrated Memory Remap Enabled Components) Time Measure Disabled DLL Weak Lock Support Enabled Pwr Down Idle Timer Mrc Fast Boot Enabled Lpddr Mem WL Set Set B EV Loader Disabled EV Loader Delay Enabled...
Page 237 Appendices Item Default / Remark Platform Controller Isolate SMBus Segments Always Hub (PCH) PCI Express Configu- PCI Express Clock Gating Disabled ration Legacy IO Low Latency Disabled DMI Link ASPM PCH Side Disabled Port8xh Decode Disabled Peer Memory Write Enable Disabled Compliance Test Mode Disabled...
Page 238 Appendices Item Default / Remark Platform Controller SATA And RST Con- Hot Plug Disabled Hub (PCH) figuration Spin Up Device Disabled SATA Device Type Hard Disk Drive Topology Unknown SATA Port 2 DevSlp Disabled DITO Configuration Disabled USB Configuration XHCI Disable Compliance Mode False xDCI Support Disabled...
Page 239 Appendices  BIOS - Chipset Details This section provides BIOS Chipset details for: • 6 generation CPUs • 7 generation CPUs with a BIOS version upto version 008 For all other CPU types or BIOS versions refer to BIOS - Chipset on page A-25 for details. Memory Thermal Configuration ¢...
Page 240 Appendices PCI Express Port ¢ Provides BIOS Chipset details for the submenu Platform Controller Hub / PCI Express Configu- ration / PCI Express Port. Changeable BIOS PCI Express Port parameters and their factory default values: Item Default / Remark PCI Express Port Enabled Topology CPU specific...
Page 241 Appendices  BIOS - Chipset BIOS version 115 and higher This section provides Chipset BIOS information for 7 generation CPUs: ® ™ • Intel Core i5-7300U with a BIOS version BU£££115 and higher ® ® • Intel Celeron 3965U with a BIOS version BV£££115 and higher For all other CPU types or BIOS versions refer to BIOS - Chipset on page A-25 for details.
Page 242 Appendices Item Default / Remark Platform Controller Isolate SMBus Segments Always Hub (PCH) PCI Express Configu- PCI Express Port Enabled ration / PCI Express ASPM Disabled x2 Slot Hot Plug Disabled PCIe Speed Auto Extra options Detect Non-Compli- ance Device = Disa- bled Prefetchable Memory = 10...
Page 243 Appendices  BIOS - Chipset for CPU Type Intel ® ® Core i7-7820EQ ® ® This section provides Chipset information for the 7 generation CPU type Intel Core i7-7820EQ. For all other CPU types refer to BIOS - Chipset on page A-25 for details. Changeable BIOS Chipset parameters and their factory default values: Item Default / Remark...
Page 244 Appendices Item Default / Remark Platform Controller Isolate SMBus Segments During POST Hub (PCH) PCI Express Configu- PCI Express Port Enabled ration / PCI Express ASPM Disabled Port 0, 4, 6, 7 Hot Plug Disabled PCIe Speed Auto Extra options Detect Non-Compli- ance Device = Disa- bled...
Page 245 Appendices BIOS - Security Provides security information like BIOS Password and HDD information. WARNING Security setting adjustments should only be performed by the engineer in charge that possesses a thorough understanding of the security settings. Selecting non-recom- mended security settings can put your system at risk. Changeable BIOS Security parameters and their factory default values: Item Default / Remark...
Page 246 Appendices BIOS - Boot This section provides Boot information for 7 generation CPUs. Changeable Boot parameters and their factory default values are grouped with the combination of your CPU type and the BIOS version. CPU type BIOS version Refer to Up to version BV£££008 BIOS - Boot BIOS up to version 008 on page ®...
Page 247 Appendices  BIOS - Boot BIOS up to version 008 This section provides BIOS Boot information for 7 generation CPUs with a BIOS version up to B£ £££008. Changeable BIOS Boot parameters and their factory default values: Item Default / Remark Quiet Boot Disabled Setup Prompt Timeout...
Page 248 Appendices  BIOS - Boot BIOS version 115 and higher This section provides Advanced BIOS information for 7 generation CPUs: ® ™ • Intel Core i5-7300U with a BIOS version BU£££115 and higher ® ® • Intel Celeron 3965U with a BIOS version BV£££115 and higher For all other CPU types or BIOS versions refer to BIOS - Advanced on page A-14 for details.
Page 249 Appendices  BIOS - Boot for CPU Type Intel ® ® Core i7-7820EQ ® ® This section provides BIOS Boot information for CPU type Intel Core i7-7820EQ. Changeable BIOS Boot parameters and their factory default values: Item Default / Remark Quiet Boot Disabled Setup Prompt Timeout...
Page 250 Appendices BIOS - Save & Exit Provides the possibility to leave the BIOS with or without saving changes and to create or restore a set of User Defaults. Save & Exit Parameters: • Save Changes and Exit Changed settings are saved and the Operating System starts with the changed settings. •...
Page 251: Bios For Atom Cpus
Appendices A-1-4 BIOS for Atom CPUs The BIOS settings for Atom CPUs. The BIOS is divided in the pages Main, Advanced, Chipset, Security, Boot and Save&Exit. BIOS - Main The main setup screen gives platform information about the BIOS, Board Information, Firmware Revi- sion, MAC Addresses and information about the number of Boots and the Running Time.
Page 252 Appendices BIOS - Advanced This section provides Advanced BIOS information for a Panel PC with an Atom CPU. Changeable BIOS Advanced parameters and their factory default values: Item Default / Remark Trusted Computing Security Device Support Enabled SHA-1 PCR Bank Enabled SHA256 PCR Bank Enabled...
Page 253 Appendices BIOS - Chipset This section provides Chipset information for a Panel PC with an Atom CPU. Changeable BIOS Chipset parameters and their factory default values: Item Default / Remark Processor Max TOLUD 2 GB (Integrated Above 4GB MMIO BIOS assignment Disabled Components) Extention Graphic...
Page 254 Appendices BIOS - Security Provides security information like BIOS Password and HDD information for a Panel PC with an Atom CPU. WARNING Security setting adjustments should only be performed by the engineer in charge that possesses a thorough understanding of the security settings. Selecting non-recom- mended security settings can put your system at risk.
Page 255 Appendices BIOS - Boot Provides Boot information and configuration settings for a Panel PC with an Atom CPU. Changeable BIOS Boot parameters and their factory default values: Item Default / Remark Setup Prompt Timeout Bootup NumLock State Enter Setup If No Boot Device Enable Popup Boot Menu Boot Priority Selection Type Based...
Page 256 Appendices BIOS - Save & Exit Provides the possibility to leave the BIOS with or without saving changes and to create or restore a set of User Defaults. Save & Exit Parameters: • Save Changes and Exit Changed settings are saved and the Operating System starts with the changed settings. •...
Page 257: A-2 Dvi Connector Pin Details
Appendices A-2 DVI Connector Pin Details This section provides the pin details for the DVI-I connector and for the optional DVI-D connector. A-2-1 DVI-I Connector Pin Details Pin details of the DVI-I connector. C1 C2 C3 C4 The pin layout represents the DVI-I connector on the Industrial Panel PC. Pin numbers increase from left to right for every row.
Page 258: A-2-2 Dvi-D Connector Pin Details
Appendices Signal Name Function TMDS clock+ Digital clock+ TMDS clock− Digital clock− Analog red Analog red Analog green Analog green Analog blue Analog blue Analog horizontal sync Analog horizontal sync 0 VDC 0 VDC Only for models NY£17, NY£1E, NY£27 and NY5. Refer to 1-4 Product Configuration Panel PC on page 1-5 for details.
Page 259 Appendices Signal Name Function Return for pin 14 Hot plug detect TMDS data 0− Digital blue− (link 1) and digital sync TMDS data 0+ Digital blue+ (link 1) and digital sync 0 VDC TMDS data 0/5 shield Not connected Not connected 0 VDC TMDS clock shield TMDS clock+...
Page 260: A-3 Rs-232C Connector Pin Details
Appendices A-3 RS-232C Connector Pin Details The pin layout represents the RS-232C connector on the Panel PC. Signal Name 0 VDC The 0 VDC pin is internally connected to the ground connection. Additional Information Refer to 5-4-2 Ground on page 5-28 for grounding details. A-52 NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 261 Index NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 262 Index Index Accessory kit ..............3-24 Electrical Specifications ..............4-5 Err LED ................3-11 Ethernet connector ............3-18 Backup ................5-56 Ethernet connectors ............3-15 Base layer .................3-5 LED indicators .............4-27 Battery low ............... 3-9, 3-11 Link/Act indicator ............4-27 Battery ..............3-23, 7-8 Specifications ..............4-26 Replace ...............
Page 263 Index Mount ..............5-14, 5-27 Thermal shutdown ........... 3-9, 3-11 Touchscreen Operations ..............6-2 NY Monitor Link .............. 3-17 Cable................3-28 LED Indicators............. 4-31 Unpack ................5-2 Specifications...............4-30 UPS ............... 3-32, 5-50 Connect I/O..............5-53 Connect USB............... 5-51 USB connectors ..............3-14 PCIe Card ...............3-22 Specifications ..............4-25 Install ................5-8 USB flash drives .............
Page 264 Index NY-series Industrial Panel PC Hardware User's Manual (W555)
Page 266 The Netherlands Hoffman Estates, IL 60169 U.S.A. Tel: (31)2356-81-300/Fax: (31)2356-81-388 Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 © OMRON Corporation 2016-2021 All Rights Reserved. OMRON (CHINA) CO., LTD. OMRON ASIA PACIFIC PTE. LTD. In the interest of product improvement, Room 2211, Bank of China Tower, No.

This manual is also suitable for:

Sysmac nyp-1 series Sysmac nyp-2 series Sysmac nyp-3 series Sysmac nyp-4 series

Omron Sysmac NYP-0 Series Hardware User Manual

Sections in this Manual

Manual Information

Terms and Conditions Agreement

Safety Precautions

Precautions for Safe Use

Precautions for Correct Use

Regulations and Standards

Related Manuals

Terminology and Abbreviations

Revision History

Intended Use

Hardware Features

ID Information Label

Product Configuration Panel PC

Overall Setup Procedure

Industrial PC Platform Overview

Configuration for NYB and NYP

Layers and Components

LED Indicators

Power Button

Connectors

SD Memory Card Slot

Cfast Card Slot (Optional)

Drive Bays

Pcie Card Slot

Spare Parts

3-10 Optional Hardware

General Specifications

Connector Specifications

Display Specifications

Environmental Specifications

Unpack

Install Options

Mount

Wire

Connect

Initial Power on

Install Software

Connect UPS

Create Backup and Repair Data

Touchscreen Operation

Power on

Power off

React to Product Messages

React to Windows Messages

Preventive Maintenance

Corrective Maintenance

A-1 Bios

A-2 DVI Connector Pin Details

A-3 RS-232C Connector Pin Details

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Omron Sysmac NYP-0 Series

Summary of Contents for Omron Sysmac NYP-0 Series
